149 / 180
Electric
Power Tools
makita.ca149
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
When
QUALITY & SERVICE
Counts – Choose Makita
STANDARD EQUIPMENT INCLUDES:
Hex Wrench 4 (783202-0), NoseAdapter (421658-6), Oil Supply (181434-7), Safety Goggles (195246-2)
15° Round Head Coil Framing Nailer
• 360° exhaust system directs exhaust away from the operator
• 3 Mode - Sequential, Bump, Lock-off
• 9 depth nailing settings in 1/16˝ increments with adjustment knob
• Convenient adjustable Belt Hook
• One touch and easy to load magazine
• Rubberized Grip for increased comfort during prolonged use
3-1/2˝ Framing Coil Nailer
SPECIFICATIONS
Operating Air Pressure 65 - 120 PSIG
Nail Size 1-3/4˝ - 3-1/2˝ (45 mm - 90 mm)
Nail Type .099˝ - .150˝ 15° Round Head
Magazine Capacity
150 - 300 Nails
Dimensions (L x W x H)
16-1/8˝ x 12-1/2˝ x 5-1/4˝
(408 mm x 316 mm x 131 mm)
Net Weight
7.1 lbs (3.2 kg)
AN901
STANDARD EQUIPMENT INCLUDES:
HookAssy (122742-7), Oil Supply (181434-7), Safety Goggles (195246-2)
21° Round Head Framing Nailer
• Large capacity air chamber for increased power
• 3 Mode - Sequential, Bump, Lock-Off
• 9 depth nailing setting in 1/16˝ increments
with adjustment knob
• Convenient Collapsible Rafter Hook
• Nose piece with sure-grip spikes prevents slipping
• Dry fire prevention system prolongs life of tool
• Silent sheet reduces noise when
disconnecting coupler
3-1/2˝ Framing Nailer
SPECIFICATIONS
Operating Air Pressure 65 - 120 PSIG
Nail Size
2˝ - 3-1/2˝
Nail Type .113˝ - .162˝ 21° Round Head
Magazine Capacity
64 - 74 Nails
Dimensions (L x W x H)
22˝ x 4-1/4˝ x 13-11/16˝
(559 mm x 109 mm x 347 mm)
Net Weight
8.6 lbs (3.9 kg)
AN923
STANDARD EQUIPMENT INCLUDES:
HookAssy (122742-7), Oil Supply (181434-7), Safety Goggles (195246-2)
34° Clipped Head Framing Strip Nailer
• Large capacity air chamber for increased power
• 3 Mode - Sequential, Bump, Lock-off
• 9 depth nailing setting in 1/16˝ increments
with adjustment knob
• Convenient Collapsible Rafter Hook
• Nose piece with sure-grip spikes prevents slipping
• Dry fire prevention system prolongs life of tool
• Silent sheet reduces noise
when disconnecting coupler
3-1/2˝ Framing Nailer
SPECIFICATIONS
Nail Type .113˝ - .131˝ 34° Clipped Head
Nail Size
2˝ - 3-1/2˝ 34° Clipped Head
Operating Air Pressure
65-120 PSIG
Magazine Capacity
60 - 84 Nails
Dimensions (L x W x H)
17-7/8˝ x 4-1/4˝ x 14-3/8˝
(455 mm x 109 mm x 365 mm)
Net Weight
8.8 lbs (4.0 kg)
AN943
Uses 34° Clipped Head
Framing Nails
Uses 21° Round Head
Framing Nails
STANDARD EQUIPMENT INCLUDES:
Oil Supply (181434-7), Safety Goggles (195246-2)
28° Round Head Framing Strip Nailer
• Large capacity air chamber for increased power
• 2 Mode - Sequential & Bump
• Depth setting knob for adjustment of nailing depth
• Convenient Collapsible Rafter Hook
• Nose piece with sure-grip spikes prevents slipping
Uses 28° Round Head
Framing Nails
3-1/2˝ Framing Nailer
SPECIFICATIONS
Nail Type 0.113˝ - 0.131˝, 28° Round Head
Magazine Capacity
60 - 84 Nails
Operating Air Pressure
70-120 PSIG
Nail Size 2-1/2˝- 3-1/2˝, 28° Round Head
Dimensions (L x W x H)
17-1/2˝ x 4-31/32˝ x 13-11/32˝
(445 mm x 126 mm x 339 mm)
Net Weight
7.0 lbs (3.2 kg)
AN944
AF635
