Makita General Catalogue

36 / 180

LITHIUM-ION
36
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing And Assembly
6349DWFE
STANDARD EQUIPMENT INCLUDES:
Two 18V (3.0Ah) Ni-MH Batteries 1835 (193140-2),Charger (DC1804),TwoBatteryCovers (414938-7),1/2˝KeylessDrillChuck (763191-5),
1 Ea. Square Bits (784639-4, 784640-9), Side Handle (122712-6), Plastic Carrying Case (824763-2)
MXT Series Drill (Makita Xtreme Technology)
• 16 Clutch Settings deliver up to 560 in. lbs of torque
• Three Speed Gearing for more efficiency
• Shift-Lock drive converts from Drill to Driver mode
• All Metal Gears for more efficient power transmission
1/2˝ Drill / Driver
SPECIFICATIONS
Battery 18V (3.0 Ah) Ni-MH
Capacities:
Steel 1/2˝ (13 mm)
Wood 2-9/16˝ (65 mm)
No Load Speed:
Low 0 - 300 RPM
Medium 0 - 600 RPM
High 0 - 1,700 RPM
Maximum Torque 560 in. lbs (63 Nm)
Overall Length 9-11/16˝ (246 mm)
Net Weight 5.7 lbs (2.6 kg)
DF010DSE
STANDARD EQUIPMENT INCLUDES:
Two 7.2V (1.0Ah) Li-Ion Batteries BL14302 (194356-2), Charger (DC07SA), Phillips Bit 1-50 (784245-5), Phillips Bit 2-50 (784244-7),
Battery Plastic Case (824781-0), Plastic Carrying Case (158775-6)
High Fastening Clutch Accuracy With 21 Torque Settings
• Auto Stop System indicates battery power reduction and stops operation when battery reaches
minimal capacity in order to prevent incomplete fastening
• Auto Stop Clutch stops motor automatically when clutch is disengaged
• Adjustable Handle with Enhanced Hinge Mechanism for operational versatility
• LED Job Light illuminates work area and features Independent On / Off Switch
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
1/4˝ Drill / Driver
SPECIFICATIONS
Battery 7.2V (1.0 Ah) Li-Ion
Hex Shank 1/4˝ Hex
Capacities:
Steel 3/16˝ (5 mm)
Wood 1/4˝ (6 mm)
No Load Speed:
Low 200 RPM
High 650 RPM
Maximum Torque 50 in. lbs (5.6 Nm)
Net Weight 1.2 lbs (0.6 kg)
Variable 2-Speed,
Reversible
RM01
Compact Design For
Maximum Portability
• LCD Digital Display with Backlight
• FM Telescopic Antenna
• 5 FM / 5 AM Preset Function
• Push Button AM / FM Digital Tuning Feature
• Digital and Manual Tuning Feature
• Digital Volume Control
• Auxilliary Input & Earphone Jack
• Dual Front Speakers produce
clear, high quality sound
Tool Only. Batteries and Charger Sold Separately.
12V / 10.8V Li-Ion Radio
SPECIFICATIONS
Battery Capacities: 10.8V (1.3 Ah) Li-Ion
12V MAX (1.3 Ah) Li-Ion
Continuous Run Time Approx. 2.5 Hours
Overall Dimensions (L x W x H)
6-5/8˝ x 3-1/4˝ x 2-15/16˝
(169 mm x 83 mm x 74 mm)
Net Weight 0.7 lbs (0.3 kg)
HU01Z
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.ShearBladeAssembly (195178-3),BladeCover (195274-7),ChipReceiverSet (195278-9)
Compact Design For Added Versatility
• Dual Blade action cuts quickly with shearing effect
• Chip Receiver prevents material from falling onto blade
• Non-Electrolyzed Nickel Plated Blades reduce staining and rusting
• Battery Capacity Warning Light indicates low battery capacity
• Tool-less Blade Changing System enables simple and easy blade changes
• Left and Right Hand Lock Off Button for added safety
7-7/8˝ Hedge Trimmer
SPECIFICATIONS
Battery 12V MAX (1.3 Ah) Li-Ion
No Load Speed 1,250 SPM
Cutting Width 7-7/8˝ (200 mm)
Maximum Cutting Thickness 5/16˝ (8 mm)
Overall Length 18-1/8˝ (460 mm)
Net Weight 2.2 lbs (1.0 kg)
MU01Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. Shear BladeAssembly (195176-7), Base Frame (325896-1),
Change Lever (451813-6), Blade Cover (452055-5)
Compact Design For Added Versatility
• Dual Blade action cuts quickly with shearing effect
• Non-Electrolyzed Nickel Plated Blades reduce staining and rusting
• Wire Toboggan Style Base Frame enables quick and easy depth adjustment
• Battery Capacity Warning Light indicates low battery capacity
• Tool-less Blade Changing System enables simple and easy blade changes
• Left and Right Hand Lock-Off Button for operator safety
• Ergonomic Soft Rubber Grip design for vibration absorption and
comfortable operation
Dual Blade Action
6-5/16˝ Grass Shear
SPECIFICATIONS
Battery 12V MAX (1.3 Ah) Li-Ion
No Load Speed 1,250 SPM
Cutting Width 6-5/16˝ (160 mm)
Depth Adjustment 3/8˝ / 9/16˝ / 1˝
(10 mm / 15 mm / 25 mm)
Overall Length 11-1/2˝ (292 mm)
Net Weight 2.0 lbs (0.9 kg)
Makita offers a wide variety of ACCESSORIES!
Optional Grass
Shear Attachment
for HU01Z
Grass Shear Blades 195176-7
Grass Shear Cover195269-0
Optional Hedge
Trimmer Attachment
for DUM168Z & MU01Z
Hedge Trimmer Blades 195178-3
Hedge Trimmer Cover195274-7
Dual Blade Action
Chip Receiver Set
(Standard Equipment)
(Part No. 195278-9)
Variable 3-Speed,
Reversible
STANDARD EQUIPMENT INCLUDES:
7.2V (1.5Ah) Li-Ion Battery Batteries BL0715 (198001-1), Pod / Stick Charger (DC10WB), Holster (168435-2),
Phillips Bit 2-50 (784244-7),Tool Bag (831277-4)
1/4˝ Cordless Impact Driver
SPECIFICATIONS
Battery 7.2V (1.5 Ah) Li-Ion
Hex Shank 1/4˝ Hex
Impacts Per Minute 0 - 3,000 IPM
No Load Speed 0 - 2,450 RPM
Maximum Fastening Torque
220 in. lbs (25 Nm)
Capacities:
Machine Screw 1/8˝ - 5/16˝ (M3 - M8)
Standard Bolt 1/8˝ - 5/16˝ (M3 - M8)
High Tensile Bolt 1/8˝ - 1/4˝ (M3 - M6)
Overall Length 11-1/8˝ (282 mm)
Net Weight 1.2 lbs (0.5 kg)
TD022DS
Variable Speed, Reversible,
Electric Brake
Compact And Lightweight Design With Precision Control
And High Fastening Torque
• Multi-function variable speed rotary switch allows operators to adjust driving speed and direction
simultaneously for precise fastening applications
• Switch position enables easy access for left or right handed users
• Lock-off button prevents accidental startup
• Adjustable handle with enhanced hinge mechanism for operational versatility
• LED job light with pre-glow feature
