108 / 220
WOODWORKING
makita.ca
106
Flush Trimmer – Self-Piloting
For flush, square edges on plastic laminates.
Small diameter allows intricate and close quarter cuts.
No router guides are necessary.
TYPE
A
B
C
D E
PART NO.
1/4"
1/4"
1-1/16"
1/4" 1-1/2"
733128-0A
SOLID
CARBIDE
C
B
E
D
A
7° Bevel Trimmer – Self-Piloting
For 7° bevel edging on plastic laminates.
Small diameter allows intricate and close quarter
cuts. No router guides are necessary.
TYPE
A
B
C
D E
PART NO.
3/16"
1/4"
1-1/16"
1/4" 1-1/2"
733128-2A
SOLID
CARBIDE
C
B
E
D
A
2 Flute Flush Trimmer
For fast, smooth and accurate 90° flush trimming applications.
Non marring ball bearing pilot.
TYPE
A
B
C
D E
PART NO.
1/4"
1/2"
1"
1/4" 2-1/2"
733128-1A
3/8"
1/2"
1"
1/4"
2"
733128-7A
3/8"
1"
1-1/4"
1/4" 2-1/2"
733128-8A
1/2"
1/2"
1-1/4"
1/4"
2"
733128-9A
1/2"
1"
1-1/4"
1/4" 2-1/2"
733129-0A
CARBIDE
TIPPED
C
B
E
D
A
Combination Flush / 10° Bevel Trimmer
Gives both 90° flush or 10° bevel cut depending on depth setting.
Used with guide assembly.
TYPE
A
B
C
D E
PART NO.
1/4"
3/8"
1"
1/4" 1-1/2"
733128-5A
SOLID
CARBIDE
C
B
E
D
A
No File Trimmer
Eliminates hand filing of laminates that normally follows trimming.
These specially designed tools will flush trim the laminate and
break the sharp edge all in one pass.
TYPE
A
B
C
D E
PART NO.
1/8"
3/8"
1"
1/4" 1-7/8"
733327-A
CARBIDE
TIPPED
B
C
A
D
2 Flute 15° Bevel Trimmer
For smooth 15° bevel cuts.
REPLACEMENT BEARING NO. 733132-4A
TYPE
A
B
C
D E
PART NO.
1/2"
9/32"
1"
1/4" 1-7/8"
733128-3A
CARBIDE
TIPPED
2 Flute 25° Bevel Trimmer
For smooth 25° bevel cuts.
REPLACEMENT BEARING NO. 733132-4A
TYPE
A
B
C
D E
PART NO.
1/2"
9/32"
1"
1/4" 1-7/8"
733128-4A
SOLID
CARBIDE
C
B
E
D
A
C
B
E
D
A
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
TRIMMERACCESSORIES
Model
No.
Template
Guide
Straight
Guide
Trimmer
Guide
Trimmer
Base
Tilt Trimmer
Base
Trimmer
Shoe
Offset
Base
Plunge
Base
1/4" Collet
Cone
3709
343577-5
122704-5
122703-7
194267-1 122753-2 155263-4
-
-
763663-0
RT0701
122965-7
196613-4 196092-6
-
196093-4 196094-2 763637-1
RT0701C
LAMINATE TRIMMINGBITS
STANDARD EQUIPMENT INCLUDES:
1/4" Collet Cone (763663-0),Trimmer Guide (122703-7), Straight Guide (122704-5), Straight Bit 6E (733238-9),Template Guide 10 (343577-5),
Wrench 10 (781036-5), Wrench 17 (781037-3), Chip Deflector (418647-0),Aluminum Carrying Case (823293-0)
• Rack and Pinion Mechanism for fine depth adjustment
• Adjustable Guide for trimming laminates
• Ergonomic Slim Body style for maximum operator comfort and control
• Soft Rubber Grip design for vibration absorption
and comfortable operation
1/4" Trimmer
SPECIFICATIONS
Base Type
Transparent Base
Collet Capacity
1/4" (6.4 mm)
AMPS (120V)
4.0 A
No Load Speed
30,000 RPM
Overall Height
7-7/8" (199 mm)
Net Weight
3.3 lbs (1.5 kg)
3709X
STANDARD EQUIPMENT INCLUDES:
1/4" Collet Cone (763663-0),Trimmer Guide (122703-7), Straight Guide (122704-5), Straight Bit 6E (733238-9),
Template Guide 10 (343577-5), Wrench 10 (781036-5), Wrench 17 (781037-3), Chip Deflector (418647-0)
• Rack and Pinion Mechanism for fine depth adjustment
• Adjustable Guide for trimming laminates
• Ergonomic Slim Body style for maximum operator comfort and control
• Soft Rubber Grip design for vibration absorption and comfortable operation
1/4" Trimmer
SPECIFICATIONS
Base Type
Transparent Base
Collet Capacity
1/4" (6.4 mm)
AMPS (120V)
4.0 A
No Load Speed
30,000 RPM
Overall Height
7-7/8" (199 mm)
Net Weight
3.3 lbs (1.5 kg)
3709
Trimmer Base for 3709
194267-1
Tilt Trimmer Base for 3709
122753-2
Trimmer Base for RT0701
196613-4
Tilt Trimmer Base for RT0701
196092-6
