18 / 180
LITHIUM-ION
makita.ca18
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
DDA350RFE
Two 18V (3.0Ah) Li-Ion Batteries
BL1830B (194205-3), Rapid Charger (DC18RC), Battery Cover (450128-8),
Side Handle (153489-2), Chuck Key Holder (450688-0), Chuck Key(763415-9), Plastic Carrying Case(824851-5)
DDA350Z:
ToolOnly.BatteriesandChargerSoldSeparately.
SideHandle(153489-2),ChuckKeyHolder(450688-0),ChuckKey(763415-9)
Compact Design For Optimal Versatility In Confined Spaces
• 2-5/8˝ Head height ideal for operation in confined spaces
• Industrial Aluminum Gear Housing for increased durability
• LED Light with Afterglow feature
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Variable Speed, Reversible
3/8˝ Angle Drill
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Steel
3/8˝ (10 mm)
Wood
1˝ (25 mm)
No Load Speed
0 - 1,800 RPM
Overall length
12-3/8˝ (314 mm)
Net Weight
4.0 lbs (1.8 kg)
DDA350RFE
DDA350Z
2-5/8˝
DFS452Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Two + Bits 2-25 (784261-7), Magnetic Bit Holder (784801-1), Hook (346449-3),
Locator (158876-0) )
Features NEW and INNOVATIVE Push-Drive Technology
Ultra-High Efficiency Comparable to AC Screwdrivers
• Push-drive technology minimizes power consumption under no load for extended battery run time
and reduced noise and vibration
• Aluminum gear housing for increased durability
• Brushless DC motor with high power to weight ratio
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in
manufacturing / production applications
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids
for optimal performance in extreme conditions
1/4˝ Drywall Screwdriver
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
1/4˝ Hex
No Load Speed
0 - 4,000 RPM
Overall Length
9-7/8˝ (251 mm)
Net Weight
2.5 lbs (1.1 kg)
Variable Speed, Reversible
DFR550RFE
STANDARD EQUIPMENT INCLUDES:
DFR550RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830B (194205-3), Rapid Charger (DC18RC),Two Square Bit 2-162 (784645-9),
Phillips Bit 2-162 (784251-0), Belt Clip (281217-6), Plastic Carrying Case (824807-8)
DFR550Z:
ToolOnly.BatteriesandChargerSoldSeparately.
TwoSquareBit2-162(784645-9),PhillipsBit2-162(784251-0),BeltClip(281217-6)
High Torque Model For Driving Screws Up To 2-3/16˝ Long
• Anti-Tilt Mechanism prevents screws from swaying out of the drive position
• Silent Clutch enables smooth gearing engagement for quiet operation and reduced maintenance
• Adjustable Stopper Base can be set for different screw lengths
• Lock On Button for easy continuous operation
• Non-Marring Rubber Contact Tip prevents damage to materials
• Dust Proof Construction enables smooth sliding action of Stopper Base for more efficient operation
• Folding Screw Guide prevents collated screw strip from becoming tangled
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Reversible
1/4˝ Autofeed Screwdriver
DFR550Z
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
1/4˝ Hex
Screw Capacity
1˝ - 2-3/16˝
(25 mm to 55 mm)
No Load Speed
4,000 RPM
Overall Length
16-3/4˝ (424 mm)
Net Weight
5.1 lbs (2.3 kg)
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.
TwoSquareBit2-182(784647-5),PhillipsBit2-182(784253-6),BeltClip(281217-6)
High Torque Model For Driving Screws Up To 2-15/16˝ Long
• Anti-Tilt Mechanism prevents screws from swaying out of the drive position
• Silent Clutch enables smooth gearing engagement for quiet operation and reduced maintenance
• Adjustable Stopper Base can be set for different screw lengths
• Lock On Button for easy continuous operation
• Non-Marring Rubber Contact Tip prevents damage to materials
• Dust Proof Construction enables smooth sliding action of Stopper Base for more efficient operation
• Folding Screw Guide prevents collated screw strip from becoming tangled
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Reversible
1/4˝ Autofeed Screwdriver
DFR750Z
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
1/4˝ Hex
Screw Capacity 1-3/4˝ to 2-15/16˝
(45 mm to 75 mm)
No Load Speed
4,000 RPM
Overall Length
18-1/4˝ (464 mm)
Net Weight
5.1 lbs (2.3 kg)
DTD152RFE
STANDARD EQUIPMENT INCLUDES:
DTD152RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830B (194205-3),RapidCharger(DC18RC),BatteryCover(450128-8),
Hook(346449-3),PlasticCarryingCase(824812-5)
DTD152SYE:
Two18V(Compact)Li-IonBatteries
BL1815N(196235-0),StandardCharger(DC18SD),BatteryCover(450128-8),
Hook(346449-3),PlasticCarryingCase(824812-5)
DTD152Z:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3)
Ultra-Compact and Lightweight Design with Overall Length of Just 5-3/8"
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• NEW Battery Protection System provides Over-Discharge, Temperature and Circuit Protection
for enhanced performance, battery cycle life and overall battery life
• Increased max. torque of 1,460 in. lbs
• One-touch bit holder enables
quick and easy bit installation
• Twin LED lights with pre-glow
and after-glow functions
• Glow in the dark rubber bumper
1/4˝ Impact Driver
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Hex Shank
1/4˝ Hex
No Load Speed 0 - 2,900 RPM
Impacts Per Minute 0 - 3,500 IPM
Maximum Fastening Torque
1,460 in. lbs (165 Nm)
Overall Length 5-3/8˝ (137 mm)
Net Weight
2.0 lbs (0.9 kg)
Variable Speed, Reversible
DTD152Z
DTD152SYE
Motor runs only when
clutch is engaged
Makita offers a wide variety of
ACCESSORIES!
DFS452Z
Drives up to :
1,860 Screws or 58 (4´x 8´) Drywall Sheets
per 4.0 Ah BL1840B battery charge.
1-1/4" drywall screws into 1/2" drywall and 20 ga steel studs
For
ACCESSORIES
see page 115
For
ACCESSORIES
see page 115
