MITRE SAW WORK STATION – 194943-7
MITRE SAW WORK STATION – WST05
Maximum
support
height 36-1/2˝
Electric
Power Tools
makita.ca
51
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
12˝ Double Edged HSS Planer Blades (793346-8), 2 Ea. Magnetic Holder (762014-4), Socket Wrench (782203-5), Hex Wrench (783208-8),
Key (415715-0A)
Fastest And Easiest Blade Change On The Market
• 4-Post design with Diagonal Cross Supports provide maximum operational stability
• Interna-Lok Automated Head Clamp Feed Mechanism ensures smooth finishes with minimal snipe
• Indicator Lamp indicates active power supply
• Large Support Table for maximum material support
• Fold Away Depth Adjustment Handle for compact transport and storage
• Flat Top Design facilitates repetitive cutting operations
• On-Board, Detachable Tool Box for operator convenience
12˝ Thickness Planer
SPECIFICATIONS
Cutting Capacities:
Width
12˝ (304 mm)
Depth
1/8˝ (3 mm)
Thickness
6-3/32˝ (155 mm)
Feed Rate Per Minute
27.9' (8.5 m)
No Load Speed
8,500 RPM
AMPS (120V)
15.0 A
Table Size (W x L)
12˝ x 30-3/8˝
(304 mm x 771 mm)
Overall Dimensions (W x H x L)
19˝ x 15-13/16˝ x 30-3/8˝
(483 mm x 401 mm x 771 mm)
Net Weight
61.9 lbs. (28.1 kg)
2012NB
STANDARD EQUIPMENT INCLUDES:
2705X1:
10˝ C.T.Blade32T(A-94948),PushStick(416772-1),Wrench19(781038-1),Wrench13-22(782024-5),HexWrench5(783224-0),
Adaptor Ring 1˝ x 5/8˝ (257060-5),Angle Rule (122838-4), RulerAssembly (122740-1), Center Cover (125279-3),Table Saw Stand (194093-8)
2705:
10˝ C.T. Blade 32T(A-94948), Push Stick (416772-1), Wrench 19 (781038-1), Wrench 13-22 (782024-5),
Hex Wrench 5 (783224-0),Adaptor Ring 1" x 5/8" (257060-5),Angle Rule (122838-4), RulerAssembly (122740-1), Center Cover (125279-3)
Enhanced Safety Features For Improved Operator Safety
• Quick Release Blade Guard is easily accessible and provides clear line of sight to blade
• Adjustable Riving Knife prevents material pinching behind blade eliminating risk of material kickback
• Electric Brake for operator safety
• Aluminum Diecast Precision Machined Table remains flat and true for out of the box accuracy
• Smooth Operating Guide Rail with larger Locking Lever and Lock Mechanism for quick and easy setup
• Large cutting capacity (3-9/16˝ at 90° and 2-1/2˝ at 45°) allows cutting 4x material in a single pass
• Bevel Capacity of -0.5° to 45.5°
10˝ Table Saw & Table Saw with Stand
SPECIFICATIONS
Blade Diameter
10˝ (255 mm)
Arbor
5/8˝ (15.9 mm)
Maximum Cutting Capacities:
90°
3-9/16˝ (91 mm)
45°
2-1/2˝ (63 mm)
Maximum Dado Capacity
6˝ x 13/16˝ (152 mm x 21 mm)
No Load Speed
4,800 RPM
AMPS (120V)
15.0 A
Table Size (L x W)
26-3/4˝ x 30-1/4˝
(678 mm x 766 mm)
Net Weight
65.5 lbs (29.7 kg)
2705X1
2705
Riving Knife, Electric Brake
Maximum support width 113˝
Maximum
support
height 40˝
Heavy duty wheels
Tread kickers for
easy transportation
Tubular aluminum construction
• Collapsible Stand with Gravity Rise Feature
• Easy Storage and Transportation
• Adjustable Roller
and Support
Extensions Included
5 ADJUSTABLE
HEIGHT POSITIONS:
LEVEL FIVE: 33˝
LEVEL FOUR: 31-1/4˝
LEVEL THREE: 29-7/8˝
LEVEL TWO: 27-3/4˝
LEVEL ONE: 26˝
Fits All Makita Mitre Saws!
Maximum support width 106-1/2
˝
• Collapsible Mitre Saw Stand
• 2 Adjustable Height
Positions
• Tool less Benchtop
Tool Removal
• Adjustable Roller and
Support Extensions
Included
• Lightweight Design
2 ADJUSTABLE
HEIGHT POSITIONS:
LEVEL TWO: 31-1/2˝
LEVEL ONE: 21-5/8˝
Tool-less benchtop tool removal
Tubular aluminum construction
