BENCHTOP
makita.ca
48
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Up To 15˝ Cuts In 2x Material, 8˝ Nested Crown Moulding & 6-1/2˝ Vertical Baseboard
Class Leading Cutting Capacity
• Dual Sliding Rail Mechanism incorporating 6 Linear Ball Bearings provides increased
rigidity to produce precise, adjustment free cuts right out of the box
• Electronic Speed Control maintains constant speed under heavy load
• Soft Start feature gradually increases speed to eliminate start up shock
• 3 Stage Gear Reduction System greatly increases capacity when cutting vertical
baseboard or nested crown molding
Incorporates Makita's Deep And Exact Cutting Technology (DXT)
SPECIFICATIONS
Blade Diameter
12˝ (305 mm)
Arbor
1˝ (25.4 mm)
No Load Speed
3,200 RPM
AMPS (120V)
15.0 A
Overall Dimensions (L x W x H)
31-3/4˝x 25-1/4˝x 28-3/8˝
(806 mm x 640 mm x 721 mm)
Net Weight
58.6 lbs. (26.6 kg)
LS1216, LS1216L, LS1216X, LS1216X3, LS1216LX, LS1216LX4
12˝ Dual Sliding Compound Mitre Saws
STANDARD EQUIPMENT INCLUDES:
12˝ C.T. Blade 60T(A-93712), Box Wrench (782232-8), Dust Bag (122852-0), 2 Ea. Switch Safety Buttons (451037-4), Vertical Vise
(122854-6),Triangle Rule (762001-3), 2 Ea. Holder (325673-1)
LS1216
Up To 12˝ Cuts In 2x Material, 6-5/8˝ Nested Crown Moulding & 4-3/4˝ Vertical Baseboard
Class Leading Cutting Capacity
• Dual Sliding Rail Mechanism incorporating 6 Linear Ball Bearings provides increased
rigidity to produce precise, adjustment free cuts right out of the box
• Electronic Speed Control maintains constant speed under heavy load
• Soft Start feature gradually increases speed to eliminate start up shock
• 3 Stage Gear Reduction System greatly increases capacity when cutting vertical
baseboard or nested crown molding
Incorporates Makita's Deep And Exact Cutting Technology (DXT)
SPECIFICATIONS
Blade Diameter
10˝ (255 mm)
Arbor
5/8˝ (15.9 mm)
No Load Speed
3,200 RPM
AMPS (120V)
15.0 A
Overall Dimensions (L x W x H)
28-1/4˝ x 25-1/4˝ x 26-1/2˝
(718 mm x 640 mm x 671 mm)
Net Weight
53.1 lbs. (24.1 kg)
LS1016, LS1016L, LS1016X, LS1016X6, LS1016LX, LS1016LX5
10˝ Dual Sliding Compound Mitre Saws
STANDARD EQUIPMENT INCLUDES:
10˝ C.T. Blade 60T(A-93675), Box Wrench (782232-8), Dust Bag (122852-0), Vertical Vise (122854-6),Triangle Rule (762001-3),
2 Ea. Holder (325673-1)
LS1016
Affordable, Professional Quality
• Sliding Rail Mechanism incorporating 3 Linear Ball Bearings provides increased
rigidity to produce precise, adjustment free cuts right out of the box
• Sliding Fence (Left Side) can be adjusted outwards when bevel cutting or inwards for
increased support of small or delicate materials
• Soft Start feature gradually increases speed to eliminate start up shock
• Battery Operated, Factory Calibrated Class II Laser enables accurate alignment of blade
and cutting line
• Bevel Capacity of 45° Left or Right
• Mitre Capacity of 47° Left or 60° Right with Positive Stops at 0°, 15°, 22.5°, 31.6° & 45°
• Re-Located Mitre Scale enables easier viewing during operation
SPECIFICATIONS
Blade Diameter
10˝ (255 mm)
Arbor
5/8˝ (15.9 mm)
No Load Speed
4,300 RPM
AMPS (120V)
13.0 A
Overall Dimensions (L x W x H)
32-1/2˝ x 21-1/8˝ x 25˝
(825 mm x 536 mm x 633 mm)
Net Weight
43.7 lbs (19.8 kg)
LS1018L, LS1018LX, LS1018LX3
10˝ Dual Sliding Compound Mitre Saws
STANDARD EQUIPMENT INCLUDES:
10˝ C.T. Blade 40T(JM23000176), Box Wrench (JM23100197), Dust Bag (JM23100501), Vertical Vise (JM23100502),
Triangle Rule (JM27000328), 2 Ea. Holder (322312-4)
LS1018L
Affordable, Professional Quality
• Sliding Rail Mechanism incorporating 3 Linear Ball Bearings provides increased
rigidity to produce precise, adjustment free cuts right out of the box
• Sliding Fence (Left Side) can be adjusted outwards when bevel cutting or inwards
for increased support of small or delicate materials
• Soft Start feature gradually increases speed to eliminate start up shock
• Battery Operated, Factory Calibrated Class II Laser enables accurate alignment
of blade and cutting line
• Bevel Capacity of 45° Left or 5° Right
• Mitre Capacity of 47° Left or 60° Right with Positive Stops at 0°, 15°, 22.5°, 31.6° & 45°
• Re-Located Mitre Scale enables easier viewing during operation
SPECIFICATIONS
Blade Diameter
10˝ (255 mm)
Arbor
5/8˝ (15.9 mm)
No Load Speed
4,200 RPM
AMPS (120V)
13.0 A
Overall Dimensions (L x W x H)
32-1/2˝ x 22-7/8˝ x 21-1/8˝
(536 mm x 825 mm x 581 mm)
Net Weight
42.8 lbs (19.4 kg)
LS1017L, LS1017LX, LS1017LX2
10˝ Dual Sliding Compound Mitre Saws
STANDARD EQUIPMENT INCLUDES:
10˝ C.T. Blade 40T(JM23000176), Box Wrench (JM23100197), Dust Bag (JM23100501), Vertical Vise (JM23100502),
Triangle Rule (JM27000328), 2 Ea. Holder (322312-4)
LS1017L
