Makita General Catalogue

Cordless

Power Tools

makita.ca

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

3/8˝ Impact Wrench

STANDARD EQUIPMENT INCLUDES:

WT01:

Two 12V MAX (1.3Ah) Li-Ion Batteries

BL1014 (195332-9), Pod / Stick Charger (DC10WB), Plastic Carrying Case (141104-0)

WT01Z:

Tool Only. Batteries and Charger Sold Separately.

Compact, Lightweight Impact Power

• 3/8˝ Square Drive ideal for machine bolts, anchors and industrial fasteners

• LED Job Light with Afterglow feature

• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation

SPECIFICATIONS

Battery

12V MAX (1.3 Ah) Li-Ion

Square Drive

3/8˝ Square

No Load Speed

0 - 2,300 RPM

Impacts Per Minute

0 - 3,000 IPM

Maximum Torque 1,000 in. lbs (110 Nm)

Overall Length

6-3/8˝ (163 mm)

Net Weight

2.1 lbs (1.0 kg)

WT01

WT01Z

RJ01

STANDARD EQUIPMENT INCLUDES:

RJ01:

Two 12V MAX (1.3Ah) Li-Ion Batteries

BL1014 (195332-9), Pod / Stick Charger (DC10WB),

Blade (1 Ea. B-20432, 1 Ea. 723063-A-5), Plastic Carrying Case (824993-5)

RJ01Z:

Tool Only. Batteries and Charger Sold Separately.

Blade (1 Ea. B-20432, 1 Ea. 723063-A-5)

Ultra-Compact and Lightweight Design for Maximum

Versatility and Application

• Multi-Position Switch (Tool Handle & Tool Body) with Lock-Off Levers for easier operation,

maximum versatility and operator safety

• Battery Protection System shuts tool off when battery capacity is low

• One-Handed, Fast Tool-Less Blade Changes

• LED Joblight with Pre-Glow feature

• Ergonomic Soft Rubber Grip design for

vibration absorption and

comfortable operation

Reciprocating Saw

SPECIFICATIONS

Battery

12V MAX (1.3 Ah) Li-Ion

Maximum Cutting Capacities:

Wood

2˝ (50 mm)

Pipe

2˝ (50 mm)

Length of Stroke

1/2˝ (13 mm)

Strokes Per Minute

0 - 3,300 SPM

Overall Length

14˝ (355 mm)

Net Weight

2.6 lbs (1.2 kg)

RJ01Z

VJ01

STANDARD EQUIPMENT INCLUDES:

VJ01:

Two 12V MAX (1.3Ah) Li-Ion Batteries

BL1014 (195332-9), Pod / Stick Charger (DC10WB), Blade (1 Ea. 792529-7),

Hex Wrench 3 (783201-2), Guide Rule (192732-4), Plastic Carrying Case (821508-9)

VJ01Z:

Tool Only. Batteries and Charger Sold Separately.

Blade (5pk-792529-7), Hex Wrench 3 (783201-2)

Compact and Lightweight Design for Maximum Maneuverability

• Variable Speed Trigger Switch

• Battery Protection System shuts tool off when battery capacity is low

• 3 Orbital Settings enable operator to obtain a more aggressive cut

• Blower feature keeps cutting line free of saw dust

• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation

Jig Saw

SPECIFICATIONS

Battery

12V MAX (1.3 Ah) Li-Ion

Maximum Cutting Capacities:

Wood

2˝ (50 mm)

Pipe

2˝ (50 mm)

Length of Stroke

1/2˝ (13 mm)

Strokes Per Minute

0 - 3,300 SPM

Overall Length

14˝ (355 mm)

Net Weight

2.6 lbs (1.2 kg)

VJ01Z

Variable Speed

AD01

STANDARD EQUIPMENT INCLUDES:

AD01:

Two 12V MAX (1.3Ah) Li-Ion Batteries

BL1014 (195332-9), Pod / Stick Charger (DC10WB), Drill Chuck (766018-8),

Chuck Key (763450-7), Phillips Bit 2-50(784244-7), Plastic Carrying Case (821556-8)

AD01Z:

Tool Only. Batteries and Charger Sold Separately.

Drill Chuck (766018-8), Chuck Key (763450-7), Phillips Bit 2-50 (784244-7)

Compact Design For Optimal Versatility In Confined Spaces

• 2-5/8

Head Height ideal for operation in confined spaces

• Industrial Aluminum gear housing for increased durability

• LED Job Light

• Ergonomic Soft Rubber Grip design with vibration

absorption and comfortable operation

3/8˝ Angle Drill

SPECIFICATIONS

Battery

12V MAX (1.3 Ah) Li-Ion

Capacities:

Steel

3/8˝ (10 mm)

Wood

1/2˝ (12 mm)

No Load Speed

0 - 800 RPM

Overall Length

11-3/4˝ (298 mm)

Net Weight

2.4 lbs (1.1 kg)

AD01Z

2-5/8˝

Variable Speed,

Reversible

When

QUALITY & SERVICE

Counts – Choose Makita

FD02Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Phillips Bit 2-50 (784244-7), 3/8" Keyless Drill Chuck (763228-8)

Lightweight & Compact With High Operational Efficiency

• 18 Clutch Settings deliver up to 200 in. lbs of torque

• Two Speed Gearing for more efficiency

• Lightweight and Compact Design

• LED Job Light with Afterglow feature

• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation

Variable 2-Speed,

Reversible

3/8˝ Drill / Driver

SPECIFICATIONS

Battery

12V MAX (1.3 Ah) Li-Ion

Capacities:

Steel

3/8˝ (10 mm)

Wood

13/16˝ (21 mm)

Maximum Torque

200 in. lbs (22 Nm)

No Load Speed:

Low

0 - 350 RPM

High

0 - 1,300 RPM

Overall Length

7-7/16˝ (189 mm)

Net Weight

2.2 lbs (1.0 kg)

SH01

STANDARD EQUIPMENT INCLUDES:

Two 12V MAX (1.3Ah) Li-Ion Batteries

BL1014 (195332-9), Pod / Stick Charger (DC10WB), 3-3/8˝ Circular Saw Blade 20CT (A-95021),

Hex Wrench 4 (783202-0), Plastic Carrying Case (824961-8)

Compact And Versatile Design For Flooring, Panelling, Trim And More!

• Battery Protection System shuts tool off when overloaded or when battery capacity is low

• Left and Right Side Lock-Out Button for operator safety

• Blower feature keeps cutting line free of sawdust

• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation

Dust Blower

3-3/8˝ Circular Saw

SPECIFICATIONS

Battery

12V MAX (1.3 Ah) Li-Ion

Blade Diameter

3-3/8˝ (85 mm)

Arbor

9/16˝ (15 mm)

Maximum Cutting Capacities:

0°

1˝ (25.5 mm)

45°

5/8˝ (16.5 mm)

No Load Speed

1,400 RPM

Overall Length

11-3/4˝ (300 mm)

Net Weight

3.3 lbs (1.5 kg)

Variable Speed,

Reversible
