17 / 180
Cordless
Power Tools
makita.ca17
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
DTW281RME
1/2˝ Impact Wrench
DTW281Z
DTW253RFE
STANDARD EQUIPMENT INCLUDES:
DTW253RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830B (194205-3), Rapid Charger (DC18RC), Battery Cover (450128-8),
Plastic Carrying Case (824753-5)
DTW253Z:
Tool Only. Batteries and Charger Sold Separately.
High Torque To Size / Weight Ratio
• Compact and Lightweight Design (Only 6-1/8˝ Long)
• LED Light with Afterglow feature
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
3/8˝ Square Drive,
Variable Speed,
Reversible
3/8˝ Impact Wrench
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Square Drive
3/8˝ Square
No Load Speed
0 - 2,100 RPM
Impacts Per Minute
0 - 3,200 IPM
Maximum Torque 155 ft. lbs (210 Nm)
Overall Length
6-1/8˝ (155 mm)
Net Weight
3.3 lbs (1.5 kg)
DTW253Z
When
QUALITY & SERVICE
Counts – Choose Makita
DTD170Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3)
Features NEW 'Cam-Out' Elimination Mode and ULTRA-COMPACT DESIGN
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• 4 Stage impact power selection + TEK and 'Cam-Out' modes to ensure precise fastening and
prevent damage to fasteners
• “Cam-out” elimination mode operates at low speed until fastening begins to eliminate “cam-out” and
cross-threading
• TEK mode reduces impact power during final stages of fastener seating
• Battery fuel gauge indicates
approximate remaining
battery power
• Brushless DC motor
generates less heat
buildup and is ideal for
prolonged use in
manufacturing production
applications
1/4˝ Impact Driver
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
1/4˝ Hex
No Load Speed:
0 - 3,600 / 3,200 / 2,100 / 1,100 RPM
Impacts Per Minute:
0 - 3,800 / 3,600 / 2,600 / 1,100 IPM
Maximum Fastening Torque
1,550 in. lbs (175 Nm)
Overall Length
4-5/8˝ (117 mm)
Net Weigh
2.0 lbs (0.9 kg)
DTD154RME
STANDARD EQUIPMENT INCLUDES:
DTD154RTE:
Two 18V (5.0Ah) Li-Ion Batteries
BL1850B (196675-2), Rapid Charger (DC18RC), Battery Cover (450128-8),
Hook (346449-3), Plastic Carrying Case (821532-2)
DTD154RME:
Two 18V (4.0Ah) Li-Ion Batteries
BL1840B (196401-9), Rapid Charger (DC18RC), Battery Cover (450128-8),
Hook (346449-3), Plastic Carrying Case (821532-2)
DTD154Z:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3)
Heavy Duty, ULTRA-COMPACT Design (Just 4-5/8" Long)
and Brushless DC Motor
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• 3 Stage impact power selection + TEK mode prevents over tightening of fasteners
• TEK mode reduces impact power during final stages of fastener seating
• Brushless DC motor generates
less heat buildup and is
ideal for prolonged use in
manufacturing and
production applications
1/4˝ Impact Driver
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
1/4˝ Hex
No Load Speed:
0 - 1,100 / 2,100 / 3,600 RPM
Impacts Per Minute:
0 - 1,100 / 2,600 / 3,800 IPM
Maximum Fastening Torque
1,550 in. lbs (175 Nm)
Overall Length
4-5/8˝ (117 mm)
Net Weight
3.3 lbs (1.5 kg)
DTD154Z
DTD153RME
STANDARD EQUIPMENT INCLUDES:
DTD153RME:
Two 18V (4.0Ah) Li-Ion Batteries
BL1840B (196401-9), Rapid Charger (DC18RC), Battery Cover (450128-8),
Hook (346449-3), Plastic Carrying Case
DTD153SYE:
Two 18V (Compact) Li-Ion Batteries
BL1815N (196235-0), Standard Charger (DC18SD), Battery Cover (450128-8),
Hook (346449-3), Plastic Carrying Case
DTD153Z:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3)
Compact and Lightweight Design with Brushless DC Motor
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing
and production applications
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Battery protection system
provides over-discharge,
temperature and circuit
protection for enhanced
performance, battery
cycle life and overall
battery life
1/4˝ Impact Driver
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
1/4˝ Hex
No Load Speed
0 - 3,400 RPM
Impacts Per Minute
0 - 3,600 IPM
Maximum Fastening Torque
1,500 in. lbs (170 Nm)
Overall Length
5˝ (126 mm)
Net Weight
3.3 lbs (1.5 kg)
DTD153Z
DTD153SYE
Variable 4-Speed,
Reversible
Variable 3-Speed,
Reversible
STANDARD EQUIPMENT INCLUDES:
DTW281RME:
Two 18V (4.0Ah) Li-Ion Batteries
BL1840B (196401-9), Rapid Charger (DC18RC), Hook (346449-3),
Battery Cover (450128-8), Plastic Carrying Case
DTW281Z:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3)
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Square Drive
1/2˝
No Load Speed:
0 - 1,300 / 2,100 / 2,800 RPM
Impacts Per Minute:
0 - 1,800 / 2,800 / 3,500 IPM
Maximum Torque
207 ft.lbs (280 Nm)
Overall Length
5-3/4˝ (147 mm)
Net Weight
4.0 lbs (1.8 kg)
Features Increased Maximum Fastening Torque And Ultra-Compact Design
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• 3 Stage impact power selection prevents over-tightening of fasteners
• Battery fuel gauge indicates approximate remaining battery power
• Brushless DC motor with
high power to weight
and size ratio
1/2˝ Square Drive,
Variable 3-Speed,
Reversible
Variable Speed,
Reversible
DTD154RTE
DTW285RME
1/2˝ Impact Wrench
STANDARD EQUIPMENT INCLUDES:
Two 18V (4.0Ah) Li-Ion Batteries
BL1840B (196401-9), Rapid Charger (DC18RC), Hook (346449-3), Battery Cover (450128-8),
Plastic Carrying Case
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Square Drive
1/2˝
No Load Speed:
0 - 1,600 / 2,100 / 2,800 RPM
Impacts Per Minute:
0 - 1,800 / 2,600 / 3,500 IPM
Maximum Torque
210 ft.lbs (280 Nm)
Overall Length
5-3/4˝ (147 mm)
Net Weight
3.8 lbs (1.7 kg)
Features Increased Maximum Fastening Torque And Ultra-Compact Design
• Auto stop mode stops impact and rotation in 0.2 seconds after fastener is loosened
(when trigger is fully depressed in reverse rotation)
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids
for optimal performance in extreme conditions
• Battery protection system provides over-discharge, temperature and
circuit protection for enhanced performance, battery cycle life
and overall battery life
• 3 stage impact power
selection prevents
over-tightening
of fasteners
1/2˝ Square Drive,
Variable 3-Speed,
Reversible
