107 / 220
Electric
Power Tools
makita.ca
105
When
QUALITY&SERVICE
Counts – ChooseMakita
STANDARD EQUIPMENT INCLUDES:
1/4" Collet Cone (193214-9), 1/2" Collet Cone (193215-7),Two Wrenches 27 (781031-5)
On / Off Toggle Switch
• Electronic Speed Control maintains constant speed under heavy load
• Variable Speed Dial adjusts motor speed based on materials or application
• Soft Start feature gradually increases speed to eliminate start up shock
• 3 Stage Depth Adjustments ideal for use when performing deep or repetitive cutting operations
• Flat Top Design for increased stability when changing bits
• Industrial Cam-Lock enables fast and easy depth adjustment and removal of motor
• Sub-Base accepts industry standard template guides
Electronic Speed Control,
Variable Speed, Soft Start
2-1/4 HP Plunge Router
SPECIFICATIONS
Collet Capacities:
1/4", 1/2"
(6.4 mm, 12.7 mm)
Plunge Capacity
2-19/32" (66 mm)
No Load Speed
8,000 - 24,000 RPM
AMPS (120V)
11.0 A
Base Diameter
5-3/4" (146 mm)
Overall Height
11-1/2" (291 mm)
Net Weight
9.3 lbs (4.2 kg)
RP1101
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
1/4" Collet Cone (763637-1), Wrench 13 (781006-4), Wrench 22 (781011-1), Straight Guide (164834-6), Plastic Carrying Case (824880-8)
Compact And Lightweight Plunge Router With Enhanced Durability
• Large Ball Bearing on fan end and Dust Proof Bearing on commutator end of armature for
enhanced durability of tool
• 3 Stage Depth Adjustments ideal for use when performing deep or repetitive cutting operations
• Trigger Switch located on handle for operator convenience
• Conveniently located Plunge Locking Lever for easy engagement during operation
• Four Raised Ribs on top of Motor Housing provide a stable platform during bit changes
• Can be used with 55" (194368-5) or 118" (194367-7) Guide Rails and Router Guide Rail Adapter (194579-2)
for precision routing applications
1-1/4 HP Plunge Router
SPECIFICATIONS
Collet Capacities:
1/4", 3/8"
(6.4 mm, 9.5 mm)
Plunge Capacity
1-3/8" (35 mm)
No Load Speed
27,000 RPM
AMPS (120V)
8.0 A
Base Diameter
4-5/16" (110 mm)
Overall Height
8-17/32" (217 mm)
Net Weight
6.0 lbs (2.7 kg)
RP0900K
STANDARD EQUIPMENT INCLUDES:
1/4" Collet Sleeve (763803-0), Wrench 23 (781012-9), Wrench 21 (781029-2)
(Shown with Optional Guide Plate)
Trigger Switch with Lock-On Feature
• Large Calibrated Depth Control Ring for easy
depth adjustment
• D-Handle Design with Locking Trigger Switch for
maximum operator control and comfort during
continuous use applications
1-3/8 HP Router
SPECIFICATIONS
Collet Capacities:
1/4", 3/8", 1/2"
(6.4 mm, 9.5 mm, 12.7 mm)
Base Plate Diameter
6-1/4" (160 mm)
No Load Speed
23,000 RPM
AMP (120V)
8.5 A
Base Diameter
6-1/4" (159 mm)
Overall Height
7-1/2" (190 mm)
Net Weight
7.9 lbs (3.6 kg)
3601B
STANDARD EQUIPMENT INCLUDES:
1/4" Collet Cone (763608-8), Wrench 17 (781008-0)
Affordable Lightweight Router
• Large Calibrated Depth Control Ring for easy depth adjustment
• Shaft Lock enables quick changing of bits with just one wrench
• Ergonomic Handles for operator comfort and control
1 HP Router
SPECIFICATIONS
Collet Capacity
1/4" (6.4 mm)
No Load Speed
30,000 RPM
AMPS (120V)
7.0 A
Base Diameter
5-29/32" (150 mm)
Overall Height
7-1/8" (181 mm)
Net Weight
5.1 lbs (2.3 kg)
3606
STANDARD EQUIPMENT INCLUDES:
1/4" Collet Cone (763637-1), Straight Guide (122965-7),
Wrench 13 (781039-9), Wrench 22 (781011-1)
• Accepts Makita and other industry standard 2 piece template guides
• Soft start feature gradually increases speed to eliminate start up shock
• Constant speed control maintains constant speed under heavy load
• Variable speed dial allows operator to adjust speed based on materials or application
• Flat top design provides a stable platform when changing bits
• Shaft lock button enables quick and easy bit changes and eliminates the need for dual wrenches
• Aluminum base and housing offer increased durability and accuracy
• On/off rocker switch is easy to operate and eliminates interference with handling
1-1/4 HP Compact Router
SPECIFICATIONS
Collet Capacity
1/4", 3/8" (6.35 mm, 9.53 mm)
AMPS (120V)
6.5 A
No Load Speed
10,000 - 30,000 RPM
Maximum Horsepower
1-1/4 HP
Overall Height
7-7/8" (200 mm)
Net Weight
3.9 lbs (1.8 kg)
RT0701C
Compact and Versatile Router
For Maximum Versatility
• Accepts Makita and other industry standard
2 piece template guides
• Soft start feature gradually increases speed to
eliminate start up shock
• Constant speed control maintains constant speed
under heavy load
• Variable speed dial allows operator to adjust speed
based on materials or application
1-1/4 HP Compact Router
SPECIFICATIONS
Collet Capacity
1/4", 3/8" (6.35 mm, 9.53 mm)
AMPS (120V)
6.5 A
No Load Speed
10,000 - 30,000 RPM
Maximum Horsepower
1-1/4 HP
Overall Height
7-7/8" (200 mm)
Net Weight
3.9 lbs (1.8 kg)
RT0701CX8
Compact and Versatile
Router with
4 Base Options
for Maximum
Versatility
STANDARD EQUIPMENT INCLUDES:
1/4" ColletCone (763637-1), 3/8" ColletCone (763619-3),Trimmer
Guide (122703-7),StraightGuide (122965-7),TemplateGuide10
(343577-5),TemplateGuide 16 (193043-0), Wrench 13 (781039-9),
Wrench 22 (781011-1),PlungeBaseSet (196094-2),TiltBaseSet
(196092-6),GuideHolderSet (195564-8),OffsetBaseSet (196093-4),
DustNozzleSet-PlungeBase (P-80011),SideHandle (153489-2),
ToolBag (831327-5)
Trigger Switch
On / Off Toggle Switch
