Makita General Catalogue

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

Cordless

Power Tools

makita.ca

DHP458RFE

STANDARD EQUIPMENT INCLUDES:

DHP458RFE:

Two18V(3.0Ah)Li-IonBatteries

BL1830B(194205-3),

Rapid Charger(DC18RC),BatteryCover(450128-8),SideHandle(126131-8),TwoDoubleEndedBits(784637-8),BitHolder(452947-8),

StopperPole(122576-8),1/2˝KeylessChuck(766015-4),Hook(346449-3), PlasticCarryingCase(821532-2)

DHP458Z:

Tool Only. Batteries and Charger Sold Separately.

Side Handle (126131-8),Two Double Ended Bits (784637-8),

Bit Holder (452947-8), Stopper Pole (122576-8), 1/2˝Keyless Chuck (766015-4), Hook (346449-3)

High Efficiency, Compact Design

• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids

for optimal performance in extreme conditions

• Independent Battery Fuel Gauge indicates approximate remaining battery power

• Battery Protection System provides Over-Discharge,

Temperature and Circuit Protection for

enhanced performance,

battery cycle life

and overall

battery life

• 21 Clutch Settings

deliver up to 750 in. lbs

of torque

1/2" Hammer Drill / Driver

SPECIFICATIONS

Battery Capacities 18V Li-Ion

Capacities:

Concrete

5/8˝ (16 mm)

Steel

1/2˝ (13 mm)

Wood

2-9/16˝ (65 mm)

No Load Speed:

Low

0 - 400 RPM

High

0 - 1,800 RPM

Blows Per Minute:

Low

0 - 6,000 BPM

High

0 - 27,000 BPM

Maximum Lock Torque

750 in. lbs (84 Nm)

Overall Length 8-7/8˝ (225 mm)

Net Weight

5.3 lbs (2.4 kg)

DHP458Z

Independent Battery

Fuel Gauge,

Variable 2-Speed,

Reversible

DDF458RFE

STANDARD EQUIPMENT INCLUDES:

DDF458RFE:

Two18V(3.0Ah)Li-IonBatteries

BL1830B(194205-3),Rapid Charger(DC18RC),BitHolder(452947-8),SideHandle(126130-0),

TwoDoubleEndedBit2-45(784637-8),BatteryCover(450128-8),1/2˝KeylessChuck(766015-4),Hook(346449-3),PlasticCarryingCase(821532-2)

DDF458Z:

Tool Only. Batteries and Charger Sold Separately.

Side Handle (126130-0),Two Double Ended Bits (784637-8),

Bit Holder (452947-8), 1/2˝Keyless Chuck (766015-4), Hook (346449-3)

High Efficiency, Compact Design

•

eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for

optimal performance in extreme conditions

• Battery Protection System provides Over-Discharge, Temperature and Circuit Protection for enhanced

performance, battery cycle life and overall battery life

• 21 Clutch Settings deliver up to 750 in. lbs of torque

• All Metal Gears for more efficient power transmission

• Dual LED Job

Lights with

Pre-Glow and

Afterglow feature

1/2˝ Drill / Driver

SPECIFICATIONS

Battery Capacities 18V Li-Ion

Capacities:

Steel

1/2˝ (13 mm)

Wood

2-9/16˝ (65 mm)

Maximum Torque

750 in. lbs (84 Nm)

No Load Speed:

Low

0 - 400 RPM

High

0 - 1,800 RPM

Overall Length 8-7/8˝ (225 mm)

Net Weight

5.0 lbs (2.3 Kg)

Variable 2-Speed,

Reversible

DDF458Z

DHP451RFE

STANDARD EQUIPMENT INCLUDES:

DHP451RFE:

Two 18V (3.0Ah) Li-Ion Batteries

BL1830B (194205-3),

Rapid Charger (DC18RC), Battery Cover (450128-8), Side Handle (122750-8),Two Double Ended Bits 2-45 (784637-8),

Stopper Pole (122576-8), 1/2˝ Keyless Chuck (763191-5), Bit Holder (452947-8), Hook (346449-3), Plastic Carrying Case (140354-4)

DHP451Z:

Tool Only. Batteries and Charger Sold Separately.

