Makita General Catalogue

makita.ca

166

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

BRUSH CUTTER & CLEARING BLADES

Model No.

EBH253U EBH341U

24.5

33.5

Arbor Size

Model

Description Diameter Arbor Size Teeth

B-14118

4-Point

Blades

4 T

●

385 224 140

10"

20 mm

B-14124

●

195298-3 3-Point

Blade

●

380 224 180

Eddy

Blades

20 mm 8 T

385 224 200

10"

B-14168 Saw Blade 10"

80 T

●

DUR364LZ

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Bump and FeedTrimmer HeadAssembly (197297-1), Safety Goggles (195246-2), Hex Wrench 5 (783217-7), Hex Wrench 4 (783202-0),

Accessory Bag (831304-7), Protector (455622-5)

Powerful trimming for where low noise is a concern

• Brushless motor is located on the trimmer head end to provide ultimate torque for trimming

• XPT (eXtreme Protection Technology) is provided to protect the unit under wet and

dirty conditions for the longest life

• Electronic current limiter for overload protection

• Dual battery fuel gauges for batteries state of charge at a glance

• Soft start feature for added motor protection

• Brushless motor with electronic 2 speed selection

• Reverse switch for easy removal of stuck grass clippings

in the trimmer head

14˝ / 18Vx2 LXT Cordless Line Trimmer

SPECIFICATIONS

Battery

Two 18V Li-Ion

Cutting Width

13-3/4˝ (350 mm)

No Load Speed:

Low

5,000 RPM

High

6,500 RPM

Overall Length

69˝ (175 cm)

Net Weight

8.6 lbs (3.9 kg)

Makita offers a wide variety of

ACCESSORIES!

DUR181Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately

Nylon Cord (195864-6), Bump & Feed Spool Set (195858-1),

Shoulder Harness (125516-5), Safety Cover (453353-0),

Safety Goggles (195246-2)

Well Balanced Design With Fully Adjustable Features To Suit Any Operator

• Adjustable Trimmer Head features 5 angled cutting positions for maximum versatility and ease

of operation when trimming around obstacles

• Telescopic Shaft adjusts quickly and easily to suit any operator

• Lock-Off Safety Lever prevents accidental start up

• Battery Capacity Warning Light indicates low battery capacity

10-1/4˝ / 18V LXT Cordless Line Trimmer

SPECIFICATIONS

Battery Capacities

18V Li-Ion

No Load Speed

7,800 RPM

Cutting Width

10-1/4˝ (260 mm)

Overall Length

56-1/2˝ (143 cm)

Net Weight

5.5 lbs (2.5 kg)

Replacement Nylon

Cutting Line 195864-6 (49')

or 195861-2 (98')

180°

Trimmer Head

rotates 180°

to enable easy

edge trimming

STANDARD EQUIPMENT INCLUDES:

Trimmer Head (DA00000655), Protective Guard (DA00000630), Socket Wrench M5 (DA00000457),Tool Kit (DA00000458),

Spark Plug (965 603 021)

Compliant With EPA Phase 2, EU Stage 2 Exhaust Emissions Regulations

• Multi-positional engine

• Environment-friendly 2-stroke engine with catalytic exhaust

• Equipped with Easy Start system for faster,

easier starting

• Compact trimmer head cover for better view

of cutting area, without losing performance

of preventing grass clippings

to be scattered

• High power output to easily

trim the 16" cutting swath

15-3/4˝ / 25.7 cc 2-Stroke Line Trimmer

SPECIFICATIONS

Cutting Width

15-3/4˝ (400 mm)

Displacement

25.7 cc

Maximum Engine Power

0.83 Kw / 1.11 hp

Carburetor

Diaphragm Type

Fuel / Oil Mixture

50:1

Fuel Tank Capacity

0.6L

Overall Length

64-3/4˝ (164 cm)

Dry Weight

9.5 lbs ( 4.3 kg)

ER2600L

Lightweight yet powerful

2-Stroke trimmer

DUR187LZ

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Bump & FeedTrimmer Head (198385-7), Shoulder Harness (125516-5),

Hex Wrench 4 (783202-0), Hex Wrench 5 (783217-7),Accessory Bag (831304-7), Protective Guard (457324-9)

Lightweight and Powerful with Low Noise Level suitable for use in

Residential Areas and Public Spaces

• Brushless DC Motor for Longer Life / Less Heat / More Run Time & More Work

• XPT (eXtreme Protection Technology) Prevent Debris & Liquids from entering the tool, Expands Tool

Usage to Harsh Environments and Provides Longer Tool Life

• Automatic torque Drive Technology (ADT) Adjusts Motor Speed and Torque during

heavy-Duty cutting for Maximum Efficiency and Performance

• Battery Protection System provides Over-Discharge,Temperature and

Circuit Protection for Enhanced Performance, and Overall Battery Life

11-3/4˝ / 18V LXT Cordless Line Trimmer

SPECIFICATIONS

Battery Capacities

18V Li-Ion

No Load Speed 4,000 / 5,000 / 6,000 RPM

Cutting Width

11-3/4˝ (300 mm)

Overall Length

70-1/2˝ (179.1 cm)

Net Weight

6.0 lbs (2.8 kg)

Brushless / ADT / XPT

Battery Protection System

3 Speed,

Reversible

TRIMMER LINE 15M (TWIST LINE)

Description

Length

Diameter

Part No.

Twist Line

50' (15 m)

0.080" (2 mm)

197472-9

Replacement

Trimmer Line

ideal for

Cordless Line

Trimmers

197472-9

“Twist”

Line
