STATICWATER LIFT
A measure of
AIR POWER
being drawn in by the turbine. Measured in terms of the total height at which a 2" column of water can be drawn.
STANDARD EQUIPMENT INCLUDES:
DVC261TX11:
Two 18V (5.0Ah)Li-IonBatteries
BL1850B (196675-2),DualPortRapidCharger (DC18RD),BatteryCover (450128-8),
HEPAFilter (123636-9), 1-1/8"X3'Hose (143787-2),HoseBand (166116-2),BentPipe (127093-3),FlexibleRubberNozzle (197900-4),
FloorNozzle (127082-8),TelescopicPipe (140G19-0),PaperFilterBag (197902-0),BackpackShoulderHarness (162469-7)
DVC261ZX:
ToolOnly.BatteriesandChargerSoldSeparately.
HEPAFilter (123636-9),1-1/8"X5'HoseWithFrontCuff 38 (152992-0),Hose
Band (166116-2),PaperFilterBag (1Ea. 197902-0),FrontCuff 22 (195547-8),FrontCuff 24 (424379-9),BackpackShoulderHarness (162469-7)
DVC261ZX11:
ToolOnly.BatteriesandChargerSoldSeparately.
HEPAFilter (123636-9),1-1/8"X3'Hose (143787-2),
HoseBand (166116-2),FlexibleRubberNozzle (197900-4),FloorNozzle (127082-8),TelescopicPipe (140G19-0),BentPipe (127093-3),
PaperFilterBag (1Ea. 197902-0),BackpackShoulderHarness (162469-7)
Makita 18Vx2 LXT Brushless Backpack Vacuum Is A Powerful
And Portable Cleaning And Dust Extraction Solution
• Up to 140 minutes of continuous operation using two 18V (5.0 Ah) LXT batteries
• Two stage HEPA filtration system captures large, small and micro dust particulates and is certified to
99.99% efficiency (0.01% permeability)
at 0.3 - 0.5 microns (µm)
• Makita brushless motor generates 71 CFM of
suction power and 44.2˝ of static water lift
2.0 L Backpack Vacuum Cleaners
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Container Capacity
2.0 L
Continuous Use with Two 18V (6.0 Ah) Batteries:
Approx. 40 minutes (Max)
Approx. 75 minutes (High)
Approx. 140 minutes (Low)
Maximum Air Flow
71 CFM
Power: 90 W (Max) / 45 W (High) / 25 W (Low)
Static Water Lift
44" (112 cm)
Overall Length
9" (230 mm)
Net Weight
7.0 lbs (3.1 kg)
DVC261ZX DVC261ZX11
STANDARD EQUIPMENT INCLUDES:
ToolOnly.Batteries andChargerSoldSeparately.
HEPAFilter (123636-9), 1-1/8"X 5'HoseWithFrontCuff 38 (152992-0),
HoseBand (166116-2),PaperFilterBag (1Ea. 197902-0),FrontCuff 22 (195547-8),FrontCuff 24 (424379-9),
Auto-startWirelessSystem (AWS)Bluetooth
®
Transmitter (198901-5),BackpackShoulderHarness (162469-7)
Auto-Start Wireless System (AWS) Technology Features
Wireless Dust Collection Technology!
• AWS (Auto-Start Wireless System) uses Bluetooth technology to communicate between tool and vacuum
and enable wireless control when used with Makita AWS cordless tools
• Up to 75 minutes of continuous operation using two 18V (5.0 Ah) LXT batteries
• Two stage HEPA filtration system captures large, small and micro dust particulates and is certified to
99.99% efficiency (0.01% permeability) at 0.3 - 0.5 microns (µm)
• Makita brushless motor generates 64 CFM of suction power and 44.2˝ of water lift
2.0 L Backpack Vacuum Cleaner with AWS
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Container Capacity
2.0 L
Continuous Use with Two 18V (6.0 Ah) Batteries:
Approx. 40 minutes (High)
Approx. 75 minutes (Low)
Maximum Air Flow
64 CFM
Power:
85 W (High) / 45 W (Low)
Static Water Lift
44.2" (112 cm)
Overall Length
9" (230 mm)
Net Weight
7.1 lbs (3.2 kg)
DVC265ZXU
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Floor Nozzle
(122512-4), 1-1/2" x 11-1/2' Hose (195434-1), 1-1/8" x 11-1/2' Hose
With Front Cuffs 22, 24And 38 (195433-3), Poly Bag (10 / Pk)
(195432-5), 22" Straight Pipe (192563-1), 22" Bending Pipe (192562-3),
12" Corner Nozzle (410306-2), HEPAFilter (197166-6), Damper
(195552-5), Pre-Filter (195553-3),AccessoryTool Box (455732-8)
Operates With AC (120V) Or DC (18Vx2 Li-Ion) Power
Sources For Maximum Jobsite Efficiency And Versatility
• HEPA filter certified to 99.99% efficiency
(0.01% permeability at 0.3 - 0.5
microns (μm)
• Variable speed power enables
operator to adjust the suction
power to the application
• Large on / off switch enables
easy operation
• 3 stage HEPA filtration
system suitable for use
with dry L class
materials only
15.0 L & 8.0 L LXT & AC Dry Only Vacuum Cleaners
DVC861LZ (8.0 L)
Dry Only
Cordless
or Electric
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
1-1/8" x 11-1/2' Hose With Front Cuffs 22, 24And 38 (195433-3),
Poly Bag (10 / Pk) (195432-5), HEPAFilter (197166-6), Damper
(195552-5), Pre-Filter (195553-3),AccessoryTool Box (455732-8),
Auto-start Wireless System (AWS) Bluetooth
®
Transmitter (198901-5)
Auto-Start Wireless System (AWS) Technology Features
Wireless Dust Collection Technology!
