General Catalogue

18V LXT

Outdoor Power Equipment

makita.ca

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

Makita offers a wide variety of

ACCESSORIES!

DUC400Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

16" Chain (196742-3), 16" Guide Bar (165247-4), Chain Cover (419242-9), Oil Supply (182229-1), Spike Bumper (347078-5)

16" / 18Vx2 LXT Cordless Chainsaw

with Specialized Battery Positioning

for Optimum Balance and Control

• Fast, Variable Speed (3,940 Feet Per Minute)

Equivalent to a 30 cc Gasoline Chainsaw

• Specialized 18Vx2 Battery Positioning is the Makita

Industry Game Changer within the Cordless

Product line offering Premium Balance, Control

and Cutting Performance

• Makita Built Outer Rotor Brushless Motor Direct

Drive System for High Power & Speed equivalent

to a 30 cc Gasoline Chainsaw

16" Chainsaw

SPECIFICATIONS

Battery Capacities

Two 18V Li-Ion

Guide Bar Length

16" (400 mm)

Chain Pitch / Gauge

3/8" / 0.043"

Chain Speed 0-3,940 FPM (0-1 200 m/min)

Overall Length

32-1/4" (818 mm)

Net Weight

9.3 lbs (4.2 kg)

Brushless Outer Motor

+ XPT + 3 Year Limited Warranty

Toolless Chain Tension

Adjustment

Features Extreme Protection Technology (XPT™) to provide increased dust and water resistance in harsh job site conditions

• Delivers up to 60 minutes of run time under load using one 18V LXT (6.0 Ah) BL1860 battery

• Holds (2) 18V LXT Lithium-Ion batteries but operates using (1) 18V battery at a time; utilizes second battery when needed

• Makita-built BL™ Brushless Motor for optimal performance

• 2-speed with maximum speed up to 2.5 MPH on a 12º incline

• Maximum load capacity up to 287 lbs (130 kg)

• 7" mechanical disc brake for faster stopping

• Rear wheel spacing is adjustable from 19" to 30" to accommodate the work environment

• L-shaped legs can be easily installed to replace rear wheels

• L.E.D. lights on each side of frame to illuminate the work area

DCU180ZX1, DCU180ZX2

Power-Assisted Wheelbarrows

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Maximum Speed:

Forward, High / Low

0 - 3.5 km/h / 0 - 1.5 km/h

Reverse

0 - 1.0 km/h

Minimum Turning Radius

(Outer diameter when turning with front wheel as axis) 110 cm

Maximum Climbing Capacity

12°

Maximum Load Capacity

287 lbs (130 kg)

DCU180ZX1:

Overall Dimensions during operation (L x W x H)

61-1/2" x 41-3/4" x 35-1/2" (156 cm x 106 cm x 90 cm)

Net Weight

97.5 lbs (44.2 kg)

DCU180ZX2:

Overall Dimensions during operation (L x W x H)

51-1/2" x 31-1/8" x 35-1/2" (131 cm x 79 cm x 90 cm)

Net Weight

86 lbs (39 kg)

Convenient

solution for

material

transport

on job sites

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and

Charger Sold Separately.

Support Foot (2 Ea. 144675-6),

Key (643890-4),

Wrench 13 (2 Ea. 781006-4),

Bucket (198494-2)

DCU180ZX2

with Bucket

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Support Foot (2 Ea. 144675-6), Key (643890-4),

Wrench 13 (2 Ea. 781006-4), FlatbedTray (199116-7)

DCU180ZX1

with Flatbed Tray

18V x2 LXT POWER-ASSISTED

WHEELBARROWACCESSORIES

FLATBED TRAY

199116-7

BUCKET

198494-2

Description

• Easy four bolt installation and removal

• Side rails install in up or down position;

large knob for easy adjustment

• Ideal for loading heavy duty bulky

material such as bricks, concrete

bags and more

• For use with Makita Power Assisted

Wheelbarrow model DCU180Z

•

INCLUDES:

Flatbed Tray

• Easy four bolt installation

and removal

• Heavy duty steel based bucket

for tough workloads

• Ideal for transporting material

on job sites

• For use with Makita Power Assisted

Wheelbarrow model DCU180Z

•

INCLUDES:

Bucket

TWO BATTERIES DELIVER

Max Power, Speed & Run Time