Side Handle (122750-8),Two Double Ended Bits 2-45 (784637-8), Stopper Pole (122576-8), 1/2˝ Keyless Chuck (763191-5),

Bit Holder (452947-8), Hook (346449-3)

Features 3 Speed RPM Range

•

16 Clutch Settings deliver up to 560 in. lbs of torque

• Three Speed Gearing for more efficiency

• Dual LED Lights with Afterglow feature

• Shift-Lock drive converts from Hammer to Drill to Driver mode

• All Metal Gears for more

efficient power

transmission

1/2" Hammer Drill / Driver

SPECIFICATIONS

Battery Capacities 18V Li-Ion

Capacities:

Steel

1/2˝ (13 mm)

Masonry

5/8˝ (15.8 mm)

Wood

2 - 9/16˝ (65mm)

No Load Speed:

1st Speed

0 - 300 RPM

2nd Speed

0 - 600 RPM

3rd Speed 0 - 1,700 RPM

Blows Per Minute:

1st Speed

0 - 4,500 BPM

2nd Speed 0 - 9,000 BPM

3rd Speed 0 - 25,500 BPM

Maximum Torque

560 in. lbs (63 Nm)

Overall Length 9 - 7/8˝ (250 mm)

Net Weight

5.5 lbs (2.5 kg)

DHP451Z

Variable 3-Speed,

Reversible

When

QUALITY & SERVICE

Counts – Choose Makita

DDF451RFE

STANDARD EQUIPMENT INCLUDES:

Two 18V (3.0Ah) Li-Ion Batteries

BL1830 (194205-3), Rapid Charger (DC18RC), Battery Cover (450128-8), Bit Holder (452947-8),

Side Handle (122749-3), 1/2˝ Keyless Chuck (763191-5),Two Double Ended Bits (784637-8), Hook (346449-3)

Plastic Carrying Case (140354-4)

Features 3 Speed RPM Range

•

16 Clutch Settings deliver up to 560 in. lbs of torque

• Three Speed Gearing for more efficiency

• Dual LED Lights with Afterglow feature

• Shift-Lock drive converts from Hammer to

Drill to Driver mode

• All Metal Gears for more efficient power transmission

1/2˝ Drill / Driver

SPECIFICATIONS

Battery Capacities 18V Li-Ion

Capacities:

Steel

1/2˝ (13 mm)

Wood

2-9/16˝ (65 mm)

No Load Speed:

1st Speed

0 - 300 RPM

2nd Speed

0 - 600 RPM

3rd Speed 0 - 1,700 RPM

Maximum Torque

560 in. lbs (63 Nm)

Overall Length 9-3/8˝ (238 mm)

Net Weight

5.3 lbs (2.4 kg)

Hammer Drill / Driver

STANDARD EQUIPMENT INCLUDES:

DHP481Z:

Tool Only. Batteries and Charger Sold Separately.

Side Handle

(126413-8),Two Double Ended Bits (784637-8), Bit Holder (452947-8),

Stopper Pole (122576-8), 1/2˝Keyless Chuck (766015-4), Hook (346449-3)

DHP481RME:

SameasDHP481Zexceptwith

Two18V(4.0Ah)Li-IonBatteries

BL1840B(196401-9),RapidCharger(DC18RC),PlasticCarryingCase(821524-1)

DHP481RTE:

SameasDHP481Zexceptwith

Two18V(5.0Ah)Li-IonBatteries

BL1850B(196675-2),RapidCharger(DC18RC),PlasticCarryingCase(821524-1)

Drill / Driver

Variable 2-Speed,

Reversible

Features Brushless DC Motor

• eXtreme Protection Technology (XPT) offers

maximum protection against dust, debris and liquids

for optimal performance in extreme conditions

• Battery fuel gauge indicates approximate remaining

battery power

• Brushless DC motor with high power to weight

and size ratio

• Brushless DC motor generates less heat buildup

and is ideal for prolonged use in manufacturing /

production applications

DHP481Z / RME / RTE & DDF481Z / RME / RTE

1/2˝ Hammer Drills / Drivers

PICTURED: DHP481RTE

Hammer

Drill / Driver

DHP481RTE

DHP481Z DHP481RME

DDF481RTE

DDF481Z

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Capacities:

Concrete

5/8˝ (16 mm)

Steel

1/2˝ (13 mm)

Wood

3˝ (76 mm)

No Load Speed

0 - 550 / 0 - 2,100 RPM

Blows Per Min.

0 - 8,250 / 0 - 31,500 BPM

Maximum Lock Torque

1,090 in. lbs (125 Nm)

Overall Length

8-1/8˝ (205 mm)

Net Weight

6.0 lbs (2.7 kg)

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Capacities:

Steel

1/2˝ (13 mm)

Wood

3˝ (76 mm)

No Load Speed 0 - 550 / 0 - 2,100 RPM

Maximum Lock Torque

1,090 in. lbs (125 Nm)

Overall Length

8-1/8˝ (205 mm)

Net Weight

5.7 lbs (2.6 kg)

STANDARD EQUIPMENT INCLUDES:

DDF481Z:

Tool Only. Batteries and Charger Sold Separately.

Side Handle (126412-0),Two Double Ended Bits (784637-8),

Bit Holder (452947-8), 1/2˝ Keyless Chuck (766015-4),

Hook (346449-3)

DDF481RTE:

Same as DDF481Z except with

Two 18V (5.0Ah)

Li-Ion Batteries

BL1850B (196675-2), Rapid Charger (DC18RC),

Plastic Carrying Case (821524-1)

Variable 3-Speed,

Reversible