• 3 stage HEPA filtration system suitable for use with dry L class materials only
• Variable suction power enables operator to adjust the suction power to the application
• Large on / off switch enables easy operation
• Battery cover protects batteries against water penetration
• Caster stoppers protects vacuum cleaner against unintentional movement during operation
15.0 L & 8.0 L Dry Only Vacuum Cleaners with AWS
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Continuous Use with Two 18V (5.0 Ah) Batteries
Approx. 40 minutes
Maximum Air Flow
74 CFM
Power
90 W
Static Water Lift
39.4" (100 cm)
Overall Length
14-3/8" (366 mm)
Container Capacity:
DVC154LZXU
15.0 L
DVC864LZX2
8.0 L
Net Weight:
DVC154LZXU
16.1 lbs (7.3 kg)
DVC864LZX2
15.7 lbs (7.1 kg)
DVC154LZXU (15.0 L) DVC864LZX2 (8.0 L)
Bluetooth
®
is a registered trademark of Bluetooth
®
SIG
Dry Only
See pages 80-83 for our
FULL LINE
of
VacuumCleaner Accessories
Switch on the Tool & Vacuum Cleaner is
ACTIVATED!
• AWS transmitter enables Bluetooth
®
connectivity between AWS tool and AWS dust extractor
• Maximum transmission distance: approx. 33' / 10m
• For use with AWS tools
Auto-start Wireless System (AWS) Bluetooth
®
Transmitter
198901-5
DVC864LZX2
Bluetooth
®
is a registered
trademark of Bluetooth
®
SIG
Bluetooth
®
is a
registered trademark
of Bluetooth
®
SIG
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Floor Nozzle
(122512-4), 1-1/2" x 11-1/2' Hose (195434-1), Poly Bag (10 / Pk)
(195432-5), 22" Straight Pipe (192563-1), 22" Bending Pipe (192562-3),
12" Corner Nozzle (410306-2),AccessoryTool Box (455732-8),
Cloth Filter (140248-3)
Operates With DC (18Vx2 Li-Ion) Power Sources For
Maximum Jobsite Efficiency And Versatility
• Accepts 2 x 18V Li-Ion batteries without a battery converter for use with
existing 18V Li-ion battery platform
• Variable suction power enables
operator to adjust the suction
power to the application
• Large on / off switch
enables easy operation
• Battery cover protects
batteries against water
penetration
15.0 L & 8.0 L Wet & Dry Vacuum Cleaners
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Continuous Use with Two 18V (5.0 Ah) Batteries
Approx. 65 minutes
Maximum Air Flow
74 CFM
Power
90 W
Static Water Lift
39.4" (100 cm)
Overall Length
14-3/8" (366 mm)
Container Capacity:
DVC152LZ
Dry Tank Capacity 15.0 L
Wet Tank Capacity 12.0 L
DVC862LZ
Dry Tank Capacity 8.0 L
Wet Tank Capacity 6.0 L
Net Weight:
DVC152LZ
14.6 lbs (6.6 kg)
DVC862LZ
12.8 lbs (5.8 kg)
Wet & Dry
DVC261TX11
DVC152LZ (15.0 L) DVC862LZ (8.0 L)
DVC151LZ (15.0 L)
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Continuous Use with Two 18V (5.0 Ah) Batteries
Approx. 65 minutes
Maximum Air Flow: 74 CFM on DC power
127 CFM on AC power
Power:
70 W DC power / 320 W on AC power
Static Water Lift: 36.2" (91 cm) on DC power
96.4" (245 cm) on AC power
AMPS (120V)
9.2 A
Overall Length
14-3/8" (366 mm)
Container Capacity:
DVC151LZ
15.0 L
DVC861LZ
8.0 L
Power Cord Length:
DVC151LZ
16.4 ft (5.0 m)
DVC861LZ
19.7 ft (6.0 m)
Net Weight:
DVC151LZ
19.9 lbs (9.0 kg)
DVC861LZ
19.2 lbs (8.7 kg)
