Powered by
Two 18V Li-ion
Batteries!
LITHIUM-ION
makita.ca
4
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Grip (158057-6), Cleaning Cloth (443122-7), Bit Grease (194683-7)
Depth Gauge (324219-0), Quick Change Drill Chuck (194079-2)
Makita's FIRST 18VX2 Direct (36V) 1˝ Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
Features Quick Change Drill Chuck
• Accepts 2 x 18V Li-Ion batteries without a battery converter for use with existing 18V Li-Ion battery platform
• Center of gravity located close to rear handle resulting in ideal tool balance during operation
• Torque limiter stops rotation if bit jams for increased operator safety and enhanced motor protection
• 40 angle bit positions enable chisels to be positioned at optimum angle of operation
• Rubber housing bumper protects mode selector switch and gear housing from damage
• LED job light with afterglow feature
• One touch sliding chuck enables quick and
easy bit changes
1˝ Cordless Rotary Hammer
SPECIFICATIONS
Battery
Two 18V Li-Ion
Capacities:
Concrete
1˝ (26 mm)
Steel
1/2˝ (13 mm)
Wood
1-1/4˝ (32 mm)
No Load Speed
0 - 1,250 RPM
Blows Per Minute
0 - 5,000 BPM
Impact Energy
2.5 J (1.8 ft. lbs)
Overall Length
14-3/4˝ (374 mm)
Net Weight
7.7 lbs (3.5 kg)
DHR264Z
Variable Speed, Reversible
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Grip (158057-6), Cleaning Cloth (443122-7), Bit Grease (194683-7),
Depth Gauge (324219-0)
Makita's FIRST 18VX2 Direct (36V) 1˝ Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Accepts 2 x 18V Li-Ion batteries without a battery converter for use with existing 18V Li-Ion battery platform
• Center of gravity located close to rear handle resulting in ideal tool balance during operation
• Torque limiter stops rotation if bit jams for increased operator safety and enhanced motor protection
• 40 angle bit positions enable chisels to be positioned at optimum angle of operation
• Rubber housing bumper protects mode selector switch and gear housing from damage
• LED job light with afterglow feature
• One touch sliding chuck enables quick
and easy bit changes
• Sliding rear handle for increased vibration absorption
1˝ Cordless Rotary Hammer
SPECIFICATIONS
Battery
Two 18V Li-Ion
Capacities:
Concrete
1˝ (26 mm)
Steel
1/2˝ (13 mm)
Wood
1-1/4˝ (32 mm)
No Load Speed
0 - 1,250 RPM
Blows Per Minute
0 - 5,000 BPM
Impact Energy
2.5 J (1.8 ft. lbs)
Overall Length
13-3/4˝ (363 mm)
Net Weight
7.5 lbs (3.4 kg)
DHR263Z
Variable Speed, Reversible
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
7-1/4" Blade 24T(A-94530), Hex Wrench (783217-7), Guide Rule (164095-8)
Makita's FIRST 36V (18VX2 Direct) 7-1/4˝ Circular Saw!
• Offers the power of electric saws with the convenience and versatility of cordless saws!
• Electric brake stops blade 3-5 seconds after trigger is released for increased operator safety
• Large lock-off safety lever prevents accidental start up
• High performance and lightweight design with magnesium blade case and base plate
• Blower feature keeps cutting line free of sawdust
• Bevel capacity of 50° with positive stop at 45°
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
7-1/4˝ Cordless Circular Saw
SPECIFICATIONS
Battery
Two 18V Li-Ion
Blade Diameter
7-1/4˝ (185 mm)
Arbor
5/8˝ (15.88 mm)
Maximum Cutting Depth:
0°
2-5/8˝ (66 mm)
45°
1-7/8˝ (47,5 mm)
50°
1-11/16˝ (42,5 mm)
No Load Speed
4,800 RPM
Overall Length
14˝ (356 mm)
Net Weight
7.5 lbs (3.4 kg)
DHS711Z
Cutting Capacity of 2-5/8" (66 mm)
Tools with this symbol use
Two 18V Li-Ion Batteries
directly without a
battery converter
DHR263Z
DIRECT CONNECT SYSTEM
Quick Change Drill Chuck
194079-2
