3/8˝ Impact Wrench
STANDARD EQUIPMENT INCLUDES:
WT01:
Two 12V MAX (1.3Ah) Li-Ion Batteries
BL1014 (195332-9), Pod / Stick Charger (DC10WB), Plastic Carrying Case (141104-0)
WT01Z:
Tool Only. Batteries and Charger Sold Separately.
Compact, Lightweight Impact Power
• 3/8˝ Square Drive ideal for machine bolts, anchors and industrial fasteners
• LED Job Light with Afterglow feature
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Square Drive
3/8˝ Square
No Load Speed
0 - 2,300 RPM
Impacts Per Minute
0 - 3,000 IPM
Maximum Torque 1,000 in. lbs (110 Nm)
Overall Length
6-3/8˝ (163 mm)
Net Weight
2.1 lbs (1.0 kg)
WT01
WT01Z
RJ01
STANDARD EQUIPMENT INCLUDES:
RJ01:
Two 12V MAX (1.3Ah) Li-Ion Batteries
BL1014 (195332-9), Pod / Stick Charger (DC10WB), Blade (1 Ea. B-20432, 1 Ea. 723063-A-5),
Plastic Carrying Case (824993-5)
RJ01Z:
Tool Only. Batteries and Charger Sold Separately.
Blade (1 Ea. B-20432, 1 Ea. 723063-A-5)
Ultra-Compact and Lightweight Design for Maximum
Versatility and Application
• Multi-Position Switch (Tool Handle & Tool Body) with Lock-Off Levers for easier operation,
maximum versatility and operator safety
• Battery Protection System shuts tool off when battery capacity is low
• One-Handed, Fast Tool-Less Blade Changes
• LED Joblight with Pre-Glow feature
• Ergonomic Soft Rubber Grip design for
vibration absorption and
comfortable operation
Reciprocating Saw
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Maximum Cutting Capacities:
Wood
2˝ (50 mm)
Pipe
2˝ (50 mm)
Length of Stroke
1/2˝ (13 mm)
Strokes Per Minute
0 - 3,300 SPM
Overall Length
14˝ (355 mm)
Net Weight
2.6 lbs (1.2 kg)
RJ01Z
VJ01
STANDARD EQUIPMENT INCLUDES:
VJ01:
Two 12V MAX (1.3Ah) Li-Ion Batteries
BL1014 (195332-9), Pod / Stick Charger (DC10WB), Blade (1 Ea. 792529-7),
Hex Wrench 3 (783201-2), Guide Rule (192732-4), Plastic Carrying Case (821508-9)
VJ01Z:
Tool Only. Batteries and Charger Sold Separately.
Blade (5pk-792529-7), Hex Wrench 3 (783201-2)
Compact and Lightweight Design for Maximum Maneuverability
• Variable Speed Trigger Switch
• Battery Protection System shuts tool off when battery capacity is low
• 3 Orbital Settings enable operator to obtain a more aggressive cut
• Blower feature keeps cutting line free of saw dust
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Jig Saw
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Maximum Cutting Capacities:
Wood
2˝ (50 mm)
Pipe
2˝ (50 mm)
Length of Stroke
1/2˝ (13 mm)
Strokes Per Minute
0 - 3,300 SPM
Overall Length
14˝ (355 mm)
Net Weight
2.6 lbs (1.2 kg)
VJ01Z
Variable Speed
AD01
STANDARD EQUIPMENT INCLUDES:
AD01:
Two 12V MAX (1.3Ah) Li-Ion Batteries
BL1014 (195332-9), Pod / Stick Charger (DC10WB), Drill Chuck (766018-8),
Chuck Key (763450-7), Phillips Bit 2-50(784244-7), Plastic Carrying Case (821556-8)
AD01Z:
Tool Only. Batteries and Charger Sold Separately.
Drill Chuck (766018-8), Chuck Key (763450-7), Phillips Bit 2-50 (784244-7)
Compact Design For Optimal Versatility In Confined Spaces
• 2-5/8
˝
Head Height ideal for operation in confined spaces
• Industrial Aluminum gear housing for increased durability
• LED Job Light
• Ergonomic Soft Rubber Grip design with vibration
absorption and comfortable operation
3/8˝ Angle Drill
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Capacities:
Steel
3/8˝ (10 mm)
Wood
1/2˝ (12 mm)
No Load Speed
0 - 800 RPM
Overall Length
11-3/4˝ (298 mm)
Net Weight
2.4 lbs (1.1 kg)
AD01Z
2-5/8˝
Variable Speed,
Reversible
LC01ZX
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Floor NozzleAssembly (122859-6), Pipe (451244-9), Sash Nozzle (451243-1),
Sash Nozzle Holder (451245-7)
Lightweight & Portable Vacuum Cleaner For Shop,
Office Or Home Use
• 2 Stage Nylon and Cloth Filter
• Easy to Empty Dust Canister
• Very Quiet Operation (71 dB)
• On Board Sash Nozzle Storage
600 ml Vacuum Cleaner
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Capacity
1.3 pints (600 ml)
Air Flow
42.4 CFM
Static Water Lift
7.2˝ (18 mb)
Overall length with straight pipe and nozzle
38˝ (966 mm)
Net Weight
1.5 lbs (0.7 kg)
CL105DWX
STANDARD EQUIPMENT INCLUDES:
NozzleAssembly (122859-6), Pipe (451244-9), Sash Nozzle (451243-1), Sash Nozzle Holder (451245-7),
Paper Filter Set 5/Pk (194566-1), Charger (DC1001)
Features Built-In 12V MAX Li-Ion Battery
• Push button air volume selection (low / high / turbo settings)
• Battery capacity warning light indicates ideal time to recharge battery and
completion of charging cycle
• Built-in battery eliminates need to transport and store
additional batteries
• Front cover opens with push button for quick and easy
access to paper filter bag
• On board sash nozzle storage
• Floor nozzle swivel joint design keeps vacuum head
close to surface and enables 360
°
rotation for
easy high-reach cleaning
Vacuum Cleaner
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Capacity
1.1 pints (500 ml)
Air Flow
39.3 CFM
Overall Length With Pipe and Nozzle
38-3/4˝ (983 mm)
Net Weight
2.3 lbs (1.1 kg)
3-Speed
When
QUALITY & SERVICE
Counts – Choose Makita
Variable Speed,
Reversible
