Makita General Catalogue

37 / 182

Cordless Power Tools
37
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
ManufacturingAnd Assembly
6349DWFE
STANDARD EQUIPMENT INCLUDES:
Two 18V (3.0Ah) Ni-MH Batteries 1835 (193140-2), Charger (DC1804),Two Battery Covers (414938-7), 1/2˝ Keyless Drill Chuck (763191-5),
1 Ea. Square Bits (784639-4, 784640-9), Side Handle (122712-6), Plastic Carrying Case (824763-2)
MXT Series Drill (Makita Xtreme Technology)
• 16 Clutch Settings deliver up to 560 in. lbs of torque
• Three Speed Gearing for more efficiency
• Shift-Lock drive converts from Drill to Driver mode
• All Metal Gears for more efficient power transmission
1/2˝ Drill / Driver
SPECIFICATIONS
Battery 18V (3.0 Ah) Ni-MH
Capacities:
Steel 1/2˝ (13 mm)
Wood 2-9/16˝ (65 mm)
No Load Speed:
Low 0 - 300 RPM
Medium 0 - 600 RPM
High 0 - 1,700 RPM
Maximum Torque 560 in. lbs (63 Nm)
Overall Length 9-11/16˝ (246 mm)
Net Weight 5.7 lbs (2.6 kg)
When QUALITY & SERVICE Counts – Choose Makita
6261DWPE
STANDARD EQUIPMENT INCLUDES:
Two 9.6V (1.3Ah) Ni-Cad Batteries PA09 (638344-4-2), Charger (DC1804),Two Battery Covers (414938-7),
3/8˝ Keyless Drill Chuck (196309-7), Phillips Bit 2- 65 (784636-0), Plastic Carrying Case (824852-3)
Versatile, General Purpose Drill / Driver
• 16 Clutch Settings deliver up to 200 in. lbs of torque
• All Metal Gears for more efficient power transmission
• Compact Design with a reduced body length of only 7-9/16˝
• Single Sleeve Keyless Drill Chuck for easy bit installation and removal
3/8˝ Drill / Driver
SPECIFICATIONS
Battery 9.6V (1.3 Ah) Ni-Cad
Capacities:
Steel 3/8˝ (10 mm)
Wood 13/16˝ (21 mm)
No Load Speed:
Low 0 - 400 RPM
High 0 - 1,300 RPM
Maximum Torque 200 in. lbs (23 Nm)
Overall Length 7-9/16˝ (192 mm)
Net Weight 3.3 lbs (1.5 kg)
DF001DW
STANDARD EQUIPMENT INCLUDES:
Plastic Carrying Case, USB Cable (661750-8),
ACAdapterADP07 (630A41-4), 81 Pc Bit Case Set
Features Built-In 3.6V (1.5 Ah)
Li-Ion Battery
Includes 81 Piece Accessory Set
• Adjustable hinged handle enables easy straight
or pistol style operation
• LED job light with Independent On / Off Switch
illuminates work area
• Built-in battery eliminates need to transport
and store additional batteries
• Includes AC charging adapter with
micro-USB connector
• Accessory set includes: magnetic bit holder,
nutsetters 3/16˝ , 1/4˝, 9/32˝, 5/16˝ , 11/32˝, 3/8˝
2" driver bits PH1, PH2, PH3, T20, T25, T30
1" insert bits: SQ0 (3), SQ1 (3), SQ2 (3), SQ3 (3)
PH0 (3), PH1 (3), PH2 (3), PH3 (3), T10 (2),
T15 (2) T20 (3), T25 (3), T27 (2), T30 (3),
T40 (2) PZ0 (1), PZ1 (2), PZ2 (2), PZ3 (1),
Hex 3/32˝ (2) 1/8˝ (2), 5/32˝ (2), 3/16˝ (2),
1/4˝ (2), 5/64˝ (2) SL4-5 (3), SL6-8 (3),
SL10-12 (3)
1/4˝ Screwdriver
SPECIFICATIONS
Battery 3.6V (1.5 Ah) Li-Ion
