DF010DSE
STANDARD EQUIPMENT INCLUDES:
Two 7.2V (1.0Ah) Li-Ion Batteries
BL14302 (194356-2), Charger (DC07SA), Phillips Bit 1-50 (784245-5), Phillips Bit 2-50 (784244-7),
Battery Plastic Case (824781-0), Plastic Carrying Case (158775-6)
High Fastening Clutch Accuracy With 21 Torque Settings
• Auto Stop System indicates battery power reduction and stops operation when battery reaches
minimal capacity in order to prevent incomplete fastening
• Auto Stop Clutch stops motor automatically when clutch is disengaged
• Adjustable Handle with Enhanced Hinge Mechanism for operational versatility
• LED Job Light illuminates work area and features Independent On / Off Switch
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
1/4˝ Driver / Drill
SPECIFICATIONS
Battery
7.2V (1.0 Ah) Li-Ion
Hex Shank
1/4˝ Hex (6.35 mm)
Capacities:
Steel
3/16˝ (5 mm)
Wood
1/4˝ (6 mm)
No Load Speed:
Low
200 RPM
High
650 RPM
Maximum Torque
50 in. lbs (5.6 Nm)
Net Weight
1.2 lbs (0.6 kg)
Variable 2-Speed,
Reversible
RM01
Compact Design For
Maximum Portability
• LCD Digital Display with Backlight
• FM Telescopic Antenna
• 5 FM / 5 AM Preset Function
• Push Button AM / FM Digital Tuning Feature
• Digital and Manual Tuning Feature
• Digital Volume Control
• Auxilliary Input & Earphone Jack
• Dual Front Speakers produce
clear, high quality sound
Tool Only. Batteries and Charger Sold Separately.
12V / 10.8V Li-Ion Radio
SPECIFICATIONS
Battery Capacities: 10.8V (1.3 Ah) Li-Ion
12V MAX (1.3 Ah) Li-Ion
Continuous Run Time Approx. 2.5 Hours
Overall Dimensions (L x W x H)
6-5/8˝ x 3-1/4˝ x 2-15/16˝
(169 mm x 83 mm x 74 mm)
Net Weight
0.7 lbs (0.3 kg)
Makita offers a wide variety of
ACCESSORIES!
STANDARD EQUIPMENT INCLUDES:
7.2V (1.5Ah) Li-Ion Battery
BL0715 (198001-1), Pod / Stick Charger (DC10WB), Holster (168435-2),
Phillips Bit 2-50 (784244-7),Tool Bag (831277-4)
1/4˝ Cordless Impact Driver
SPECIFICATIONS
Battery
7.2V (1.5 Ah) Li-Ion
Hex Shank
1/4˝ Hex (6.35 mm)
Impacts Per Minute
0 - 3,000 IPM
No Load Speed
0 - 2,450 RPM
Maximum Fastening Torque
220 in. lbs (25 Nm)
Capacities:
Machine Screw 1/8˝ - 5/16˝ (M3 - M8)
Standard Bolt
1/8˝ - 5/16˝ (M3 - M8)
High Tensile Bolt 1/8˝ - 1/4˝ (M3 - M6)
Overall Length
11-1/8˝ (282 mm)
Net Weight
1.2 lbs (0.5 kg)
TD022DS
Variable Speed, Reversible,
Electric Brake
Compact And Lightweight Design With Precision Control
And High Fastening Torque
• Multi-function variable speed rotary switch allows operators to adjust driving speed and direction
simultaneously for precise fastening applications
• Switch position enables easy access for left or right handed users
• Lock-off button prevents accidental startup
• Adjustable handle with enhanced hinge mechanism for operational versatility
• LED job light with pre-glow feature
DF012DSE
STANDARD EQUIPMENT INCLUDES:
Two 7.2V (1.5Ah) Li-Ion Batteries
BL0715 (198001-1), Charger (DC10WB), Phillips Bit 1-50 (784245-5), Phillips Bit 2-50 (784244-7),
Battery Plastic Case (824781-0), Plastic Carrying Case (158775-6)
Compact And Lightweight Design With Precision Control
• Auto stop system indicates battery power reduction and stops operation when battery reaches minimal
capacity in order to prevent incomplete fastening
• Auto stop clutch stops motor automatically when clutch is disengaged
• Adjustable handle with enhanced hinge mechanism for operational versatility
• Locking feature prevents accidental start up and enables use as a hand-held screwdriver
• LED job light illuminates work area and features independent on/off switch
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
1/4˝ Driver / Drill
SPECIFICATIONS
Battery
7.2V (1.5 Ah) Li-Ion
Hex Shank
1/4˝ Hex (6.35 mm)
Capacities:
Steel
3/16˝ (5 mm)
Wood
1/4˝ (6 mm)
No Load Speed:
Low
0 - 200 RPM
High
0 - 650 RPM
Maximum Torque
71 in. lbs (8.0 Nm)
Net Weight
0.9 lbs (0.4 kg)
Variable 2-Speed,
Reversible
CL105DWX
STANDARD EQUIPMENT INCLUDES:
NozzleAssembly (122859-6), Pipe (451244-9),
Sash Nozzle (451243-1), Sash Nozzle Holder (451245-7),
Paper Filter Set 5/Pk (194566-1), Charger (DC1001)
Features Built-In 12V MAX Li-Ion Battery
• Push Button Air Volume Selection
(High / Low / Turbo Settings)
• Battery Capacity Warning Light indicates ideal
time to recharge battery and completion
of charging cycle
• Built-in Battery eliminates need to transport
and store additional batteries
• Front Cover opens with Push Button for
quick and easy access to paper filter bag
• On board Sash Nozzle Storage
• Floor Nozzle Swivel Joint design
keeps vacuum head close to
surface and enables 360º rotation
for easy high-reach cleaning
Vacuum Cleaner (500 ml)
SPECIFICATIONS
Battery Capacities12V MAX (1.3 Ah) Li-Ion
Container Capacity
500 ml (16.9 oz)
Charging Time
Approx. 180 minutes with DC1001
Continuous Use:
Approx. 7 minutes (3rd Speed)
Approx. 10 minutes (2nd Speed)
Approx. 20 minutes (1st Speed)
Maximum Air Flow
39.3 CFM
Power:
20 W (3rd Speed)
14 W (2nd Speed)
5 W (1st Speed)
Static Water Lift
13˝ (34 cm)
Overall Length
38-3/4˝ (98 cm)
Net Weight
2.3 lbs (1.1 kg)
3-Speed
High Speed Setting
attainable by continuously
holding the Speed Selector
LC01ZX
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Floor NozzleAssembly (122859-6), Pipe (451244-9), Sash Nozzle (451243-1),
Sash Nozzle Holder (451245-7)
Lightweight & Portable Vacuum Cleaner For Shop,
Office Or Home Use
• 2 Stage Nylon and Cloth Filter
• Easy to Empty Dust Canister
• Very Quiet Operation (71 dB)
• On Board Sash Nozzle Storage
Vacuum Cleaner (600 ml )
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Capacity
600 ml
Air Flow
42.4 CFM
Static Water Lift
7.2˝ (18 mb)
Overall length with straight pipe and nozzle
38˝ (966 mm)
Net Weight
1.5 lbs (0.7 kg)
