LITHIUM-ION
makita.ca
14
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
1/2˝ (13 mm)
Steel
1/2˝ (13 mm)
Wood
1-1/2˝ (38 mm)
No Load Speed:
Low
0 - 400 RPM
High
0 - 1,550 RPM
Blows Per Minute:
Low
0 - 6,000 BPM
High
0 - 23,000 BPM
Maximum Lock Torque 530 in. lbs (60 Nm)
Overall Length
7-7/8˝ (199 mm)
Net Weight
3.4 lbs (1.5 kg)
DHP480RFE
DHP480Z
Hammer Driver Drills
STANDARD EQUIPMENT INCLUDES:
DHP480RFE:
Two18V(3.0Ah)Li-IonBatteries
BL1830(194205-3),
Charger(DC18RC),Hook(346449-3),DoubleEndedBit2-45(784637-8),
1/2"KeylessDrillChuck(766008-1),PlasticCarryingCase(821532-2)
DHP480Z:
ToolOnly.BatteriesandChargerSoldSeparately.
Hook(346449-3),
DoubleEndedBit2-45(784637-8),1/2"KeylessDrillChuck(766008-1)
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Steel
1/2˝ (13 mm)
Wood
1-1/2˝ (38 mm)
No Load Speed:
Low
0 - 400 RPM
High
0 - 1,550 RPM
Maximum Torque
530 in. lbs (60 Nm)
Overall Length
7-1/4˝ (185 mm)
Net Weight
3.8 lbs (1.7 kg)
DDF480RFE
DDF480Z
Driver Drills
STANDARD EQUIPMENT INCLUDES:
DDF480RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830
(194205-3), Charger (DC18RC), Hook (346449-3), Double Ended
Bit 2-45 (784637-8), 1/2" Keyless Drill Chuck (766008-1),
Plastic Carrying Case (821532-2)
DHP480Z:
ToolOnly.BatteriesandChargerSoldSeparately.
Hook (346449-3), Double Ended Bit 2-45 (784637-8),
1/2" Keyless Drill Chuck (766008-1)
Variable 2-Speed, Reversible
Features Brushless DC Motor
• Battery Protection System provides over-discharge,
temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• Battery fuel gauge indicates approximate remaining
battery power
• 16 clutch settings deliver up to 530 in. lbs. of torque
• All metal gears for more efficient power transmission
• Compact design (Only 7-7/8˝ Long)
• LED job light with afterglow feature
• Improved ergonomic soft rubber grip design for vibration
absorption and comfortable operation features
re-contoured rear grip portion and ribbed grip for
improved hold
DHP480RFE, DHP480Z, DDF480RFE, DDF480Z
1/2˝ Cordless Hammer / Driver Drills
PICTURED: DHP480RFE
Hammer Driver Drill
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
1/2˝ (13 mm)
Steel
1/2˝ (13 mm)
Wood
1-1/2˝ (38 mm)
No Load Speed:
Low
0 - 400 RPM
High
0 - 1,500 RPM
Blows Per Minute:
Low
0 - 6,000 BPM
High
0 - 22,500 BPM
Maximum Torque
480 in. lbs. (54 Nm)
Overall Length
8-1/8˝ (206 mm)
Net Weight
4.0 lbs. (1.8 kg)
DHP456RFE
DHP456SYE
DHP456Z
STANDARD EQUIPMENT INCLUDES:
DHP456RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RC), Hook (346449-3), Double Ended Bit 2-45
(784637-8), 1/2˝ Keyless Drill Chuck (766008-1), Plastic Carrying Case (824812-5)
DHP456SYE:
Two 18V (Compact) Li-Ion Batteries
BL1815N (196235-0), Charger (DC18SD), Hook (346449-3), Double Ended Bit 2-45
(784637-8), 1/2˝ Keyless Drill Chuck (766008-1), Plastic Carrying Case (824812-5)
DHP456Z:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3), Double Ended Bit 2-45 (784637-8)
1/2" Keyless Drill Chuck (766008-1)
DHP456RFE, DHP456SYE, DHP456Z
1/2˝ Cordless Hammer Driver Drills
Variable 2-Speed,
Reversible
Incorporates Makita's Battery
Protection System, High Power
And Ultra-Compact Design
• Battery Protection System provides Over-Discharge,
Temperature and Current Protection for enhanced performance,
battery cycle life and overall battery life
• 16 Clutch Settings deliver up to 480 in. lbs. of torque
• All Metal Gears for more efficient power transmission
• Ultra-Compact Design (Only 8-1/8
˝
Long)
• LED Job Light with Afterglow feature
• Improved Ergonomic Soft Rubber Grip for vibration
absorption and comfortable operation features
re-contoured rear grip portion and ribbed grip for
improved hold
PICTURED: DHP456RFE
Hammer Driver Drill
Features 3 Speed RPM Range
• 16 Clutch Settings deliver up to
560 in. lbs. of torque
• Three Speed Gearing for more efficiency
• Dual LED Lights with Afterglow feature
• Shift-Lock drive converts from Hammer
to Drill to Driver mode
• All Metal Gears for more efficient
power transmission
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Steel
1/2˝ (13 mm)
Masonry
5/8˝ (15.8 mm)
Wood
2 - 9/16˝ (65mm)
No Load Speed: 1st Speed 0 - 300 RPM
2nd Speed
0 - 600 RPM
3rd Speed
0 - 1,700 RPM
Blows Per Minute: 1st Speed 0 - 4,500 BPM
2nd Speed
0 - 9,000 BPM
3rd Speed
0 - 25,500 BPM
Maximum Torque 560 in. lbs. (63 Nm)
Overall Length
9 - 7/8˝ (250 mm)
Net Weight
5.5 lbs. (2.5 kg)
DHP451RFE
DHP451Z
Hammer Driver Drills
STANDARD EQUIPMENT INCLUDES:
DHP451RFE:
Two18V(3.0Ah)Li-IonBatteries
BL1830(194205-3),Charger(DC18RC),
Grip(122750-8),2Ea.DoubleEndedBits2-45(784637-8),StopperPole(122576-8),1/2"Keyless
chuck(763191-5),BitHolder(452947-8),Hook(324705-1),PlasticCarryingCase(140354-4)
DHP451Z:
ToolOnly.BatteriesandChargerSoldSeparately.
Grip(122750-8),2Ea.DoubleEndedBits2-45(784637-8),StopperPole(122576-8),
1/2"Keylesschuck(763191-5),BitHolder(452947-8),Hook(324705-1)
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Steel
1/2˝ (13 mm)
Wood
2-9/16˝ (65 mm)
No load speed:
1st Speed
0 - 300 RPM
2nd Speed
0 - 600 RPM
3rd Speed
0 - 1,700 RPM
Maximum Torque 560 in. lbs. (63 Nm)
Overall length
9-3/8˝ (238 mm)
Net weight
5.3 lbs. (2.4 kg)
DDF451RFE
Driver Drill
STANDARD EQUIPMENT INCLUDES:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger
(DC18RC), Bit Holder (452947-8), Grip (122749-3), 1/2" Keyless
Chuck (763191-5), 2Ea. Double Ended Bits(784637-8),
Hook (324705-1), Plastic Carrying Case (140354-4)
PICTURED: DHP451RFE
Hammer Driver Drill
Variable 3-Speed, Reversible
DHP451RFE, DHP451Z, DDF451RFE
1/2˝ Cordless Hammer / Driver Drills
