STANDARD EQUIPMENT INCLUDES:
Oil Supply (181434-7), Safety Goggles (195246-2), Protective Casing (BA00000372)
15° Round Head Coil Framing Nailer
• Reduced size for improved handling and optimal maneuverability during operation
• 2 Mode - Sequential, Bump Fire
• 8 depth nailing settings in 1/32˝ increments with adjustment knob
• One touch and easy to load magazine
• Rubberized Grip for increased comfort during prolonged use
3-1/2˝ Framing Coil Nailer
SPECIFICATIONS
Operating Air Pressure 70 - 120 PSIG
Nail Size 1-3/4˝ - 3-1/2˝ (45 mm - 90 mm)
Nail Type .099˝ - .150˝ 15° Round Head
Magazine Capacity
150 - 300 Nails
Dimensions (L x W x H)
12-1/2˝ x 5˝ x 14-1/4˝
(318 mm x 128 mm x 363 mm)
Net Weight
7.7 lbs (3.5 kg)
AN902
STANDARD EQUIPMENT INCLUDES:
Safety Goggles (195246-2), Oil Supply (181434-7), Hex Wrench 4 (783202-0)
15° Round Head Coil Roofing Nailer
• Operates in Bump Fire mode
• 6 depth nailing settings with adjustment knob
• Convenient adjustable Belt Hook
• One touch and easy to load magazine
• Rubberized Grip for increased comfort during prolonged use
• Easy to remove contact top to clear nail/debris jams
1-3/4˝ Coil Roofing Nailer
SPECIFICATIONS
Operating Air Pressure 65 - 120 PSIG
Nail Size 3/4 – 1-3/4˝ (19 mm - 45 mm)
Nail Type 1/8˝ (3.0 mm) 15° Round Head
Magazine Capacity
120 Nails
Dimensions (L x W x H)
10-3/8˝ x 4-5/8˝ x 10-5/8˝
(265 mm x 117 mm x 269 mm)
Net Weight
5.5 lbs (2.5 kg)
AN453
STANDARD EQUIPMENT INCLUDES:
Oil Supply (181434-7)
15° Round Head Coil Roofing Nailer
• Operates in Bump Fire Mode
• 9 Depth Settings with adjustment knob
• Two Housing Guards to protect air chamber
• One-Touch, easy to load magazine
• Quick Release Shingle Guide for easy adjustment on the jobsite
• Rubberized Grip for vibration absorption and comfortable operation
1-3/4˝ Roofing Coil Nailer
SPECIFICATIONS
Operating Air Pressure 65 - 120 PSIG
Nail Size 7/8˝ – 1-3/4˝ (22 mm - 45 mm)
Nail Type 1/8˝ (3.0 mm) 15° Round Head
Magazine Capacity
120 Nails
Dimensions (L x W x H)
9-5/8˝ x 4-1/2˝ x 10-3/8˝
(245 mm x 114 mm x 265 mm)
Net Weight
5.8 lbs (2.5 kg)
AN451
STANDARD EQUIPMENT INCLUDES:
Hex Wrench 4 (783202-0), Plastic Carrying Case (824490-1), Safety Goggles (195246-2), Oil Supply (181434-7)
15° Round Head Coil Siding Nailer
• 360° exhaust system directs exhaust away from the operator
• 3 Mode - Sequential, Bump, Lock-Off
• Easy load magazine provides maximum versatility
• 9 depth nailing settings in 1/16˝ increments with adjustment knob
• Convenient adjustable Belt Hook
• One touch and easy to load magazine
• Rubberized Grip for increased comfort during prolonged use
2-1/2˝ Coil Siding Nailer
SPECIFICATIONS
Operating Air Pressure 65 - 120 PSIG
Nail Size:
Wire Collated
1-1/4˝ - 2-1/2˝
(32 mm - 65 mm)
Plastic Collated
1-1/4˝ - 2˝
(32 mm - 50 mm)
Nail Type .080˝ - .099˝ 15° Round Head
Magazine Capacity
200 - 400 Nails
Dimensions (L x W x H)
13-1/16˝ x 5˝ x 12-1/2˝
(332 mm x 317 mm x 127 mm)
Net Weight
5.1 lbs (2.3 kg)
AN611
Makita offers a wide variety of
ACCESSORIES!
STANDARD EQUIPMENT INCLUDES:
Two NoseAdapter (HY00000422), Oil Supply, Plastic Carrying Case, Safety Goggles
15-Gauge Finish Nailer
• 2 mode - sequential & bump fire
• 360° exhaust system directs exhaust away from operator
• Air blower feature cleans material of dust and debris
• Toolless depth adjustment for quick and easy adjustment
• Quick release toolless nose enables easy clearing of jammed nails
• Contact arm design prevents accidental engagement of
trigger for maximum operator safety
• High visibility slim nose tip enables precise positioning of nails
2-1/2˝ Angled Finish Nailer
SPECIFICATIONS
Operating Air Pressure 70 - 120 PSIG
Nail Size (15 ga)
1-1/4˝ - 2-1/2˝ (32 - 64 mm)
Nail Type
15 ga Finishing Nails
Magazine Capacity
100
Dimensions (L x W x H)
13-3/8˝ x 3-15/16˝ x 12-1/8˝
(339 mm x 100 mm x 309 mm)
Net Weight
4.0 lbs (1.8 kg)
AF635
STANDARD EQUIPMENT INCLUDES:
Two NoseAdapter (HY00000560), Oil Supply, Plastic Carrying Case, Safety Goggles
16-Gauge Straight Finish Nailer
• 2 mode - sequential & bump fire
• 360° exhaust system directs exhaust away from operator
• Air blower feature cleans material of dust and debris
• Toolless depth adjustment for quick and easy adjustment
• Quick release toolless nose enables easy clearing of jammed nails
• Contact arm design prevents accidental engagement of trigger for
maximum operator safety
• High visibility slim nose tip enables precise positioning of nails
2-1/2˝ Straight Finish Nailer
SPECIFICATIONS
Operating Air Pressure 70 - 120 PSIG
Nail Size (16 ga)
1˝ - 2-1/2˝ (25 - 64 mm)
Nail Type
16 ga Finishing Nails
Magazine Capacity
100
Dimensions (L x W x H)
12˝ x 3-3/4˝ x 11-3/4˝
(304 mm x 95 mm x 297 mm)
Net Weight
3.8 lbs (1.7 kg)
AF601
