90 / 220
BENCHTOP
makita.ca
88
STANDARD EQUIPMENT INCLUDES:
12" Double Edged HSS Planer Blades (793346-8),
Two Magnetic Holder (762014-4), Socket Wrench 9 (782203-5), Hex Wrench 2.5 (783208-8), Key (415715-0A), PlasticTool Box (824002-0)
Fastest And Easiest Blade Change On The Market
• 4-Post design with Diagonal Cross Supports provide maximum operational stability
• Interna-Lok Automated Head Clamp Feed Mechanism ensures smooth finishes with minimal snipe
• Indicator Lamp indicates active power supply
• Large Support Table for maximum material support
• Fold Away Depth Adjustment Handle for compact transport and storage
• Flat Top Design facilitates repetitive cutting operations
• On-Board, Detachable Tool Box for operator convenience
12" Thickness Planer
SPECIFICATIONS
Cutting Capacities:
Width
12" (304 mm)
Depth
1/8" (3 mm)
Thickness
6-3/32" (155 mm)
Feed Rate Per Minute
27.9' (8.5 m)
No Load Speed
8,500 RPM
AMPS (120V)
15.0 A
Table Size (W x L)
12" x 30-3/8"
(304 mm x 771 mm)
Overall Dimensions (L x W x H)
19" x 15-13/16" x 30-3/8"
(483 mm x 401 mm x 771 mm)
Net Weight
61.9 lbs (28.1 kg)
2012NB
Makita offers a wide variety of
ACCESSORIES!
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
10" C.T. Blade 32T (721434-1), Socket Wrench 13 (782212-4), Dust Bag (122852-0), Vertical Vise (122536-0),Triangle Rule (762001-3),
Two Safety Switch Buttons (411478-6), Sub PlateAssy (193471-9)
• Electric Brake for increased operator safety
• 2 Stage Safety Switch for increased operator safety
• Bevel Capacity of 45° Left
• Mitre Capacity of 45° Left or 52° Right with Positive Stops at 0°, 15°, 22.5°, 30° and 45°
• Pivoting Fence (Left Side) can be adjusted when bevel cutting or to support larger materials
10" Compound Mitre Saw
SPECIFICATIONS
Blade Diameter
10" (255 mm)
Arbor
5/8" (15.9 mm)
No Load Speed
4,600 RPM
AMPS (120V)
15.0 A
Overall Dimensions (L x W x H)
20-7/8" x 18-3/4" x 21"
(530 mm x 476 mm x 532 mm)
Net Weight
27.3 lbs (12.4 kg)
LS1040
Enhanced Safety Features For Improved Operator Safety
• Quick Release Blade Guard is easily accessible and provides clear line of sight to blade
• Adjustable Riving Knife prevents material pinching behind blade eliminating risk of material kickback
• Electric Brake for operator safety
• Aluminum Diecast Precision Machined Table remains flat and true for out of the box accuracy
• Smooth Operating Guide Rail with larger Locking Lever and Lock Mechanism for quick and easy setup
• Large cutting capacity (3-9/16˝ at 90° and 2-1/2˝ at 45°) allows cutting 4x material in a single pass
• Bevel Capacity of -0.5° to 45.5°
• Maximum 25˝ Rip Capacity
• Large On / Off Paddle Switch for easy access during operation.
SPECIFICATIONS
Blade Diameter
10" (255 mm)
Arbor
5/8" (15.9 mm)
Maximum Cutting Capacities:
90°
3-9/16" (91 mm)
45°
2-1/2" (63 mm)
Maximum Dado Capacity
6" x 13/16" (152 mm x 21 mm)
No Load Speed
4,800 RPM
AMPS (120V)
15.0 A
Table Size (L x W)
26-3/4" x 30-1/4" (678 mm x 766 mm)
Net Weight
65.5 lbs (29.7 kg)
10" Table Saw
2705
STANDARD EQUIPMENT INCLUDES:
10" C.T. Blade 32T (A-94948), Push Stick (416772-1), Wrench 19 (781038-1), Wrench 13-22 (782024-5), Hex Wrench 5 (783224-0),Adapter Ring 1˝ x 5/8˝ (257060-5),Angle Rule (122838-4), RulerAssembly (122740-1), Center Cover (126901-5)
Riving Knife,
Electric Brake
Enhanced Safety Features For Improved Operator Safety
• Quick Release Blade Guard is easily accessible and provides clear line of sight to blade
• Adjustable Riving Knife prevents material pinching behind blade eliminating risk of material kickback
• Electric Brake for operator safety
• Aluminum Diecast Precision Machined Table remains flat and true for out of the box accuracy
• Smooth Operating Guide Rail with larger Locking Lever and Lock Mechanism for quick and easy setup
• Large cutting capacity (3-9/16˝ at 90° and 2-1/2˝ at 45°) allows cutting 4x material in a single pass
• Bevel Capacity of -0.5° to 45.5°
• Maximum 25˝ Rip Capacity
• Large On / Off Paddle Switch for easy access during operation.
SPECIFICATIONS
Blade Diameter
10" (255 mm)
Arbor
5/8" (15.9 mm)
Maximum Cutting Capacities:
90°
3-9/16" (91 mm)
45°
2-1/2" (63 mm)
Maximum Dado Capacity
6" x 13/16" (152 mm x 21 mm)
No Load Speed
4,800 RPM
AMPS (120V)
15.0 A
Table Size (L x W)
26-3/4" x 30-1/4" (678 mm x 766 mm)
Net Weight
65.5 lbs (29.7 kg)
10" Table Saw With Stand
2705X1
STANDARD EQUIPMENT INCLUDES:
10" C.T. Blade 32T (A-94948), Push Stick (416772-1),
Wrench 19 (781038-1), Wrench 13-22 (782024-5),
Hex Wrench 5 (783224-0),Adapter Ring 1˝ x 5/8˝ (257060-5),
Angle Rule (122838-4), RulerAssembly (122740-1),
Center Cover (126901-5),Table Saw Stand (194093-8)
Riving Knife,
Riving Knife,
Electric Brake
