Makita General Catalogue

LITHIUM-ION

makita.ca

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

FD02Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Phillips Bit 2-50 (784244-7), 3/8" Keyless Drill Chuck (763228-8)

Lightweight & Compact With High Operational Efficiency

• 18 Clutch Settings deliver up to 200 in. lbs of torque

• Two Speed Gearing for more efficiency

• Lightweight and Compact Design

• LED Job Light with Afterglow feature

• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation

Variable 2-Speed,

Reversible

3/8˝ Drill / Driver

SPECIFICATIONS

Battery

12V MAX (1.3 Ah) Li-Ion

Capacities:

Steel

3/8˝ (10 mm)

Wood

13/16˝ (21 mm)

Maximum Torque

200 in. lbs (22 Nm)

No Load Speed:

Low

0 - 350 RPM

High

0 - 1,300 RPM

Overall Length

7-7/16˝ (189 mm)

Net Weight

2.2 lbs (1.0 kg)

SH01

STANDARD EQUIPMENT INCLUDES:

SH01:

Two 12V MAX (1.3Ah) Li-Ion Batteries

BL1014 (195332-9), Pod / Stick Charger (DC10WB), 3-3/8˝ Circular Saw Blade 20CT

(A-95021), Hex Wrench 4 (783202-0), Plastic Carrying Case (824961-8)

SH01Z:

Tool Only. Batteries and Charger Sold Separately.

3-3/8˝ Circular Saw Blade 20CT (A-95021), Hex Wrench 4 (783202-0)

Compact And Versatile Design For Flooring, Panelling, Trim And More!

• Battery Protection System shuts tool off when overloaded or when battery capacity is low

• Left and Right Side Lock-Out Button for operator safety

• Blower feature keeps cutting line free of sawdust

• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation

Dust Blower

3-3/8˝ Circular Saw

SPECIFICATIONS

Battery

12V MAX (1.3 Ah) Li-Ion

Blade Diameter

3-3/8˝ (85 mm)

Arbor

9/16˝ (15 mm)

Maximum Cutting Capacities:

0°

1˝ (25.5 mm)

45°

5/8˝ (16.5 mm)

No Load Speed

1,400 RPM

Overall Length

11-3/4˝ (300 mm)

Net Weight

3.3 lbs (1.5 kg)

SH01Z

CC01

STANDARD EQUIPMENT INCLUDES:

CC01:

Two 12V MAX (1.3Ah) Li-Ion Batteries

BL1014 (195332-9), Pod / Stick Charger (DC10WB), 3-3/8˝ Diamond Blade (A-95722),

Hex Wrench 4 (783202-0)

CC01Z:

Tool Only. Batteries and Charger Sold Separately.

3-3/8˝ Diamond Blade (A-95722), Hex Wrench 4 (783202-0)

Specifically Designed For Cutting Glass and Ceramic Tile

• Battery Protection System shuts tool off when overloaded or when

battery capacity is low

• Left and Right Hand Lock-Off Lever for maximum operator safety

• Water Supply Tank (500 mL) features large cap for quick and easy refilling

• Nickel-Plated Base Plate prevents staining and corrosion

• Bevel Capacity of 45°

3-3/8˝ Glass & Tile Circular Saw

SPECIFICATIONS

Battery

12V MAX (1.3 Ah) Li-Ion

Blade Diameter

3-3/8˝ (85 mm)

Arbor

9/16˝ (15 mm)

Maximum Cutting Depths:

0°

1˝ (25.5 mm)

45°

5/8˝ (16.5 mm)

No Load Speed

1,400 RPM

Overall Length

11-3/4˝ (300 mm)

Net Weight

3.7 lbs (1.7 kg)

CC01Z

LCT207

INCLUDES:

• 1/4˝ Drill / Driver (FD01Z)

• 1/4˝ Impact Driver (DT01Z)

•

Two 12V MAX (1.3 Ah)

Li-Ion Batteries

BL1014 (195332-9)

• Pod / Stick Charger (DC10WB)

• Aluminum Carrying Case

(823304-1)

2 Tool Combo Kit

Makita offers a wide variety of

ACCESSORIES!

ML103

• Over-discharge protection circuit protects battery against over-discharge to ensure optimal battery life

• Push button ON / OFF switch

• Soft rubber grip design for comfortable operation

• BATTERY NOT

INCLUDED

12V Li-Ion LED Flashlight

SPECIFICATIONS

Battery Capacities 12V MAX CXT Li-Ion

Continuous Use

Approx. 28 Hours

(with Battery BL1041B)

Overall Dimensions (L x W x H)

3˝ x 2-1/8˝ x 1-1/8˝

(77 mm x 54 mm x 28 mm)

Net Weight

0.1 lbs (0.06 kg)

MR052

Compact Design For

Maximum Portability

• LCD Digital Display with Backlight

• Rubber FM Antenna

• 5 FM / 5 AM Preset Function

• Push Button AM/FM Digital Tuning Feature

• Digital and Manual Tuning Feature

• Digital Volume Control

• Auxilliary Input & Earphone Jack

• Dual Front Speakers produce clear,

high quality sound

Jobsite Radio

SPECIFICATIONS

Battery Capacities 12V MAX CXT Li-Ion

Continuous Run Time

Approx. 30 Hours (with 4.0 Ah BL1041B)

Overall Dimensions (L x W x H)

6-5/8˝ x 2-7/8˝ x 2-15/16˝

(169 mm x 73 mm x 74 mm)

Net Weight

0.8 lbs (0.35 kg)

???

Lumens

ML103