Hex Shank 1/4˝ (6.35 mm)
No Load Speed 220 RPM
Maximum Torque 53 in. lbs (6.0 Nm)
Overall Length 11-1/4˝ (287 mm)
Net Weight 0.8 lbs (0.36 kg)
6281DWPE
STANDARD EQUIPMENT INCLUDES:
Two 14.4V (1.3Ah) Ni-Cad Batteries PA14 (193987-4), Charger (DC1804),Two Battery Covers (414938-7),
3/8˝ Keyless Drill Chuck (196309-7), Phillips Bit 2-65 (784636-0), Plastic Carrying Case (824852-3)
Versatile, General Purpose Drill / Driver
• 16 Clutch Settings deliver up to 260 in. lbs of torque
• All Metal Gears for more efficient power transmission
• Compact Design with a reduced body length of only 7-9/16˝
• Single Sleeve Keyless Drill Chuck for easy bit installation and removal
3/8˝ Drill / Driver
SPECIFICATIONS
Battery 14.4V (1.3 Ah) Ni-Cad
Capacities:
Steel 3/8˝ (10 mm)
Wood 1˝ (25 mm)
No Load Speed:
Low 0 - 400 RPM
High 0 - 1,300 RPM
Maximum Torque 260 in. lbs (30 Nm)
Overall Length 7-9/16˝ (192 mm)
Net Weight 3.3 lbs (1.5 kg)
6391DWPE
STANDARD EQUIPMENT INCLUDES:
Two 18V (1.3Ah) Ni-Cad Batteries PA18 (194227-3, 2 / Pk), Charger (DC1804),Two Battery Covers (414938-7),
1/2˝ Keyless Drill Chuck (766027-7), Phillips Bit 2-65 (784636-0), Plastic Carrying Case (824853-1)
Versatile, General Purpose Drill / Driver
• 16 Clutch Settings deliver up to 340 in. lbs of torque
• All Metal Gears for more efficient power transmission
• Compact design with a reduced body length of only 8-3/8˝
• Single Sleeve Keyless Drill Chuck for easy bit installation and removal
1/2˝ Drill / Driver
SPECIFICATIONS
Battery 18V (1.3 Ah) Ni-Cad
Capacities:
Steel 1/2˝ (13 mm)
Wood 1-7/16˝ (36 mm)
No Load Speed:
Low 0 - 400 RPM
High 0 - 1,300 RPM
Maximum Torque 340 in. lbs (38 Nm)
Overall Length 8-3/4˝ (223 mm)
Net Weight 4.4 lbs (2.0 kg)
8391DWPE
STANDARD EQUIPMENT INCLUDES:
Two 18V (1.3Ah) Ni-Cad Batteries PA18 (194227-3, 2 / Pk), Charger (DC1804), Battery Cover (414938-7),
1/2˝ Keyless Drill Chuck (766027-7), Double Ended Bit (784636-0), Plastic Carrying Case (824853-1)
Single Sleeve 1/2˝ Keyless Chuck With Shaft Lock
• 16 Clutch Settings deliver up to 340 in. lbs of torque
• All Metal Gears for more efficient power transmission
• Compact Design with a reduced body length of only 9-1/2˝
• Single Sleeve Keyless Drill Chuck for easy bit installation and removal
1/2˝ Hammer Drill / Driver
SPECIFICATIONS
Battery 18V (1.3 Ah) Ni-Cad
Capacities:
Concrete 1/2˝ (13 mm)
Steel 1/2˝ (13 mm)
Wood 1-7/16˝ (36 mm)
No Load Speed:
Low 0 - 400 RPM
High 0 - 1,300 RPM
Blows Per Minute:
Low 0 - 6,000 BPM
High 0 - 19,500 BPM
Maximum Torque 340 in. lbs (38 Nm)
Overall Length 9-1/2˝ (241 mm)
Net Weight 4.6 lbs (2.1 kg)
Variable 3-Speed,
Reversible
Variable 2-Speed,
Reversible
Variable 2-Speed,
Reversible
Variable 2-Speed,
Reversible Variable 2-Speed,
Reversible
Reversible
