89 / 220
STANDARD EQUIPMENT INCLUDES:
8-1/2" C.T. Blade 48T (A-95934), Box Wrench 13-3 (JM23100197), Dust Bag (JM23510010), Vertical Vise (JM23510009),
Triangle Rule (JM27000328),Two Holders (JM23000127)
Up To 12˝ Cuts In 2x Material
• Electric brake for increased operator safety
• Soft start feature gradually increases speed to eliminate start up shock
• LED job light illuminates cutting area for increased accuracy and precision
• Factory calibrated class II laser enables accurate alignment of blade and cutting line
• Bevel Capacity of 48° left or 5° right
• Mitre Capacity of 50° left or 60° right with positive stops at 0°, 15°, 22.5°, 31.6° and 45°
• 2 stage safety switch for increased operator safety
8-1/2
"
Sliding Compound Mitre Saw with Laser and LED Light
SPECIFICATIONS
Blade Diameter
8-1/2" (216 mm)
Arbor
5/8" (15.88 mm)
No Load Speed
5,000 RPM
AMPS (120V)
13.0 A
Overall Dimensions (L x W x H)
29-1/2" x 17-3/4" x 19"
(750 mm x 450 mm x 483 mm)
Net Weight
31.1 lbs (14.1 kg)
LS0815FL
High Cutting Capacity And Dust Extraction Rate
Electric
Power Tools
makita.ca
87
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
10" C.T. Blade 40T (JM23000176), Box Wrench 13-3 (JM23100197), Dust Bag (JM23100501), Vertical Vise (JM23100502),
Triangle Rule (JM27000328),Two Holders (322312-4)
Affordable, Professional Quality
• Sliding Rail Mechanism incorporating 3 Linear Ball Bearings provides increased rigidity to produce
precise, adjustment free cuts right out of the box
• Sliding Fence (Left Side) can be adjusted outwards when bevel cutting or inwards for increased support
of small or delicate materials
• Soft Start feature gradually increases speed to eliminate start up shock
• Battery Operated, Factory Calibrated Class II Laser enables accurate alignment of blade and cutting line
• Bevel Capacity of 45° Left or 5° Right
• Mitre Capacity of 47° Left or 60° Right with Positive Stops at 0°, 15°, 22.5°, 31.6° & 45°
10
"
Sliding Compound Mitre Saw with Laser
SPECIFICATIONS
Blade Diameter
10" (255 mm)
Arbor
5/8" (15.88 mm)
No Load Speed
4,200 RPM
AMPS (120V)
13.0 A
Overall Dimensions (L x W x H)
32-1/2" x 21-1/8" x 22-7/8"
(825 mm x 536 mm x 581 mm)
Net Weight
42.8 lbs (19.4 kg)
LS1017L
Affordable, Professional Quality
STANDARD EQUIPMENT INCLUDES:
14" Blade 70T (792699-2), Socket Wrench 13 (782212-4), Dust Bag (122330-0),Two Safety Switch Buttons (411478-6),
Horizontal Vise (122563-7)
Makita’s Largest Mitre Saw
• 2 Stage Safety Switch for increased operator safety
• Mitre Capacity of 45° Left or Right with Positive Stops at 0°, 15°, 22.5°, 30° and 45°
14" Mitre Saw
SPECIFICATIONS
Blade Diameter
14" (355 mm)
Arbor
1" (25.4 mm)
No Load Speed
3,200 RPM
AMPS (120V)
12.0 A
Overall Dimensions (L x W x H)
24" x 21" x 17-1/4"
(610 mm x 530 mm x 440 mm)
Net Weight
75.4 lbs (34.2 kg)
LS1440
STANDARD EQUIPMENT INCLUDES:
12" C.T. Blade 60T, Hex Wrench 6 (781044-6), Dust Bag (122852-0),Triangular Rule (762001-3), Vertical Vise (122540-9),
Two Holders (323726-0), Wrench Holder 5.6 (410047-0)
• Electric Brake for increased operator safety
• 2 Stage Safety Switch for increased operator safety
• Bevel Capacity of 45° Left
• Mitre Capacity of 45° Left or Right with Positive Stops at 0°, 15°, 22.5°, 31.6° and 45°
• Pivoting Fence (Left Side) can be adjusted when bevel cutting or to support larger materials
12" Compound Mitre Saw
SPECIFICATIONS
Blade Diameter
12" (305 mm)
Arbor
1" (25.4 mm)
No Load Speed
4,000 RPM
AMPS (120V)
15.0 A
Overall Dimensions (L x W x H)
26-1/2" x 24" x 23-7/8"
(674 mm x 610 mm x 607 mm)
Net Weight
37.0 lbs (16.8 kg)
LS1221
When
QUALITY&SERVICE
Counts – ChooseMakita
STANDARD EQUIPMENT INCLUDES:
7-1/2" C.T. Blade 40T (A-90629), Hex Wrench 5 (783203-8),Triangle rule (762001-3), Dust Box (194175-6),
Two Safety Switch Button (411478-6), Vertical Vise (122571-8),Two Holders (322312-4)
Ideal For Trim And Flooring Applications
• Sliding Rail Mechanism incorporating 4 Linear Ball Bearings provides increased rigidity to produce
precise, adjustment free cuts right out of the box
• Electric Brake for increased operator safety
• Mitre Capacity of 47° Left or 57° Right with Positive Stops at 0°, 15°, 22.5°, 30° & 45°
• Bevel Capacity of 45° Left or 5° Right
• Includes Cyclonic Mitre Saw Dust Box for improved dust collection
7-1/2" Dual Sliding Compound Mitre Saw and Cyclonic Mitre Saw Dust Box
SPECIFICATIONS
Blade Diameter
7-1/2˝ (190 mm)
Arbor
5/8˝ (15.88 mm)
No Load Speed
6,000 RPM
AMPS (120V)
10.0 A
Overall Dimensions (L x W x H)
17˝ x 26-3/8˝ x 18˝
(430 mm x 670 mm x 458 mm)
Net Weight
28.9 lbs (13.1 kg)
LS0714B
STANDARD EQUIPMENT INCLUDES:
7-1/2" C.T. Blade 40T (A-90629), Hex Wrench 5 (783203-8),Triangle rule (762001-3), Dust Bag (122852-0),
Two Safety Switch Button (411478-6), Vertical Vise (122571-8),Two Holders (322312-4)
Ideal For Trim And Flooring Applications
• Sliding Rail Mechanism incorporating 4 Linear Ball Bearings provides increased rigidity to produce
precise, adjustment free cuts right out of the box
• Electric Brake for increased operator safety
• Mitre Capacity of 47° Left or 57° Right with Positive Stops at 0°, 15°, 22.5°, 30° & 45°
• Bevel Capacity of 45° Left or 5° Right
7-1/2" Dual Sliding Compound Mitre Saw
SPECIFICATIONS
Blade Diameter
7-1/2˝ (190 mm)
Arbor
5/8˝ (15.88 mm)
No Load Speed
6,000 RPM
AMPS (120V)
10.0 A
Overall Dimensions (L x W x H)
17˝ x 26-3/8˝ x 18˝
(430 mm x 670 mm x 458 mm)
Net Weight
28.9 lbs (13.1 kg)
LS0714
