When QUALITY Counts - ChooseMakita
Outdoor
Power Equipment
2-
S
TROKE
POWER
•
All Makita 2-stroke engines are compliant with CARB tier 3, EPA phase 2 and EU stage 2 government regulations.
•
Select Makita 2-stroke engines feature a catalytic converter for cleaner emissions. Some models also include a
Scavenging Losses Rejection (SLR) muffler system which recycles unburnt gas through the exhaust
increasing operational efficiency and producing much cleaner emissions.
•
Many of Makita’s 2-stroke engines offer a decompression button for easy starting.
•
All Makita 2-stroke engines require the use of synthetic engine oil with fuel stabilizer for long engine life.
•
Automatic decompression valve to reduce required start
up force by 40% for easy starting
•
No fuel / oil mixing for cleaner exhaust emissions and
reduced fuel consumption
•
Primer bulb and choke for easy starting
•
Compliant with CARB tier 3, EPA phase 2, EU stage
2 emissions requirements which exceeds government
clean air emission ratings
•
Low noise levels for quiet operation
•
Easy access to spark plug and air filter for fast service
•
Lightweight design for operational comfort
•
Diaphragm type carburetor for all position operation
•
Electronic ignition system
for reliable performance
The patented oil lubrication system expands
the use of the MM4 engines into product
lines such as brush cutters and line trimmers
where traditional 4-Stroke engines have
difficulty operating on slopes and angles.
The natural pressure changes in the
crankcase caused by the piston movement
in the cylinder are harnessed to pump oil
throughout the engine. Oil is pumped from a
reservoir in the base of the engine through
a network of one-way valves for reliable
lubrication and long service life without the
need to keep the engine level.
4-
S
TROKE
POWER
ELECTRIC
POWER
Compared with conventional
4-stroke engines, Makita’s
4-stroke engines produce approximately 20 to 30 %
more power thanks to its high combustion efficiency
and compact spark plug.
Additionally, by employing a unique lubrication system,
it has obtained the smallest in class exterior physical
dimensions among the 4-stroke engines available in the
market today. And it is also lightest in class by using a
magnesium alloy diecast for the clutch case.
Patented unique lubrication
system enables use in multiple positions
All Makita MM4 engines feature:
New compact plug
High-silicone
aluminum
alloy piston
Double element
with filter
and sponge
Oil separator
Needle bearing on both
ends of connecting rod
Check ball
Valve system
Hard chrome
plating on
cylinder
Sintered
cam gear
Decompression
system:
The force required to
pull the starter rope
is drastically reduced
by the
mechanical
decompression
system
that features
our original centrifugal
structure in the
cam gear.
Makita offers many outdoor power tools with electric motors.
Electric motors are an environmentally friendly alternative to fuel
based engines. Electric motor driven equipment can be stored in the off-season with little to no preparation.
Many of Makita’s electric outdoor tools offer a soft start feature and current limiters to protect the motor
from premature burnout, extending the life of your equipment.
