Makita General Catalogue

LITHIUM-ION

makita.ca

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

DDF482RFE

STANDARD EQUIPMENT INCLUDES:

DDF482RFE:

Two 18V (3.0Ah) Li-Ion Batteries

BL1830B (194205-3), Rapid Charger (DC18RC), Battery Cover (450128-8),

Double Ended Bit 2-45 (784637-8), 1/2˝Keyless Drill Chuck (766027-7), Hook (346449-3), Plastic Carrying Case (824812-5)

DDF482SYE:

Two 18V (Compact) Li-Ion Batteries

BL1815N (196235-0), Standard Charger (DC18SD), Battery Cover (450128-8),

Double Ended Bit 2-45 (784637-8), 1/2˝Keyless Drill Chuck (766027-7), Hook (346449-3), Plastic Carrying Case (141856-3)

DDF482Z:

Tool Only. Batteries and Charger Sold Separately.

Double Ended Bit 2-45 (784637-8), 1/2˝Keyless Drill Chuck (766027-7),

Hook (346449-3)

Incorporates Makita's NEW Battery Protection System

• Battery protection system provides over-discharge, temperature and circuit protection for enhanced

performance, battery cycle life and overall battery life

• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for

optimal performance in

extreme conditions

• 21 clutch settings

deliver up to 480 in. lbs

of torque

• All metal gears for more efficient

power transmission

• Twin LED jobs light with pre-glow and

after-glow functions

1/2˝ Drill / Driver

SPECIFICATIONS

Battery Capacities 18V Li-Ion

Capacities:

Steel

1/2˝ (13 mm)

Wood

1-1/2˝ (38 mm)

No Load Speed:

Low

0 - 600 RPM

High

0 - 1,900 RPM

Maximum Lock Torque

480 in. lbs (54 Nm)

Overall Length 7-1/4˝ (185 mm)

Net Weight

2.5 lbs (1.1 kg)

DDF482Z

DHP484RME

STANDARD EQUIPMENT INCLUDES:

DHP484RME:

Two 18V (4.0Ah) Li-Ion Batteries

BL1840B (196401-9), Rapid Charger (DC18RC), Battery Cover (450128-8),

Hook (346449-3), Double Ended Bit 2-45 (784637-8), 1/2˝Keyless Drill Chuck (766027-7), Plastic Carrying Case (821532-2)

DHP484SYE:

Two 18V (Compact) Li-Ion Batteries

BL1815N (196235-0), Standard Charger (DC18SD), Battery Cover (450128-8),

Hook (346449-3), Double Ended Bit 2-45 (784637-8), 1/2˝Keyless Drill Chuck (766027-7), Plastic Carrying Case (821532-2)

DHP484Z:

Tool Only. Batteries and Charger Sold Separately.

Hook (346449-3), Double Ended Bit 2-45 (784637-8),

1/2˝Keyless Drill Chuck (766027-7)

Features Brushless DC Motor

• eXtreme Protection Technology (XPT) offers

maximum protection against dust, debris and liquids for

optimal performance in extreme conditions

• Brushless DC motor generates less heat

buildup and is ideal for prolonged

use in manufacturing and

production applications

1/2˝ Hammer Drill / Driver

SPECIFICATIONS

Battery Capacities 18V Li-Ion

Capacities:

Concrete

1/2˝ (13 mm)

Steel

1/2˝ (13 mm)

Wood

1-1/2˝ (38 mm)

No Load Speed:

Low

0 - 500 RPM

High

0 - 2,000 RPM

Blows Per Minute:

Low

0 - 7,500 BPM

High

0 - 30,000 BPM

Maximum Lock Torque

530 in. lbs (60 Nm)

Overall Length 7-1/8˝ (182 mm)

Net Weight

4.0 lbs (1.8kg)

DHP484Z

DHP484SYE

DDF482SYE

DHP453SYE

STANDARD EQUIPMENT INCLUDES:

Two 18V (Compact) Li-Ion Batteries

BL1815N (196235-0), Standard Charger (DC18SD), Battery Cover (450128-8),

Double Ended Bit (784636-0), Hook (346449-3), 1/2˝ Keyless Drill Chuck (766027-7), Plastic Carrying Case (158777-2)

Compact And Lightweight Design

• 16 Clutch Settings deliver up to 340 in. lbs of torque

• Single Sleeve Keyless Drill Chuck for easy bit installation and removal

• All Metal Gears for more efficient power transmission

• Ergonomic Soft Rubber Grip design for vibration

absorption and comfortable operation

1/2" Hammer Drill / Driver

SPECIFICATIONS

Battery Capacities 18V Li-Ion

Capacities:

Concrete

1/2˝ (13 mm)

Steel

1/2˝ (13 mm)

