176 / 180
Impact indicator
lamp provides
visual indication
of successful or
failed fastening
MANUFACTURING & ASSEMBLY
makita.ca176
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
TD091DZ
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.
High Operational Efficiency With Ultra-Compact Design
• Heavy-duty design with 4-pole motor for maximum operational efficiency and reliability
• Electric brake stops driver bit immediately after trigger is released to prevent over-tightening of fasteners
• Short trigger stroke (just 1/4"!) minimizes operator fatigue during periods of prolonged use in
manufacturing / production applications
• Battery capacity warning light indicates ideal time to recharge battery
• Automatic battery shut-off system protects against over-discharge of cells and incomplete fastening
due to low battery power
• LED job light with pre-glow feature
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
Variable Speed,
Reversible,
Electric Brake
1/4˝ Cordless Impact Driver
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Capacity (Driving Shank)
Hex
1/4˝ (6.35 mm)
No Load Speed
0 - 2,400 RPM
Impacts Per Minute
0 - 3,000 IPM
Fastening Torque 90 Nm. (800 in./lbs)
Width
2-1/8˝ (54 mm)
Height
7-7/8˝ (200 mm)
Length
5-1/4˝ (134 mm)
Net Weight
1.6 lbs (0.7 kg.)
STANDARD EQUIPMENT INCLUDES:
DTD134RFE:
Two 14.4V (3.0Ah) Li-Ion Batteries
BL1430B (194066-1), Rapid Charger (DC18RC), Battery Cover (450128-8),
Hook (346449-3), Plastic Carrying Case (141856-3)
DTD134Z:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3)
Compact and Lightweight Design with Overall Length of 5-7/16˝
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Battery Protection System provides Over-Discharge, Temperature and Circuit Protection for
enhanced performance, battery cycle life and overall battery life
•
Increased Max. Torque of 1,370 in. lbs
• One-Touch Bit Holder enables quick and easy bit installation
• Battery Power Warning
light indicates
approximate remaining
battery power
• LED Light with Pre-Glow
and Afterglow feature
• Glow in the Dark Bumper
1/4˝ Cordless Impact Driver
SPECIFICATIONS
Battery Capacities
14.4V Li-ion
Hex Shank
1/4˝ Hex
No Load Speed
0 - 2,400 RPM
Impacts Per Minute
0 - 3,200 IPM
Maximum Torque
1,370 in. lbs (155 Nm)
Overall Length
5-7/16˝ (138 mm)
Net Weight
3.1 lbs (1.4 kg)
Variable Speed,
Reversible
DTD134Z
DTD134RFE
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
1/4˝ Cordless Impact Drivers
SPECIFICATIONS
Battery Capacities
14.4V Li-ion
Capacity (driving shank)
Hex
1/4˝ (6.35 mm)
Impacts Per Minute
0 - 3500 IPM
Width
2-15/16˝ (74 mm)
Height (with battery)
8-1/2˝ (216 mm)
Length
5-5/8˝ (144 mm)
No Load Speed:
BTD044Z
0 - 2300 RPM
BTD064Z
0 - 2500 RPM
BTD104Z
0 - 2700 RPM
Fastening Torque Up To:
BTD044Z
35 Nm. (310 in./lbs)
BTD064Z
65 Nm. (575 in./lbs)
BTD104Z
95 Nm. (841 in./lbs)
Net Weight:
BTD044Z
1.8 lbs (0.8 kg)
BTD064Z
1.6 lbs (0.7 kg)
BTD104Z
1.8 lbs (0.8 kg)
Makita offers a wide variety of
ACCESSORIES!
High Fastening Precision With
Compact And Lightweight Design
• Automatic battery shut-off system warns operator
visually and audibly to prevent incomplete fastening
due to low remaining battery power
• Automatic impact stop system prevents over or
under-tightening by stopping the motor after
completing a pre-set number of impacts
Use only with 14.4V Compact
Li-Ion Battery BL1415NA
(Part No. 196987-3)
Variable / Reversible
LED Display
Panel
BTD044Z BTD064Z BTD104Z
BTD044Z
Prevents Debris & Liquids From Entering The Tool
Expands Tool Usage To Harsh Environments
Motor And Electrical Components Remain Clean
Provides Longer Tool Life
STANDARD EQUIPMENT INCLUDES:
7.2V (1.5Ah) Li-Ion Battery
Batteries BL0715 (198001-1), Pod / Stick Charger (DC10WB), Holster (168435-2),
Phillips Bit 2-50 (784244-7),Tool Bag (831277-4)
1/4˝ Cordless Impact Driver
SPECIFICATIONS
Battery
7.2V (1.5 Ah) Li-Ion
Hex Shank
1/4˝ Hex
Impacts Per Minute
0 - 3,000 IPM
No Load Speed
0 - 2,450 RPM
Maximum Fastening Torque
220 in. lbs (25 Nm)
Capacities:
Machine Screw 1/8˝ - 5/16˝ (M3 - M8)
Standard Bolt
1/8˝ - 5/16˝ (M3 - M8)
High Tensile Bolt 1/8˝ - 1/4˝ (M3 - M6)
Overall Length
11-1/8˝ (282 mm)
Net Weight
1.2 lbs (0.5 kg)
TD022DS
Variable Speed, Reversible,
Electric Brake
Compact And Lightweight Design With Precision Control
And High Fastening Torque
• Multi-function variable speed rotary switch allows operators to adjust driving speed and direction
simultaneously for precise fastening applications
• Switch position enables easy access for left or right handed users
• Lock-off button prevents accidental startup
• Adjustable handle with enhanced hinge mechanism for operational versatility
• LED job light with pre-glow feature
