106 / 220
SAWS
makita.ca
104
STANDARD EQUIPMENT INCLUDES:
DepthAdjustment Knob (158980-5), 1/4" Collet Sleeve (763803-0), 1/2" Collet Cone (763622-4), Wrench 24 (781030-7)
Trigger Switch with Lock-On and Lock-Off Features
• Electronic Speed Control maintains constant speed under heavy load
• Labyrinth Retainers and Fan prevent contamination of motor
• Plunge Depth can be adjusted from the bottom of the router when mounted in a router table
• 3 Stage Depth Adjustments ideal for use when performing deep or repetitive cutting operations
• Dual LED Job Lights with Afterglow
• Sub-Base accepts industry standard template guides
• Can be used with 55" (194368-5) or 118" (194367-7) Guide Rails and Router Guide Rail Adapter (194579-2)
for precision routing applications
Electronic Speed Control,
Electric Brake, Variable Speed
3-1/2 HP Plunge Router
SPECIFICATIONS
Collet Capacity
1/2" (12.7 mm)
Plunge Capacity
2-3/4" (70 mm)
No Load Speed
9,000 - 22,000 RPM
AMPS (120V)
15.0 A
Base Diameter
6-11/16" (170 mm)
Overall Height
12-1/4" (312 mm)
Net Weight
13.4 lbs (6.1 kg)
RP2301FC
STANDARD EQUIPMENT INCLUDES:
DepthAdjustment Knob (158980-5), 1/4" Collet Sleeve (763803-0), 1/2" Collet Cone (763622-4), Wrench 24 (781030-7)
Trigger Switch with Lock-On and Lock-Off Features
• Linear Bearing Slide Mechanism allows extremely smooth plunge action
• Labyrinth Retainers and Fan prevent contamination of motor
• Plunge Depth can be adjusted from the bottom of the router when mounted in a router table
• 3 Stage Depth Adjustments ideal for use when performing deep or repetitive cutting operations
• Dual LED Job Lights with Afterglow
• Sub-Base accepts industry standard template guides
• Can be used with 55" (194368-5) or 118" (194367-7) Guide Rails and Router Guide Rail Adapter (194579-2)
for precision routing applications
Electric Brake
3-1/2 HP Plunge Router
SPECIFICATIONS
Collet Capacity
1/2" (12.7 mm)
Plunge Capacity
2-3/4" (70 mm)
No Load Speed
22,000 RPM
AMPS (120V)
15.0 A
Base Diameter
6-11/16" (170 mm)
Overall Height
12-1/4" (312 mm)
Net Weight
13.2 lbs (6.0 kg)
RP1801F
• Electronic Speed Control maintains constant speed under heavy load
• Variable Speed Dial adjusts motor speed based on materials or application
• Soft Start feature gradually increases speed to eliminate start up shock
• Flat Top Design for increased stability when changing bits
• Industrial Cam-Lock enables fast and easy depth adjustment
and removal of motor
• Sub-Base accepts industry standard template guides
• Sub-Base accepts industry standard template guides
• RD1101: Trigger Switch with Lock-On Feature
• RF1101: On / Off Toggle Switch
D-Handle Design
Side Handle Design
SPECIFICATIONS
Collet Capacities:
1/4", 1/2"
(6.4 mm, 12.7 mm)
No Load Speed
8,000 - 24,000 RPM
AMPS (120V)
11.0 A
Base Diameter
5-3/4" (146 mm)
Overall Height
8-3/4" (223 mm)
Net Weight
7.3 lbs (3.3 kg)
STANDARD EQUIPMENT INCLUDES:
1/4" Collet Cone (193214-9), 1/2" Collet Cone (193215-7),Two Wrenches 27 (781031-5)
RD1101
STANDARD EQUIPMENT INCLUDES:
1/4" Collet Cone (193214-9), 1/2" Collet cone (193215-7),Two Wrenches 27 (781031-5)
RF1101
Variable Speed, Constant Speed
Control, Soft Start
RD1101, RF1101
2-1/4 HP Routers
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Fixed Base
• Industrial Cam-Lock enables fast and easy depth adjustment and removal of motor
Plunge Base
• 3 Stage Depth Adjustments ideal for use when performing deep or repetitive cutting operations
• Conveniently located Plunge Locking Lever for easy engagement during operation
SPECIFICATIONS
Collet Capacities:
1/4", 1/2"
(6.4 mm, 12.7 mm)
Plunge Capacity
2-19/32" (66 mm)
No Load Speed
8,000 - 24,000 RPM
Center Hole Diameter
1-3/16" (30.5 mm)
AMPS (120V)
11.0 A
Base Diameter
5-3/4" (146 mm)
Overall Height:
Fixed
8-3/4" (223 mm)
Plunge
11-1/2" (292 mm)
Net Weight
7.3 lbs (3.3 kg)
RF1101KIT
2-1/4 HP Router Kit
STANDARD EQUIPMENT INCLUDES:
2-1/4 HPRouter Motor RF1101, Plunge Base (193457-3), 1/4" Collet (193214-9), 1/2" Collet (193215-7), Dust Nozzle (P-80009), Straight Guide (193073-1),
Base Plate (193155-9),Two Wrenches 27 (781031-5), Hex Wrench 4 (783202-0), Plastic Carrying Case (125153-5)
On / Off
Toggle Switch,
Electronic
Speed Control,
Variable Speed,
Soft Start
Makita offers a wide variety of
ACCESSORIES!
