88 / 220
BENCHTOP
makita.ca
86
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
10" C.T. Blade 40T (JM23000176), Box Wrench 13-3 (JM23100197), Dust Bag (JM23100501), Vertical Vise (JM23100502),
Triangle Rule (JM27000328),Two Holders (322312-4)
Affordable, Professional Quality
• Sliding Rail Mechanism incorporating 3 Linear Ball Bearings provides increased rigidity to produce
precise, adjustment free cuts right out of the box
• Sliding Fence (Left Side) can be adjusted outwards when bevel cutting or inwards for increased support
of small or delicate materials
• Soft Start feature gradually increases speed to eliminate start up shock
• Battery Operated, Factory Calibrated Class II Laser enables accurate alignment of blade and cutting line
• Bevel Capacity of 45° Left or Right
• Mitre Capacity of 47° Left or 60° Right with Positive Stops at 0°, 15°, 22.5°, 31.6° & 45°
10
"
Sliding Compound Mitre Saw With Laser
SPECIFICATIONS
Blade Diameter
10" (255 mm)
Arbor
5/8" (15.88 mm)
No Load Speed
4,300 RPM
AMPS (120V)
13.0 A
Overall Dimensions (L x W x H)
32-1/2" x 21-1/8" x 25"
(825 mm x 536 mm x 633 mm)
Net Weight
43.7 lbs (19.8 kg)
LS1018L
STANDARD EQUIPMENT INCLUDES:
10" C.T. Blade 40T (JM23000176), Box Wrench 13-3 (JM23100197), Dust Bag (JM23100501), Vertical Vise (JM23100502),
Triangle Rule (JM27000328),Two Holders (322312-4), Mitre Saw Stand (WST06)
Affordable, Professional Quality
• Sliding Rail Mechanism incorporating 3 Linear Ball Bearings provides increased rigidity to produce
precise, adjustment free cuts right out of the box
• Sliding Fence (Left Side) can be adjusted outwards when bevel cutting or inwards for increased support
of small or delicate materials
• Soft Start feature gradually increases speed to eliminate start up shock
• Battery Operated, Factory Calibrated Class II Laser enables accurate alignment of blade and cutting line
• Bevel Capacity of 45° Left or Right
• Mitre Capacity of 47° Left or 60° Right with Positive Stops at 0°, 15°, 22.5°, 31.6° & 45°
• Includes Mitre Saw Stand (WST06) for easy transport and jobsite portability
10
"
Sliding Compound Mitre Saw With Laser And Mitre Saw Stand
SPECIFICATIONS
Blade Diameter
10" (255 mm)
Arbor
5/8" (15.88 mm)
No Load Speed
4,300 RPM
AMPS (120V)
13.0 A
Overall Dimensions (L x W x H)
32-1/2" x 21-1/8" x 25"
(825 mm x 536 mm x 633 mm)
Net Weight
43.7 lbs (19.8 kg)
Makita offers a wide variety of
ACCESSORIES!
STANDARD EQUIPMENT INCLUDES:
12" C.T. Blade 60T (A-93712), Dust Bag (122852-0), Vertical Vise (126617-2),Triangle Rule (762001-3), Holder 90 (327145-2),
Hex Wrench 6 (781044-6)
NEW Close To Wall "Zero Clearance" Design!
• Rail forward design enables saw to be placed against wall to maximize effective workspace
• Integrated guide fence and lower fence increases rigidity and support of materials
• Front bevel knob enables easy adjustment without reaching for operator convenience and precise
setting of bevel angle
• Constant Speed Control maintains constant speed under heavy load
• Soft Start feature gradually increases speed to eliminate start up shock
• Electric brake stops blade quickly after trigger is released for increased operator safety
• Bevel capacity of 48° left or right with positive stops at 0°, 22.5°, 33.9°, 45° & 48°
12
"
Sliding Compound Mitre Saw
SPECIFICATIONS
Blade Diameter
12"(305 mm)
Arbor
1" (25.4 mm)
No Load Speed
3,200 RPM
AMPS (120V)
15.0 A
Overall Dimensions (L xW x H)
35-1/4" x 26-1/8" x 28-1/2"
(898 mm x 664 mm x 725 mm)
Net Weight
64.6 lbs (29.3 kg)
LS1219
Incorporates Makita's Deep And eXact
Cutting Technology (DXT)
STANDARD EQUIPMENT INCLUDES:
12" C.T. Blade 60T (A-93712), Dust Bag (122852-0), Vertical Vise (126617-2),Triangle Rule (762001-3), Holder 90 (327145-2),
Hex Wrench 6 (781044-6), Hex Wrench 2.5 (783208-8)
NEW Close To Wall "Zero Clearance" Design!
