STANDARD EQUIPMENT INCLUDES:
5˝ Continuous Rim Diamond Wheel (A-90934), Hex Wrench 5 (783203-8), Wrench 22 (781011-1), Water Supply Plug (165263-6),
Pressure Regulator (165264-4)
Ideal For Wet Cutting Of Tile, Masonry, Concrete And More
• Special Cover Design prevents water from entering motor housing
• Equipped with a Ground Fault Circuit Interrupter (GFCI) plug for operator safety
• Lock-On Button for easy continuous operation
• Bevel Capacity of 45°
• Includes 15 ft. of Tubing, Water Pressure Regulator and Water Valve
Blade Left
5˝ Masonry Saw
SPECIFICATIONS
Blade Diameter
5˝ (125 mm)
Arbor
3/4˝ (20 mm)
Maximum Cutting Capacities:
0°
1-5/8˝ (41.5 mm)
45°
1˝ (26 mm)
No Load Speed
12,000 RPM
AMPS (120V)
7.9 A
Overall Length
9-1/4˝ (236 mm)
Net Weight
6.5 lbs. (3.0 kg)
4101RH
STANDARD EQUIPMENT INCLUDES:
4˝Turbo Rim Diamond Blade (A-94546), Wrench 22 (781011-1), Socket Wrench 9 (782209-3)
Dry Cutting Masonry Saw For Stone, Masonry, Tile, Concrete And More
• Heavy Duty Aluminum Gear Housing for increased durability
• 14ga Steel Baseplate ensures accuracy and durability
• Leading Edge of Baseplate indicates precise line of cut
• Lock-Off Button prevents accidental startup for operator safety
• Dust Proof Switch prevents contamination of motor
• Flat Motor Housing allows tool to stand upright when changing blades
Blade Left
4-3/8˝ Masonry Saw
SPECIFICATIONS
Blade Diameter Maximum 4-3/8˝ (110 mm)
Arbor
3/4˝ (20 mm)
Maximum Cutting Capacity
0°
1-3/8˝ (34 mm)
No Load Speed
13,000 RPM
AMPS (120V)
9.6 A
Overall Length
9-1/4˝ (234 mm)
Net Weight
6.4 lbs (2.9 kg)
4100NH
STANDARD EQUIPMENT INCLUDES:
4"Turbo Rim Diamond Blade (A-94546), 4-3/8" Curved Diamond Blade (D-36968), Wrench 22 (781011-1), Hex. Wrench 5 (783203-8)
Dry Cutting Masonry Saw For Stone, Masonry, Tile, Concrete And More
• Wide Blade Case enables use of Curved Diamond Wheel
• Heavy Duty Aluminum Gear Housing for increased durability
• 14 ga Steel Baseplate ensures accuracy and durability
• Leading Edge of Baseplate indicates precise line of cut
• Dust Proof Switch and Labyrinth Construction prevents contamination of motor
• Flat Motor Housing allows tool to stand upright when changing blades
• Bevel Capacity of 45˚
4-3/8˝ Masonry Saw
SPECIFICATIONS
Blade Diameter
Maximum 5˝ (120 mm)
Arbor
3/4˝ (20 mm)
Maximum Cutting Capacities:
0°
1-1/4˝ (32.5 mm)
45°
7/8˝ (21.5 mm)
No Load Speed
12,000 RPM
AMPS (120V)
10.0 A
Overall Length
9-3/8˝ (238 mm)
Net Weight
6.6 lbs (3.0 kg)
4100NH2ZX1
Blade Left
Unique Plunge Action For Specialized Cuts
• Depth Stopper enables splinter-free cutting
• PrecisionBevelCutfeaturemaintainsexactbladepositionforquickandeasybevelcutting
withoutcompensatingadjustments
• Soft Start feature gradually increases speed to eliminate start up shock
• Constant Speed Control maintains constant speed under heavy load
• Overload Protection prevents motor burnout due to current overload
• Variable Speed Dial adjusts cutting speed based on materials or application
• Close to Wall Cut of just 11/16˝
SPECIFICATIONS
Blade Diameter
6-1/2˝ (165 mm)
Arbor
13/16˝ (20 mm)
Maximum Cutting Capacity:
0°
2-3/16˝ (56 mm)
45°
1-9/16˝ (39 mm)
48°
1-1/2˝ (38 mm)
No Load Speed
2,000 - 5,200 RPM
AMPS (120V)
12.0 A
Overall Length
13-3/8˝ (341 mm)
Net Weight
9.7 lbs. (4.4 kg)
55˝ Guide Rail
(139.7 cm)
STANDARD EQUIPMENT INCLUDES:
6-1/2˝ C.T. Blade 48T(B-07353),
Hex Wrench 5 (783203-8),
Vacuum HoseAdapter (P-80013),
55˝ (139.7 cm) Guide Rail (194368-5)
SP6000X1
STANDARD EQUIPMENT INCLUDES:
6-1/2˝ C.T. Blade 48T(B-07353),
Hex Wrench 5 (783203-8),
Vacuum HoseAdapter (P-80013),
118˝ (299.7 cm) Guide Rail (194367-7)
SP6000X2
118˝ Guide Rail
(299.7 cm)
+
STANDARD EQUIPMENT INCLUDES:
6-1/2˝ C.T. Blade 48T(B-07353), Hex Wrench 5 (783203-8),
Vacuum HoseAdapter (P-80013)
SP6000
+
+
SP6000, SP6000X1, SP6000X2
6-1/2
˝
Plunge Cut Circular Saws
