HRH01
STANDARD EQUIPMENT INCLUDES:
2 Ea. 36V (2.6Ah) Li-Ion Batteries BL3626 (194874-0), Charger (DC36RA), Battery Cover (451153-2), Grip(158057-6),
Cleaning Cloth (443122-7), Bit Grease (194683-7), Depth Gauge (324219-0), Plastic Carrying Case (141407-2)
Lightweight 3-Mode Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Center of Gravity located close to rear handle resulting in ideal tool balance during operation
• Torque Limiter stops rotation if bit jams for increased operator safety and enhanced motor protection
• 40 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• Rubber Housing Bumper protects mode selector switch and gear housing from damage
• LED light with Afterglow feature
• One Touch Sliding Chuck enables quick and easy bit change
• Sliding Rear Handle for increased vibration absorption
• Ergonomic Soft Rubber Grip design for vibration
absorption and comfortable operation
1˝ Cordless Rotary Hammer
SPECIFICATIONS
Battery Capacities:
36V (2.6 Ah) Li-Ion
Two 18V (3.0 Ah) Li-Ion
Capacities:
Concrete
1˝ (26 mm)
Steel
1/2˝ (13 mm)
Wood
1-1/4˝ (32 mm)
No Load Speed
0 – 1,200 RPM
Blows Per Minute
0 – 4,800 BPM
Impact Energy
3.0 J (2.2 ft. lbs)
Overall Length
14-1/4˝ (363 mm)
Net Weight
9.9 lbs (4.5 kg)
Variable Speed, Reversible
HKU01ZX2
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Direct Connect Battery Converter BCV02 (195850-7)
Lightweight Design with High Efficiency, Zero Emissions
and Low Noise Level
• Zero Emissions and Low Noise Level ideal for use in sensitive work environments,
including residential areas and more
• Adjustable 3-Stage Handle enables positioning at optimal angle of operation or for more compact
storage when not in use
• Battery Capacity Warning Light indicates approximate remaining battery power for each battery
• Transport Wheels enable easy movement around the work site and can be folded upright when not in use
• Carrying Handles enable easier loading or unloading from vehicle or trailer
• 2-Step Switch/Handle Lever Starting System and
Child Lock Key prevents accidental start up for
maximum safety
13-3/4˝ Cordless Cultivator
SPECIFICATIONS
Battery Capacities:
36V (2.6 Ah) Li-Ion
Two 18V (3.0 Ah) Li-Ion
No Load Speed:
Tine Axle Speed
85 RPM
Motor Speed
4,100 RPM
Cultivating Width
13-3/4˝ / 8-7/8˝ (350 / 225 mm)
Tine Diameter
9-5/8˝ (245 mm)
Transmission Speeds
1-Forward
Dimensions (L x W x H)
47˝x 19-1/4˝x 39-1/4˝
(1,193 mm x 488 mm x 998 mm)
Net Weight
48.5 lbs (22.2 kg)
BCV02
ACCEPTS BCV02
NOT INCLUDED
18V
to
36V
BATTERY CONVERTERS
Direct Connect Style –
BCV03
Belt / Shoulder Style –
BCV01
• Enables the use of Two 18V Li-Ion
Batteries to operate most 36V Li-Ion
Tools and Accessories
• Features Li-Ion Battery Protection
System, including Over-Discharge.
Temperature and Circuit Protection for
enhanced performance, battery cycle life
and overall battery life
• LED Power Lights indicate remaining
battery power
• Compact Design ideal for direct mounting on tools and accessories
• Batteries not included
For use with models:
HRH01, HRU01ZX2,
HKU01ZX2
• Enables the use of Two 18V Li-Ion
Batteries to operate most 36V Li-Ion
Tools and Accessories
• Features Li-Ion Battery Protection
System, including Over-Discharge.
Temperature and Circuit Protection for
enhanced performance, battery cycle life
and overall battery life
• LED Power Lights indicate remaining
battery power
• Rugged ABS Plastic Cover provides maximum bettery protection
• Heavy Duty 5' Power Cord allows for maximum reach
• Can be worn using Belt Hook and Loops or with optional Shoulder Strap
(Part No. 166094-6, not shown)
For use with models:
HRH01, HKU01ZX2
HRU01ZX2
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.
CutterAssembly
(126183-9), Protective Guard (195959-5),Tool Kit (195960-0), Direct Connect Battery Convertor BCV02 (195850-7)
Low Noise Level And Zero Emissions
• Brushless DC Motor with high power to weight and size ratio
• Battery Power Warning light indicates approximate remaining battery power
• Motor Indicator Warning Light indicates current limiter has been activated
• Current Limiter prevents motor burnout caused by overheating
• Electric Brake for increased operator safety
• Variable Speed Settings allow operator to adjust cutting speed based on
materials or application
• 11-3/4˝ Cutting Path (using standard equipment string trimmer head)
• Well Balanced design with Cushioned Rubber Rear Grip and Front Handle, with Shoulder Strap
for Superior Ergonomic Comfort
• Includes BCV02 18V to 36V Li-Ion Battery Converter enabling use with 2 x 18V Li-Ion BL1830 Batteries
11-3/4˝ Cordless Curved Shaft Line Trimmer
Electric Brake, Variable Speed,
Reversible
BCV02
SPECIFICATIONS
Battery Capacities:
36V (2.6 Ah) Li-Ion
Two 18V (3.0 Ah) Li-Ion
Cutting Width
11-3/4˝ (300 mm)
No Load Speed:
High
0 - 7,000 RPM
Low
0 - 5,100 RPM
Dimensions (L x W x H)
67-3/4˝ x 11-5/8˝ x 16-1/2˝
(1,720 mm x 295 mm x 420 mm)
Net Weight
8.4 lbs (3.8 kg)
MORE POWER
MORE RUN TIME
MORE WORK
BCV03
196810-2
BCV01
195512-7