Wood

1-7/16˝ (36 mm)

Blows Per Minute:

Low

0 - 6,000 BPM

High

0 - 19,500 BPM

Maximum Torque

340 in. lbs (38 Nm)

No Load Speed:

Low

0 - 400 RPM

High

0 - 1,300 RPM

Overall Length 9-7/16˝ (240 mm)

Net Weight

2.9 lbs (1.3 kg)

Variable 2-Speed,

Reversible

DDF453SYE

STANDARD EQUIPMENT INCLUDES:

Two 18V (Compact) Li-Ion Batteries

BL1815N (196235-0), Standard Charger (DC18SD), Double Ended Bit 2-65 (784636-0),

Battery Cover (450128-8), 1/2˝ Keyless Drill Chunk (766027-7), Hook (346034-2), Plastic Carrying Case (158777-2)

Compact And Lightweight Design

• 16 Clutch Settings deliver up to 340 in. lbs of torque

• Single Sleeve Keyless Drill Chuck for easy bit installation and removal

• All Metal Gears for more efficient power transmission

• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation

1/2˝ Drill / Driver

SPECIFICATIONS

Battery Capacities 18V Li-Ion

Capacities:

Steel

1/2˝ (13 mm)

Wood

1-7/16˝ (36 mm)

Maximum Torque

340 in. lbs (38 Nm)

No Load Speed:

Low

0 - 400 RPM

High

0 - 1,300 RPM

Overall Length 8-3/4˝ (222 mm)

Net Weight

2.6 lbs (1.2 kg)

Makita offers a wide variety of

ACCESSORIES!

Variable 2-Speed,

Reversible

DHP482SYE

STANDARD EQUIPMENT INCLUDES:

DHP482SYE:

Two 18V (Compact) Li-Ion Batteries

BL1815N (196235-0), Standard Charger (DC18SD), Battery Cover (450128-8),

Hook (346449-3), Double Ended Bit 2-45 (784637-8), 1/2˝Keyless Drill Chuck (766027-7), Plastic Carrying Case (824812-5)

DHP482Z:

Tool Only. Batteries and Charger Sold Separately.

Hook (346449-3), Double Ended Bit 2-45 (784637-8),

1/2˝Keyless Drill Chuck (766027-7)

Incorporates Makita's NEW Battery Protection System

• Battery protection system provides over-discharge, temperature and circuit protection for enhanced

performance, battery cycle life and overall battery life

• eXtreme Protection Technology (XPT) offers maximum

protection against dust, debris and liquids for optimal

performance in extreme conditions

• 21 clutch settings deliver up to 480 in. lbs. of torque

• All metal gears for

more efficient

power transmission

1/2" Hammer Drill / Driver

SPECIFICATIONS

Battery Capacities 18V Li-Ion

Capacities:

Concrete

1/2˝ (13 mm)

Steel

1/2˝ (13 mm)

Wood

1-1/2˝ (38 mm)

No Load Speed:

Low

0 - 600 RPM

High

0 - 1,900 RPM

Blows Per Minute:

Low

0 - 9,000 BPM

High

0 - 28,500 BPM

Maximum Lock Torque

480 in. lbs (54 Nm)

Overall Length 7-3/4˝ (198 mm)

Net Weight

3.5 lbs (1.5kg)

DHP482Z

Variable 2-Speed,

Reversible

Variable 2-Speed,

Reversible

Variable 2-Speed,

Reversible

DDF484RME

STANDARD EQUIPMENT INCLUDES:

DDF484RME:

Two 18V (4.0Ah) Li-Ion Batteries

BL1840B (196401-9), Rapid Charger (DC18RC), Plastic Carrying Case (821532-2),

Battery Cover (450128-8), 1/2˝Keyless Drill Chuck (766027-7), Double Ended Bit 2-45 (784637-8), Hook (346449-3)

DDF484Z:

Tool Only. Batteries and Charger Sold Separately.

1/2˝Keyless Drill Chuck (766027-7),

Double Ended Bit 2-45 (784637-8), Hook (346449-3)

Features Brushless DC Motor

• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for

optimal performance in extreme conditions

• Brushless DC motor with high power to weight and size ratio

• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing /

production applications

1/2˝ Drill / Driver

SPECIFICATIONS

Battery Capacities 18V Li-Ion

Capacities:

Steel

1/2˝ (13 mm)

Wood

1-1/2˝ (38 mm)

No Load Speed:

Low

0 - 500 RPM

High

0 - 2,000 RPM

Maximum Torque

530 in. lbs (60 Nm)

Overall Length 6-3/4˝ (172 mm)

Net Weight

3.9 lbs (1.8 kg)

DDF484Z

Variable 2-Speed,

Reversible
