SAWS
makita.ca
56
STANDARD EQUIPMENT INCLUDES:
1 Ea.7-1/4" Blade 24T, Wrench 13 (782016-4)
Makita's Best Selling Circular Saw
• Heavy Duty Aluminum Base Plate for jobsite durability
• Well Balanced design for better control from above or behind the saw
• Bevel Capacity of 45°
AC/DC
Cutting Capacity Of 2-3/8˝ (60 mm)
7-1/4˝ Circular Saw
SPECIFICATIONS
Blade Diameter
7-1/4˝ (185 mm)
Arbor
5/8˝ (15.9 mm)
Maximum Cutting Capacities:
90°
2-3/8˝ (60 mm)
45°
1-3/4˝ (46 mm)
No Load Speed
5,800 RPM
AMPS (120V)
15.0 A
Overall Length
11-5/8˝ (295 mm)
Net Weight
10.9 lbs. (4.9 kg)
5007NB
STANDARD EQUIPMENT INCLUDES:
1 Ea. 7-1/4” Blade 24T, Hex Wrench (783203-8), Wrench Holder (410047-0), Guide Rule (164095-8)
High Power To Weight Ratio
• Heavy Duty Aluminum Baseplate for durability
• Well Balanced design for better control from above or behind the saw
• Bevel Capacity of 45°
Cutting Capacity Of 2-1/2˝ (63.5 mm)
7-1/4˝ Circular Saw
SPECIFICATIONS
Blade Diameter
7-1/4˝ (185 mm)
Arbor
5/8˝ (15.9 mm)
Maximum Cutting Capacities:
90°
2-1/2˝ (64 mm)
45°
1-5/8˝ (42 mm)
No Load Speed
4,700 RPM
AMPS (120V)
10.5 A
Overall Length
11-3/4˝ (298 mm)
Net Weight
7.9 lbs. (3.6 kg)
5740NB
STANDARD EQUIPMENT INCLUDES:
7-1/4˝ C.T. Blade 28T(A-90451), Offset Wrench (782016-4), Guide Rule (164095-8)
For Cutting Fibre-Cement Materials
• Dust Collection Container captures waste for a clean work environment
• Dust Proof Structure prevents contamination of motor
• Aluminum Baseplate for increased stability
• Guard Lever enables guard to be retracted for easier plunge cutting applications
Dust Collector
7-1/4˝ Circular Saw
SPECIFICATIONS
Blade Diameter
7-1/4˝ (185 mm)
Arbor
5/8˝ (15.9 mm)
Maximum Cutting Capacities:
0°
2-3/8˝ (60 mm)
45°
1-1/8˝ (30 mm)
No Load Speed
5,800 RPM
AMPS (120V)
13.0 A
Overall Length
14˝ (354 mm)
Net Weight
11.9 lbs. (5.4 kg)
5057KB
STANDARD EQUIPMENT INCLUDES:
5-1/2˝ Blade 50T(792334-2), Socket Wrench (782209-3), Guide Rule (164095-8)
Lightweight Design For Increased Maneuverability
• Electric Brake for operator safety
• Lock-Off Button prevents accidental start-up for increased operator safety
• Rugged Steel Base for improved operational stability
Blade Left
5-1/2˝ Circular Saw
SPECIFICATIONS
Blade Diameter
5-1/2˝ (140 mm)
Arbor
5/8˝ (15.9 mm)
Maximum Cutting Capacities:
0°
1-3/4˝ (45 mm)
45°
1-3/16˝ (31 mm)
No Load Speed
8,000 RPM
AMPS (120V)
8.0 A
Overall Length
9-13/16˝ (249 mm)
Net Weight
6.2 lbs. (2.8 kg)
5005BA
STANDARD EQUIPMENT INCLUDES:
1 Ea. 7-1/4" Blade 24T, Hex Wrench 6 (783204-6)
Hypoid Gear System Provides Increased Power Transmission
• Ideal for Framers, Home Builders, Masons, and Contractors
• High quality, Hardened Steel Hypoid Gears do not wear like bronze-alloy worm drive gears
• Bevel Capacity of 51.5° with Positive Stops at 45° and 51.5° ideal for cutting trusses and rafters
• Ergonomic Soft Rubber Rear Grip design for vibration absorption and comfortable operation
Cutting Capacity Of 2-3/8˝ (60 mm)
7-1/4˝ Hypoid Saw
SPECIFICATIONS
Blade Diameter
7-1/4˝ (185 mm)
Arbor
5/8˝ (15.9 mm)
Maximum Cutting Capacities:
0°
2-3/8˝ (60 mm)
45°
1-3/4˝ (44 mm)
50°
1-9/16˝ (40 mm)
No Load Speed
4,500 RPM
AMPS (120V)
15.0 A
Overall Length
17-3/8˝ (442 mm)
Net Weight
14.3 lbs. (6.5 kg)
5477NB
STANDARD EQUIPMENT INCLUDES:
1 Pc. 7-1/4˝ Blade 24CT(A-94530-10), Hex Wrench (783204-6)
Hypoid Gear System Provides Increased Power Transmission
• Ideal for Framers, Home Builders, Masons, and Contractors
• High quality, Hardened Steel Hypoid Gears do not wear like bronze-alloy worm drive gears
• High Performance Magnesium Base Plate, Blade Case and Motor Housing
• Bevel Capacity of 51.5° with Positive Stops at 22.5°, 45° and 51.5° ideal for cutting trusses and rafters
• Rafter Hook enables convenient storage on 2x materials when not in use
• Ergonomic Soft Rubber Top and Rear Grip design for vibration absorption and comfortable operation
Cutting Capacity Of 2-3/8˝ (60 mm)
7-1/4˝ Hypoid Saw
SPECIFICATIONS
Blade Diameter
7-1/4˝ (185 mm)
Arbor
5/8˝ (15.9 mm)
Maximum Cutting Capacity:
0°
2-3/8˝ (60 mm)
45°
1-3/4˝ (44 mm)
50°
1-9/16˝ (40 mm)
No Load Speed
4,500 RPM
AMPS (120V)
15.0 A
Overall Length
17-3/4˝ (450 mm)
Net Weight
13.2 lbs. (6.0 kg)
5377MG
