MAXIMUMAIR FLOW
The
AMOUNT
of air being drawn in by the turbine. Typically measured in cubic feet per minute (CFM)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
1-1/8" x 11-1/2' Hose With Front Cuffs 22, 24And 38 (195433-3),
Poly Bag (10 / Pk) (195432-5), HEPAFilter (197166-6), Damper (195552-5), Pre-Filter (195553-3),AccessoryTool Box (455732-8)
Operates With DC (18Vx2 Li-Ion) Power Sources For
Maximum Jobsite Efficiency And Versatility
• HEPA filter certified to 99.99% efficiency (0.01% permeability at 0.3 - 0.5 microns (μm)
• Accepts 2 x 18V Li-Ion batteries without a battery converter for use with existing 18V Li-ion battery platform
• Variable suction power enables operator to adjust the suction power to the application
• Large on / off switch enables easy operation
• Battery cover protects batteries against
water penetration
• Caster stoppers protects vacuum cleaner against
unintentional movement
during operation
15.0 L & 8.0 L Dry Only Vacuum Cleaners
Dry Only
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Wireless Remote Controller (SH00000238), Side Brushes (SH00000065),
50' Boundary LineTape (SH00000240), Power Brush (SH00000063),Turn Brush Cover Protector (SH00000064), Filter (SH00000213)
19 Sensors Enable Optimal Vacuuming Performance
• Accepts Two 18V Li-Ion Batteries from our 18V Li-Ion Battery platform
• Brushless DC Motor with High Power to Weight and Size ratio generates less
heat buildup and is ideal for periods of prolonged use
• Operates in Random or Pattern mode for maximum vacuuming efficiency
• Two Dust Collection modes suitable for a wide range of vacuuming applications:
Vacuum Plus Power Brush, for small and large debris / Power Brush only, for large debris
• 19 Sensors enable Optimal Vacuuming Performance through automatic operation and obstacle
detection (Bumper Sensor, Gyro Sensor, 2x IR Sensors, 4x IR Cliff Sensors, Magnetic Field Sensor,
2x Wheel Sensors and 8x Ultrasonic Sensors)
2.5 L Robotic Vacuum Cleaner
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Container Capacity
2.5 L
Continuous Use with Two 18V (5.0 Ah) Batteries
Approx. 3.3 hours
Maximum Cleaning Area with Two
18V (5.0 Ah) Batteries 5,382 sq.ft.
(500 m
2
)
Running Mode
Random / Pattern
Overall Length
18-1/8" (460 mm)
Net Weight
14.6 lbs (6.6 kg)
DRC200Z
Cleans Up To 5,382 sq.ft. in 3.3 Hours
*
*withadditional50'ofBoundaryLineTape&Two18V (5.0Ah)Li-IonBatteries
DVC350Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold
Separately.
Blower Nozzle (132025-7),
Dust Bag (122918-6), 1-1/8" x 8' Hose
With Front Cuff 22 (140456-6),
Shoulder Harness (166094-6),
Front Cuff 38 (195545-2)
Portable & Versatile Vacuum Cleaner
2-Speed
• Push Button Air Volume Selection
(High / Low Settings)
• Shoulder Strap for operator convenience
• Can be converted into a blower by attaching
nozzle assembly
3.0 L Vacuum Cleaner
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Container Capacity
3.0 L
Continuous Use with 18V (5.0 Ah) Battery:
Approx. 21 minutes (High)
Approx. 42 minutes (Low)
Maximum Air Flow
120 CFM
Maximum Air Speed 308 ft./s (94 m/s)
Power:
50 W (High) / 15 W (Low)
Static Water Lift
22" (560 mm)
Overall Length
15-7/8" (403 mm)
Net Weight
3.5 lbs (1.6 kg)
Includes
Powerful
Blower
Feature
DVC750LZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
HEPAFilter (162518-0), 1-1/8" x 6-1/2' Hose (140G04-3), Wide Nozzle (458891-7),
Sash Nozzle (458919-1)
Operates On DC (18V Li-Ion) Power Source For Maximum Jobsite Efficiency And
Versatility / L Class Vacuum Cleaner Suitable For Wet and Dry Applications
• For wet and dry vacuuming cleaning
• Washable HEPA filter cartridge filter
• Brushless DC motor with high power to weight and size ratio
• Suction power enables operator to adjust the suction power to the application (Normal 1 / High 2)
• Battery cover protects batteries against water penetration
• Convenient Carriage Handle for portable transport
• Sash Nozzle and Wide Nozzle can be fixed onto the
body for convenient storage
• Removable dust canister can be emptied quickly
and easily for minimal downtime
• Use with optional Shoulder Strap part no. 199486-4
7.5 L Portable Vacuum Cleaner
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Dry Tank Capacity
7.5 L
Wet Tank Capacity
4.5 L
Continuous Use with 18V (5.0 Ah) Battery:
Approx. 30 minutes (High)
Approx. 60 minutes (Low)
Maximum Air Flow
57 CFM
Power:
90 W (High) / 25 W (Normal)
Static Water Lift
26.9" (680 mm)
Overall Length
16-1/2" (418 mm)
Net Weight
8.8 lbs (4.0 kg)
See pages 80-83 for our
FULL LINE
of
VacuumCleaner Accessories
DCL280FZB
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Floor Nozzle (123539-7), Sash Nozzle (456586-6), Pipe (458942-6),
Sash Nozzle Holder (459038-6), High Efficiency Filter (199966-0)
Lightweight And Portable Vacuum Cleaner For Professional Use, Office
Or Home Use / Trigger Switch + Sliding Lock-On Switch
• Enhanced motor durability equipped with BL motor and improved
dust-resistant performance
• Pipe is fixed by the locking mechanism to prevent it from
accidentally coming off
• On board sash nozzle storage
• Angled suction port enables cleaning without floor
nozzle and prevents extension pipes from
wobbling during operation
• Floor nozzle swivel joint design
keeps vacuum head close to
surface and enables 360º
rotation for easy
high-reach cleaning
750 ml Vacuum Cleaner
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Container Capacity
750 ml
Continuous Use with 18V (5.0 Ah) Battery
Approx. 17 minutes
Maximum Air Flow
49 CFM
Power
40 W
Static Water Lift
25.7" (650 mm)
Overall Length
40" (102 cm)
Net Weight
2.0 lbs (0.9 kg)
DVC750Z
DVC153LZX (15.0 L) DVC863LZX (8.0 L)
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Continuous Use with Two 18V (5.0 Ah) Batteries
Approx. 40 minutes
Maximum Air Flow
74 CFM
Power
90 W
Static Water Lift
39.4" (100 cm)
Overall Length
14-3/8" (366 mm)
Container Capacity:
DVC153LZX
15.0 L
DVC863LZX
8.0 L
Net Weight:
DVC153LZX
16.1 lbs (7.3 kg)
DVC863LZX
14.4 lbs (6.5 kg)
