ML183
• Ideal where wide illumination is required.
• Great for automotive use, camping and hiking
• BATTERY NOT INCLUDED
Fluorescent Flashlight
SPECIFICATIONS
Battery
ML183
18V Ni-Cd / Ni-MH
ML143
14.4V Ni-Cd / Ni-MH
Continuous Use
up to 280 Minutes
Overall Length
16-1/4˝ (441 mm)
Net Weight
0.9 lbs (0.4 kg)
ML143
ML901
• Ideal where wide illumination is required
• Great for automotive use, camping and hiking
• BATTERY NOT INCLUDED
Fluorescent Flashlight
SPECIFICATIONS
Battery
9.6V Ni-Cd / Ni-MH
Continuous Use
up to 120 Minutes
Overall Length
10˝ (254 mm)
Net Weight
0.1 lbs (0.2 kg)
ML180
• 4 Position Adjustable Head
• BATTERY NOT
INCLUDED
Flashlight
SPECIFICATIONS
Battery
ML180
18V Ni-Cd / Ni-MH
ML140
14.4V Ni-Cd / Ni-MH
ML120
12V Ni-Cd / Ni-MH
ML903
9.6V Ni-Cd / Ni-MH
Continuous Use
up to 270 Minutes
Overall Length
11-5/8˝ (294 mm)
Net Weight
0.7 lbs (0.3 kg)
ML120
ML140
ML903
FLASHLIGHTS & BULBS QUICK REFERENCE CHART
Flashlight
LED Circuit Board
Fluorescent Tube
Incandescent Bulb
Model No.
Battery Type
Voltage
Part No.
Part No.
Part No.
BML360
Li-Ion Slide
36V
-
A-95015
-
DML185 / BML185
18V
-
-
A-90261
DML801 / LXLM03
18V
GM00001284
-
-
DML186 / LXLM01
18V
GM00001187
-
-
DMR050 / LXRM01
18V
SE00000109
-
-
DML807
14.4V / 18V
GM00001465
-
-
DML802 / LXLM04
14.4V / 18V
GM00001213
-
-
DML184 / BML184
14.4V / 18V
-
SM00000050
A-94502
BML145
14.4V
-
-
A-90233
ML103
12V
GM00001493
-
-
ML102
Li-Ion Pod
12V
TE00000122
-
-
LM02
12V
GM00001243
-
-
BML240
Ni-MH Slide
24V
-
-
A-90984
ML902
Ni-Cad or Ni-MH Stick
9.6V
-
-
192545-3
ML702
7.2V
-
-
192242-1
ML183
Ni-Cad or Ni-MH Pod
18V
-
A-90978
-
ML180
18V
-
-
A-90261
ML143
14.4V
-
A-90978
-
ML140
14.4V
-
-
A-90233
ML123
12V
-
A-90978
-
ML120
12V
-
-
A-90233
ML903
9.6V
-
-
192545-3
ML901
9.6V
-
-
192545-3
LM02
• Super Bright LED illuminates work area
• Belt Clip for operator convenience
• Light Weight and Portable Size
• Flexible Legs wrap around cylindrical surfaces or bend to form
convenient stand for illuminating hard to reach locations
• BATTERY NOT INCLUDED
12V Li-Ion LED Flashlight
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Continuous Use
Up to 9 hours
Overall Dimensions (L x W x H) (Light Only)
4-11/16˝ x 2-1/16˝ x 2-3/16˝ (119 mm x 52 mm x 55 mm)
Net Weight
0.4 lbs (0.2 Kg)
ML102
• Can be operated in flashlight (spot or area
illumination) or lantern mode
(360º illumination)
• Push button ON / OFF switch
• Top and bottom hanging hooks allow lantern
to be hung in multiple positions
• Over-discharge circuit protection
prevents damage to battery
caused by over-discharge of cells
• IP54 rated for protection against water,
dust, dirt and debris when used in outdoor
applications or harsh environments
• BATTERY NOT INCLUDED
12V / 7.2V Li-Ion LED Lantern
SPECIFICATIONS
Battery Capacities:
12V MAX (1.3 Ah) Li-Ion
7.2V (1.0 Ah) Li-Ion
Continuous Use up to 5 hours (with battery BL7010)
up to 9 hours (with battery BL1014)
Overall Dimensions (D x H)
2-9/16˝ x 7-1/8˝
Net Weight
0.46 lbs (0.2 kg)
ML103
• Over-discharge protection circuit protects battery against
over-discharge to ensure optimal battery life
• Push button ON / OFF switch
• Soft rubber grip design for comfortable operation
• BATTERY NOT INCLUDED
12V Li-Ion LED Flashlight
SPECIFICATIONS
Battery Capacities
12V MAX CXT Li-Ion
Continuous Use
Approx. 28 Hours (with Battery BL1041B)
Overall Dimensions (L x W x H)
3˝ x 2-1/8˝ x 1-1/8˝ (77 mm x 54 mm x 28 mm)
Net Weight
0.1 lbs. (0.06 kg)
100
Lumens
100
Lumens
