CC01
STANDARD EQUIPMENT INCLUDES:
CC01:
Two 12V MAX (1.3Ah) Li-Ion Batteries
BL1014 (195332-9), Pod / Stick Charger (DC10WB), 3-3/8˝ Diamond Blade (A-95722),
Hex Wrench 4 (783202-0)
CC01Z:
Tool Only. Batteries and Charger Sold Separately.
3-3/8˝ Diamond Blade (A-95722), Hex Wrench 4 (783202-0)
Specifically Designed For Cutting Glass and Ceramic Tile
• Battery Protection System shuts tool off when overloaded or when
battery capacity is low
• Left and Right Hand Lock-Off Lever for maximum operator safety
• Water Supply Tank (500 mL) features large cap for quick and easy refilling
• Nickel-Plated Base Plate prevents staining and corrosion
• Bevel Capacity of 45°
3-3/8˝ Glass & Tile Circular Saw
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Blade Diameter
3-3/8˝ (85 mm)
Arbor
9/16˝ (15 mm)
Maximum Cutting Depths:
0°
1˝ (25.5 mm)
45°
5/8˝ (16.5 mm)
No Load Speed
1,400 RPM
Overall Length
11-3/4˝ (300 mm)
Net Weight
3.7 lbs (1.7 kg)
CC01Z
Makita offers a wide variety of
ACCESSORIES!
ML103
• Over-discharge protection circuit protects battery against over-discharge to ensure optimal battery life
• Push button ON / OFF switch
• Soft rubber grip design for comfortable operation
• BATTERY NOT
INCLUDED
12V Li-Ion LED Flashlight
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Continuous Use
Approx. 28 Hours
(with Battery BL1041B)
Overall Dimensions (L x W x H)
3˝ x 2-1/8˝ x 1-1/8˝
(77 mm x 54 mm x 28 mm)
Net Weight
0.1 lbs (0.06 kg)
MR052
Compact Design For
Maximum Portability
• LCD Digital Display with Backlight
• Rubber FM Antenna
• 5 FM / 5 AM Preset Function
• Push Button AM/FM Digital Tuning Feature
• Digital and Manual Tuning Feature
• Digital Volume Control
• Auxilliary Input & Earphone Jack
• Dual Front Speakers produce clear,
high quality sound
Jobsite Radio
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Continuous Run Time
Approx. 30 Hours (with 4.0 Ah BL1041B)
Overall Dimensions (L x W x H)
6-5/8˝ x 2-7/8˝ x 2-15/16˝
(169 mm x 73 mm x 74 mm)
Net Weight
0.8 lbs (0.35 kg)
100
Lumens
ML103
CL106FDZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
NozzleAssembly (123488-8), Sash Nozzle (451243-1), Pipe (451244-9),
Sash Nozzle Holder (451245-7), Cloth Filter (443060-3), Nylon Pre-Filter (451208-3)
Easy To Empty Dust & Debris Collection
Canister Minimizes Downtime &
Maximizes Vacuuming Efficiency
• LED job light illuminates cleaning area
• 2-stage Nylon and Cloth filter
• On board Sash Nozzle Storage
• Floor Nozzle Swivel Joint design keeps
vacuum head close to surface and enables
360º rotation for easy high-reach cleaning
Vacuum Cleaner (600 ml)
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Container Capacity
600 ml (20.2 oz)
Continuous Use
Approx. 42 minutes with BL1041B
Maximum Air Flow
45.9 CFM
Power
19 W
Static Water Lift
12-1/2˝ (31 cm)
Overall Length
37-3/4˝ (95 cm)
Net Weight
2.0 lbs (0.9 kg)
Includes LED Job Light
UH201DZ
12V MAX CXT Slide
STANDARD EQUIPMENT INCLUDES:
UH201DZ:
ToolOnly.BatteriesandChargerSoldSeparately.
ShearBladeAssemblySet (198409-9),BladeCover (195274-7),ChipReceiverSet (198402-3)
HU01Z:
ToolOnly.BatteriesandChargerSoldSeparately.
ShearBladeAssembly (195178-3),BladeCover (195274-7),ChipReceiverSet (195278-9)
Compact Design For Added Versatility
• Dual Blade action cuts quickly with shearing effect
• Chip Receiver prevents material from falling onto blade
• Non-Electrolyzed Nickel Plated Blades reduce staining and rusting
• Tool-less Blade Changing System enables simple and easy blade changes
7-7/8˝ Hedge Trimmers
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
No Load Speed
2,500 SPM
Cutting Length
7-7/8˝ (200 mm)
Maximum Cutting Thickness 5/16˝ (8 mm)
Overall Length
19-7/8˝ (504 mm)
Net Weight
2.5 lbs (1.1 kg)
Optional Grass
Shear Attachment
for UH201DZ or HU01Z
Shear BladeAssembly
195176-7
Blade Cover
452055-5
Grass Catcher
457426-1
Chip Receiver Set
(Standard Equipment)
(Part No. 198402-3)
HU01Z
12V MAX (1.3 Ah) Pod
UH201DZ
UH201DZ:
12V MAX CXT Slide
HU01Z:
12V MAX (1.3 Ah) Pod
HU01Z
UM600DZ
12V MAX CXT Slide
STANDARD EQUIPMENT INCLUDES:
UM600DZ:
ToolOnly.BatteriesandChargerSoldSeparately.
ShearBladeAssembly (195176-7),BladeCover (452055-5),GrassCatcher (457426-1)
MU01Z:
Tool Only. Batteries and Charger Sold Separately.
Shear BladeAssembly (195176-7), Base Frame (325896-1),
Change Lever (451813-6), Blade Cover (452055-5)
Compact Design For Added Versatility
• Dual Blade action cuts quickly with shearing effect
• Non-Electrolyzed Nickel Plated Blades reduce staining and rusting
• Grass Catcher enables quick and easy depth adjustment
• Tool-less Blade Changing System enables simple and easy blade changes
6-5/16˝ / 12V LXT Cordless Grass Shears
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
No Load Speed
2,500 SPM
Cutting Width
6-5/16˝ (160 mm)
Depth Adjustment
5/8˝ / 13/16˝ / 1˝
(15 mm / 20 mm / 25 mm)
Overall Length
13-5/8˝ (347 mm)
Net Weight
2.5 lbs (1.1 kg)
Optional Hedge
Trimmer Attachment
for UM600DZ or MU01Z
Shear BladeAssembly
198409-9
Chip Receiver Set
198402-3
Blade Cover
195274-7
MU01Z
12V MAX (1.3 Ah) Pod
UM600DZ
UM600DZ:
12V MAX CXT Slide
MU01Z:
12V MAX (1.3 Ah) Pod
MU01Z
