Electric
Power Tools
makita.ca
55
STANDARD EQUIPMENT INCLUDES:
16-5/16˝ C.T. Blade 32T(A-95093), Hex Wrench 6 (783204-6), Guide Rule (164019-4), Protective Stand Set (194701-1)
Large Capacity For Beam And Timber Cutting
• Powerful Motor delivers 1,800 max watts out
• Rugged Steel Base for for maximum stability
• Electric Brake for increased operator safety
• Blade Stabilizer for stable blade rotation and superior cutting performance
• Large Depth Control Lever for convenience and secure adjustments
Electric Brake
16-5/16˝ Circular Saw
SPECIFICATIONS
Blade Diameter
16-5/16˝ (415 mm)
Arbor
1˝ (25 mm)
Maximum Cutting Capacities:
0°
6-1/4˝ (158 mm)
45°
4-3/16˝ (106 mm)
No Load Speed
2,300 RPM
AMPS (120V)
15.0 A
Overall Length
24-1/4˝ (616 mm)
Net Weight
32.2 lbs. (14.6 kg)
5402NA
STANDARD EQUIPMENT INCLUDES:
10-1/4˝ C.T. Blade 24T(A-94910), Hex Wrench 6 (783204-6), Guide Rule (165499-7)
"SJS" Technology Prevents Kickback If Blade Jams, Protecting the
Operator And The Tool
• Electric Brake for increased operator safety
• Lock-Off Button prevents accidental start-up for operator safety
• Diecast Aluminum Base for maximum operational stability
• Compact Blade Case and reduced overall tool height for enhanced operational versatility
• Large Top Handle for easy carrying
• Flat Motor Housing for stability during blade changes
"SJS" Technology, Electric Brake
10-1/4˝ Circular Saw
SPECIFICATIONS
Blade Diameter
10-1/4˝ (260 mm)
Arbor
5/8˝ (15.9 mm)
Maximum Cutting Capacities:
0°
3-3/4˝ (95 mm)
45°
2-3/4˝ (69 mm)
No Load Speed
3,800 RPM
AMPS (120V)
15.0 A
Overall Length
16˝ (405 mm)
Net Weight
20.3 lbs. (9.2 kg)
5104
STANDARD EQUIPMENT INCLUDES:
8-1/4˝ C.T. Blade 24T(D-21521), Hex Wrench 6 (783204-6), Guide Rule (164095-8)
High Performance Magnesium Blade Case And Base
• Electric Brake for operator safety
• Dual LED Job Lights illuminate cut line
• Blower feature keeps cutting line free of sawdust
• Bevel Capacity of 50° with Positive Stops at 22.5°, 45°, and 50°
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Cutting Depth Capacity Of 3˝ (75.5 mm)
Electric Brake
8-1/4˝ Circular Saw
SPECIFICATIONS
Blade Diameter
8-1/4˝ (210 mm)
Arbor
5/8˝ (15.9 mm)
Maximum Cutting Capacities:
0°
3˝ (75.5 mm)
45°
2-1/4˝ (57 mm)
50°
2˝ (51.5 mm)
No Load Speed
5,200 RPM
AMPS (120V)
15.0 A
Overall Length
13-1/8˝ (332 mm)
Net Weight
11.2 lbs. (5.1 kg)
5008MGA
STANDARD EQUIPMENT INCLUDES:
5007MG:
1 Pc. 7-1/4˝ Blade 24T(A-94530-10), Hex Wrench 6 (783204-6), Guide Rule (164095-8), Plastic Carrying Case (158279-8)
5007MGA:
1 Pc. 7-1/4˝ Blade 24T(A-94530-10), Hex Wrench 6 (783204-6), Guide Rule (164095-8), Plastic Carrying Case (158279-8)
High Performance Magnesium Blade Case And Base
• Dual LED Job Lights illuminate cut line
• Blower feature keeps cutting line free of sawdust
• Bevel Capacity of 56° with Positive Stops at 22.5°, 45°, and 56°
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Cutting Capacity Of 2-1/2˝ (63.5 mm)
Electric Brake (5007MGA)
7-1/4˝ Circular Saw
SPECIFICATIONS
Blade Diameter
7-1/4˝ (185 mm)
Arbor
5/8˝ (15.9 mm)
Maximum Cutting Capacities:
0°
2-1/2˝ (63.5 mm)
45°
1-3/4˝ (45 mm)
56°
1-3/8˝ (35 mm)
No Load Speed
5,800 RPM
AMPS (120V)
15.0 A
Overall Length
12-1/2˝ (317 mm)
Net Weight
10.6 lbs. (4.8 kg)
5007MG
5007MGA
High Power To Weight Ratio
• Electric Brake for increased operator safety
• Heavy Duty Aluminum Base Plate for
jobsite durability
• LED Job Light with Independent On / Off Switch
• Flat Motor Housing provides stability during
blade changes
• Bevel Capacity of 45°
Cutting Capacity Of 2-3/8˝ (60 mm)
Electric Brake
7-1/4˝ Circular Saws
SPECIFICATIONS
Blade Diameter
7-1/4˝ (185 mm)
Arbor
5/8˝ (15.9 mm)
Maximum Cutting Capacities:
0°
2-3/8˝ ( 60 mm)
45°
1-3/4˝ (46 mm)
No Load Speed
5,800 RPM
AMPS (120V)
15.0 A
Overall Length
12˝ (305 mm)
Net Weight
11.1 lbs. (5.0 kg)
STANDARD EQUIPMENT INCLUDES:
1 Pc. 7-1/4˝ Blade 24T(A-94530-10),
Wrench 13 (782016-4), Guide Rule (164095-8),
Plastic Carrying Case (824473-1)
5007FAK
STANDARD EQUIPMENT
INCLUDES:
1 Pc. 7-1/4˝ Blade 24T
(A-94530-10),
Wrench 13 (782016-4)
5007FA
+
Plastic Carrying Case
High Power To Weight Ratio
• Heavy Duty Aluminum Base Plate for
jobsite durability
• LED Job Light with Independent On / Off Switch
• Flat Motor Housing provides stability during
blade changes
• Bevel Capacity of 45°
AC/DC
Cutting Capacity Of 2-3/8˝ (60 mm)
7-1/4˝ Circular Saws
SPECIFICATIONS
Blade Diameter
7-1/4˝ (185 mm)
Arbor
5/8˝ (15.9 mm)
Maximum Cutting Capacities:
0°
2-3/8˝ ( 60 mm)
45°
1-3/4˝ (46 mm)
No Load Speed
5,800 RPM
AMPS (120V)
15.0 A
Overall Length
12˝ (305 mm)
Net Weight
11.1 lbs. (5.0 kg)
STANDARD EQUIPMENT INCLUDES:
1Ea.7-1/4˝CircularSawBlade
24CT(A-94530-10),Wrench13(782016-4),
GuideRule(164095-8),PlasticCarryingCase(824473-1)
5007FK
STANDARD EQUIPMENT
INCLUDES:
7-1/4" Blade 24T,
Wrench 13 (782016-4)
5007F
+
Plastic Carrying Case