• Rail forward design enables saw to be placed against wall to maximize effective workspace
• Integrated guide fence and lower fence increases rigidity and support of materials
• Front bevel knob enables easy adjustment without reaching for operator convenience and precise
setting of bevel angle
• Constant Speed Control maintains constant speed under heavy load
• Soft Start feature gradually increases speed to eliminate start up shock
• Electric brake stops blade quickly after trigger is released for increased operator safety
• Bevel capacity of 48° left or right with positive stops at 0°, 22.5°, 33.9°, 45° & 48°
• Laser marker enables accurate alignment of blade and cutting line
12
"
Sliding Compound Mitre Saw with Laser
SPECIFICATIONS
Blade Diameter
12" (305 mm)
Arbor
1" (25.4 mm)
No Load Speed
3,200 RPM
AMPS (120V)
15.0 A
Overall Dimensions (L xW x H)
35-1/4" x 26-1/8" x 28-1/2"
(898 mm x 664 mm x 725 mm)
Net Weight
65 lbs (29.5 kg)
LS1219L
Incorporates Makita's Deep And eXact
Cutting Technology (DXT)
STANDARD EQUIPMENT INCLUDES:
10" C.T. Blade 60T (A-93675), Hex Wrench 6 (781044-6), Dust Bag (122852-0), Vertical Vise (126617-2),Triangle Rule (762001-3),
Dust Nozzle (123980-4),Two Holders (326978-2), Wrench Holder (416536-3)
NEW Close To Wall "Zero Clearance" Design!
Up To 12" Cuts In 2x Material, 6-5/8" Nested Crown Moulding And 5-1/4" Vertical Baseboard
• Rail forward design enables saw to be placed against wall to maximize effective workspace
• 3 stage gear reduction system greatly increases capacity when cutting vertical baseboard or
nested crown molding
• 1-3/16" guide rail diameter provides increased stability and cutting precision
• Integrated guide fence and lower fence increases rigidity and support of materials
• Fence design allows fence to be secured to holders to prevent damage and/or loss
• Front bevel knob enables easy adjustment without reaching for operator convenience and precise
setting of bevel angle
10
"
Sliding Compound Mitre Saw
SPECIFICATIONS
Blade Diameter
10" (255 mm)
Arbor
5/8" (15.88 mm)
No Load Speed
3,200 RPM
AMPS (120V)
15.0 A
Overall Dimensions (L x W x H)
31-3/4" x 25" x 26"
(805 mm x 644 mm x 660 mm)
Net Weight
57.9 lbs (26.3 kg)
LS1019
Incorporates Makita's Deep And eXact
Cutting Technology (DXT)
STANDARD EQUIPMENT INCLUDES:
10" C.T. Blade 60T (A-93675), Hex Wrench 6 (781044-6), Hex Wrench 2.5 (783208-8), Dust Bag (122852-0), Vertical Vise (126617-2),
Triangle Rule (762001-3), Dust Nozzle (123980-4),Two Holders (326978-2), Wrench Holder (416536-3)
NEW Close To Wall "Zero Clearance" Design!
Up To 12" Cuts In 2x Material, 6-5/8" Nested Crown Moulding And 5-1/4" Vertical Baseboard
• Rail forward design enables saw to be placed against wall to maximize effective workspace
• 3 stage gear reduction system greatly increases capacity when cutting vertical baseboard or
nested crown molding
• 1-3/16" guide rail diameter provides increased stability and cutting precision
• Integrated guide fence and lower fence increases rigidity and support of materials
• Fence design allows fence to be secured to holders to prevent damage and/or loss
• Front bevel knob enables easy adjustment without reaching for operator convenience and precise
setting of bevel angle
• Laser marker enables accurate alignment of blade
and cutting line
10
"
Sliding Compound Mitre Saw with Laser
SPECIFICATIONS
Blade Diameter
10˝ (255 mm)
Arbor
5/8" (15.88 mm)
No Load Speed
3,200 RPM
AMPS (120V)
15.0 A
Overall Dimensions (L x W x H)
31-3/4" x 25" x 26"
(805 mm x 644 mm x 660 mm)
Net Weight
57.9 lbs (26.3 kg)
LS1019L
Incorporates Makita's Deep And eXact
Cutting Technology (DXT)
LS1018LX4
Up To 15" Cuts
In 2x Material,
8" Nested Crown
Moulding and
6-3/4" Vertical
Baseboard
Up To 15" Cuts
In 2x Material,
8" Nested Crown
Moulding and
6-3/4" Vertical
Baseboard
