DHR241RFE
STANDARD EQUIPMENT INCLUDES:
DHR241RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RC), Battery Cover (450128-8), Depth Gauge
(324219-0), Side Handle (158057-6), Plastic Carrying Case (824861-2)
DHR241F:
18V (3.0Ah) Li-ion Battery
BL1830 (194205-3), Depth Gauge (324219-0), Side Handle (158057-6)
DHR241Z:
Tool Only. Batteries and Charger Sold Separately.
Depth Gauge (324219-0), Side Handle (158057-6)
Lightweight, 3 Mode Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• Rubber Joint Construction suppresses transmission of vibration to battery, minimizing battery failures
due to terminal breakage or poor electrical contact
• 40 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• Rubber Housing Bumper protects mode selector switch and gear housing from damage
• One Touch Sliding Chuck enables quick and easy bit changes
Variable Speed, Reversible
15/16˝ Cordless Rotary Hammer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
15/16˝ (24 mm)
Steel
1/2˝ (13 mm)
Wood
1-1/16˝ (26 mm)
Impact Energy
1.9 J (1.4 ft.lbs.)
No Load Speed
0 - 1100 RPM
Blows Per Minute
0 - 4000 BPM
Overall Length
16-3/8˝ (417 mm)
Net Weight
7.7 lbs. (3.5 kg)
DHR241F
DHR241Z
DHR202RFE
STANDARD EQUIPMENT INCLUDES:
DHR202RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RC), Battery Cover (450128-8), Depth Gauge
(324219-0), Side Handle (158057-6), Plastic Carrying Case (824861-2)
DHR202Z:
Tool Only. Batteries and Charger Sold Separately.
Depth Gauge (324219-0), Side Handle (158057-6)
Lightweight, 3 Mode Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• Rubber Joint Construction suppresses transmission of vibration to battery, minimizing battery failures
due to terminal breakage or poor electrical contact
• 40 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• LED Light with Afterglow feature
• One touch sliding chuck enables quick and easy bit changes
Variable Speed, Reversible
15/16˝ Cordless Rotary Hammer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
15/16˝ (24 mm)
Steel
1/2˝ (13 mm)
Wood
1˝ (26 mm)
Impact Energy
1.9 J (1.4 ft. lbs.)
No Load Speed
0 - 1,100 RPM
Blows Per Minute
0 - 4,000 BPM
Overall Length
14-1/8˝ (358 mm)
Net Weight
7.7 lbs. (3.5 kg)
DHR202Z
DHR242RFE
STANDARD EQUIPMENT INCLUDES:
DHR242RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RC), Battery Cover (450128-8),
Depth Gauge (324219-0), Side Handle (158057-6), Plastic Carrying Case (141542-6)
DHR242Z:
ToolOnly.BatteriesandChargerSoldSeparately.
DepthGauge(324219-0),SideHandle(158057-6)
Lightweight 3-Mode Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Brushless DC Motor with high power to weight and size ratio
• BrushlessDCMotorgenerateslessheatbuildupandisidealforprolongeduseinhighproductionapplications
• Quickly attaches to Makita's DX01 Dust Extraction System for dustless drilling applications in sensitive
work environments (DX01 sold separately)
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• Rubber Joint Construction suppresses transmission of vibration to battery, minimizing battery failures
due to terminal breakage or poor electrical contact
15/16˝ Cordless Rotary Hammer with Brushless Motor
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
15/16˝ (24 mm)
Steel
1/2˝ (13 mm)
Wood
1-1/16˝ (27 mm)
Impact Energy
2.4 J (1.8 ft. lbs.)
No Load Speed
0 - 950 RPM
Blows Per Minute
0 - 4,700 BPM
Overall Length
12-7/8˝ (328 mm)
Net Weight
7.3 lbs. (3.3 kg)
DHR242Z
Variable Speed, Reversible
LXRH02Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Depth Gauge (324219-0), Drill Chuck Set (194079-2), Side Handle (158057-6)
Lightweight 3-Mode Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
Features Quick Change Drill Chuck
• Brushless DC Motor with high power to weight and size ratio
• BrushlessDCMotorgenerateslessheatbuildupandisidealforprolongeduseinhighproductionapplications
• Quickly attaches to Makita's DX02 Dust Extraction System for dustless drilling applications in sensitive
work environments (DX02 sold separately)
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
15/16˝ Cordless Rotary Hammer with Brushless Motor
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
15/16˝ (24 mm)
Steel
1/2˝ (13 mm)
Wood
1-1/16˝ (27 mm)
Impact Energy
2.4 J (1.8 ft. lbs.)
No Load Speed
0 - 950 RPM
Blows Per Minute
0 - 4,700 BPM
Overall Length
13-7/8˝ (353 mm)
Net Weight
6.4 lbs. (2.9 kg)
Variable Speed, Reversible
DHR242RFEV
STANDARD EQUIPMENT INCLUDES:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RC), Battery Cover (450128-8), Depth Gauge (324219-0),
Side Handle (158057-6), Dust Extraction System (DX01), Plastic Carrying Case (141543-4)
15/16˝ Cordless Rotary Hammer with Brushless Motor
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
15/16˝ (24 mm)
Steel
1/2˝ (13 mm)
Wood
1-1/16˝ (27 mm)
Impact Energy
2.4 J (1.8 ft. lbs.)
No Load Speed
0 - 950 RPM
Blows Per Minute
0 - 4,700 BPM
Overall Length
12-7/8˝ (328 mm)
Net Weight
7.3 lbs. (3.3 kg)
Variable Speed, Reversible
Lightweight 3-Mode Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Brushless DC Motor with high power to weight and size ratio
• BrushlessDCMotorgenerateslessheatbuildupandisidealforprolongeduseinhighproductionapplications
• IncludesDX01HEPAFilterDustExtractionSystemfordustlessdrillingapplicationsinsensitiveworkenvironments
• DX01 HEPA Filter Dust Extraction System features One-Touch Attachment / Removal System,
Adjustable Depth Gauge and Large Capacity Dust Box for maximum efficiency and versatility
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• DX01 - Use with models DHR242RFEV / DHR242RFE / DHR242Z
• DX02 - Use with model LXRH02Z
• Provides effective dust extraction for drilling applications in sensitive work environments
• Transparent Dust Box allows operator to quickly reference current dust level
• One Touch Attachment/Removal system enables canister to be quickly emptied of accumulated dust
• Large Dust Canister provides extended operating time between cleaning
• Easily removable HEPA Filter for fast and effective cleaning
• Integrated Depth Gauge is fully adjustable for precise depth setting
• Easily removable from Rotary Hammer when not immediately required
• Double Lock Function prevents accidental removal from Rotary Hammer
• Automatic Operation in conjunction with Rotary Hammer using integrated DC Motor
Rotary Hammer HEPA Filter Dust Extraction System
DX01 (Shown)
Dust Extraction System
HEPA
filter
Quick Change Drill Chuck
194079-2
