Cordless
Power Tools
makita.ca
13
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Steel
1/2˝ (13 mm)
Wood
2-9/16˝ (65 mm)
Maximum Torque
750 in. lbs (84 Nm)
No Load Speed:
Low
0 - 400 RPM
High
0 - 1,800 RPM
Overall Length
8-7/8˝ (225 mm)
Net Weight
5.0 lbs. (2.3 Kg)
DDF458RFE
DDF458F DDF458Z
STANDARD EQUIPMENT INCLUDES:
DDF458RFE:
Two18V(3.0Ah)Li-IonBatteries
BL1830(194205-3),Charger(DC18RC),Bitholder(452947-8),Grip(126130-0),DoubleEnded
Bit2-45(784637-8),BatteryCover(450128-8),1/2"KeylessDrillChuck(766015-4),Hook(346449-3),PlasticCarryingCase(821532-2)
DDF458F:
18V (3.0Ah) Li-ion Battery
BL1830 (194205-3),Bitholder(452947-8),Grip(126130-0),DoubleEndedBit2-45(784637-8),
1/2"KeylessDrillChuck(766015-4),Hook(346449-3)
DDF458Z:
Tool Only. Batteries and Charger Sold Separately.
Grip (126130-0), 2 ea. Double Ended Bits (784637-8),
Bit Holder (452947-8), Keyless Chuck (766015-4), Hook (346449-3)
High Efficiency,
Compact Design
• eXtreme Protection Technology (XPT) offers maximum
protection against dust, debris and liquids for optimal
performance in extreme conditions
• Battery Protection System provides Over-Discharge,
Temperature and Circuit Protection for enhanced
performance, battery cycle life and overall battery life
• 21 Clutch Settings deliver up to 750 in. lbs. of torque
• All Metal Gears for more efficient power transmission
• Ultra-Compact Design (Only 8-7/8˝ Long)
• Dual LED Job Lights with Pre-Glow and Afterglow feature
• Improved Ergonomic Soft Rubber Grip design for vibration
absorption and comfortable operation features re-contoured
rear grip portion and ribbed grip for improved hold
DDF458RFE, DDF458F, DDF458Z
1/2˝ Cordless Driver Drills
PICTURED: DDF458RFE
Driver Drill
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
5/8˝ (16 mm)
Steel
1/2˝ (13 mm)
Wood
2-9/16˝ (65 mm)
No Load Speed:
Low
0 - 400 RPM
High
0 - 1,800 RPM
Blows Per Minute:
Low
0 - 6,000 BPM
High
0 - 27,000 BPM
Maximum Torque
750 in. lbs (84 Nm)
Overall Length
8-7/8˝ (225 mm)
Net Weight
5.3 lbs. (2.4 kg)
DHP458RFE
DHP458F DHP458Z
STANDARD EQUIPMENT INCLUDES:
DHP458RFE:
Two18V(3.0Ah)Li-IonBatteries
BL1830(194205-3),ChargerDC18RC(DC18RC),BatteryCover(450128-8),Grip(126131-8),
DoubleEndedBits(784637-8),BitHolder(452947-8),StopperPole(122576-8),KeylessChuck(766015-4),Hook(346449-3),PlasticCarryingCase
(821532-2)
DHP458F:
18V (3.0Ah) Li-ion Battery
BL1830 (194205-3),Grip(126131-8),DoubleEndedBits(784637-8),BitHolder(452947-8),
StopperPole(122576-8),KeylessChuck(766015-4),Hook(346449-3)
DHP458Z:
Tool Only. Batteries and Charger Sold Separately.
Grip (126131-8), 2 ea. Double Ended Bits (784637-8),
Bit Holder (452947-8), Stopper Pole (122576-8), Keyless Chuck (766015-4), Hook (346449-3)
High Efficiency,
Compact Design
• eXtreme Protection Technology (XPT) offers maximum
protection against dust, debris and liquids for optimal
performance in extreme conditions
• Independent Battery Fuel Gauge indicates approximate
remaining battery power
• Battery Protection System provides Over-Discharge,
Temperature and Circuit Protection for enhanced performance,
battery cycle life and overall battery life
• 21 Clutch Settings deliver up to 750 in. lbs. of torque
• All Metal Gears for more efficient power transmission
• Ultra-Compact Design (Only 8-7/8˝ Long)
• Dual LED Job Lights with Pre-Glow and Afterglow feature
• Improved Ergonomic Soft Rubber Grip design for vibration
absorption and comfortable operation features re-contoured
rear grip portion and ribbed grip for improved hold
DHP458RFE, DHP458F, DHP458Z
1/2˝ Cordless Hammer Driver Drills
PICTURED: DHP458RFE
Hammer Driver Drill
Independent Battery
Fuel Gauge,
Variable 2-Speed,
Reversible
Variable 2-Speed,
Reversible
DHP481Z
Hammer Driver Drill
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
DDF481Z
Driver Drill
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Variable 2-Speed, Reversible
Features Brushless
DC Motor
• eXtreme Protection Technology (XPT)
offers maximum protection against dust,
debris and liquids for optimal performance
in extreme conditions
• Battery fuel gauge indicates approximate
remaining battery power
• Brushless DC motor with high
power to weight and size ratio
• Brushless DC motor generates
less heat buildup and is ideal for
prolonged use in manufacturing /
production applications
DHP481Z, DDF481Z
1/2˝ Cordless Hammer / Driver Drills
PICTURED: DHP481Z
Hammer Driver Drill
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
5/8˝ (16 mm)
Steel
1/2˝ (13 mm)
Wood
3˝ (76 mm)
No Load Speed:
Low
0 - 550 RPM
High
0 - 2,100 RPM
Blows Per Minute:
Low
0 - 8,250 BPM
High
0 - 31,500 BPM
Maximum Lock Torque
1,090 in. lbs (125 Nm)
Overall Length
8-1/8˝ (205 mm)
Net Weight
4.6 lbs (2.1 kg)
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Steel
1/2˝ (13 mm)
Wood
3˝ (76 mm)
No Load Speed:
Low
0 - 550 RPM
High
0 - 2,100 RPM
Maximum Lock Torque
1,090 in. lbs (125 Nm)
Overall Length
8-1/8˝ (205 mm)
Net Weight
4.4 lbs (2.0 kg)
