TD0100

Multi-Purpose, Lightweight Impact Driver Can Be

Used For Any Light Fastening Applications

• Compact design and light weight (Only 8-5/8" and 2.1 lbs)

• Compact bit sleeve

• Easy to operate forward

and reverse change lever

• Ergonomic soft rubber

grip for vibration

absorption and comfortable

operation

1/4" Impact Driver

SPECIFICATIONS

Hex Shank

1/4"

Impacts Per Minutes

0 - 3200 IPM

No Load Speed

0 - 3600 RPM

Maximum Torque

885 in.lbs (100 N.m)

Capacities:

Machine Screw

M4 - M8 (5/32" - 5/16")

Standard Bolt

M5 - M14 (3/16" - 9/16")

High Tensile Bolt

M5 - M10 (3/16" - 3/8")

AMP (120V)

1.7 A

Overall Length

8-5/8" (218 mm)

Net Weight

2.1 lbs (0.96 kg)

STANDARD EQUIPMENT INCLUDES:

Phillips Bit 2-50(784244-7)

Variable Speed,

Reversible

6953

Durable Lightweight 1/2" Drive Impact Wrench

For Industrial Applications

• Heavy duty aluminum

gear housing

• Rubber inlay grip reduces

vibration

• Tool belt clip

• High power to weight ratio

• Variable speed allows user to have

greater control

• Conveniently located forward / reverse switch

1/2" Impact Wrench

SPECIFICATIONS

Square Drive

1/2"

Capacities:

Standard Bolt

3/8" - 5/8" (10 - 16 mm)

High Tensile Bolt

5/16" - 1/2" (8 - 12 mm)

Impacts Per Minute

0 - 3,000 IPM

No Load Speed

0 - 3,000 RPM

Fastening Torque

111 ft. lbs (150 Nm)

AMPS (120V)

2.5 A

Overall Length

9-1/8" (233 mm)

Net Weight

3.3 lbs (1.5 kg)

STANDARD EQUIPMENT INCLUDES:

Belt Clip (324284-9), Plastic Carrying Case (824630-1)

Variable Speed,

Reversible

TW0350

High Power To Weight Ratio

• More power and torque than competitors 7.5 AMP models

• Heavy duty aluminum gear housing

• Heavy duty front

rubber bumper

• Rocker switch

for easy one handed

reversing

• Ergonomic soft rubber grip for

vibration absorption and comfortable

operation

1/2" Impact Wrench

SPECIFICATIONS

Square Drive

1/2"

Capacities:

Standard Bolt

1/2" - 7/8" (12 - 22 mm)

High Tensile Bolt

1/2" - 5/8" (12 -16 mm)

Impacts Per Minute

2,000 IPM

No Load Speed

2,000 RPM

Fastening Torque

258 ft. lbs (350 Nm)

AMPS (120V)

3.5 A

Overall Length

11-1/8" (283 mm)

Net Weight

6.6 lbs (3.0 kg)

STANDARD EQUIPMENT INCLUDES:

Plastic Carrying Case (824702-2)

Reversible

6905B

1/2" Square Drive

• Precision machined gears for long life and production usage

• Heavy duty front rubber bumper

• Rocker switch for

easy one

handed

reversing

1/2" Impact Wrench

SPECIFICATIONS

Square Drive

1/2"

Capacities:

Bolt Size

1/2" - 3/4" (12 mm - 20 mm)

Impacts Per Minute

2,000 IPM

No Load Speed

1,700 RPM

Fastening Torque

217 ft. lbs (294 Nm)

AMPS (120V)

4.0 A

Overall Length

10-1/4" (270 mm)

Net Weight

6.2 lbs (2.8 kg)

STANDARD EQUIPMENT INCLUDES:

Tool Only.

6906

High Capacity Impact Wrench Ideal For Heavy

Duty Industrial Applications

• High tech motor for heavy duty applications

• Rocker type reversing switch for easy one handed

forward / reverse

operation

• Side handle

Adjusts 360°

for operator

convenience at any angle

• Heavy duty rubber bumper in front

3/4" Impact Wrench

SPECIFICATIONS

Square Drive

3/4"

Capacities:

Bolt Size

5/8" - 7/8" (16 mm - 22 mm)

Impacts Per Minute

1,600 IPM

No Load Speed

1,500 RPM

Fastening Torque

433 ft. lbs (588 Nm)

AMPS (120V)

9.0 A

Overall Length

12-7/8" (327 mm)

Net Weight

12.3 lbs (5.6 kg)

STANDARD EQUIPMENT INCLUDES:

Steel Carrying Case (182604-1), Side Handle (122464-9)

TW1000

Makita’s Most POWERFUL Impact Wrench

• 1" Square drive, 738 ft. lbs (1,000 Nm)

• Side handle adjusts 360° for operator convenience at any angle

• Heavy duty front rubber bumper

• Rocker switch for

easy one handed

reversing

1" Impact Wrench

SPECIFICATIONS

Square Drive

Capacities:

Standard Bolt

1" - 1-3/16" (24 - 30 mm)

High Tensile Bolt

7/8" - 1" (22 - 24 mm)

Impacts Per Minute

1,500 IPM

No Load Speed

1,400 RPM

Fastening Torque

738 ft. lbs (1,000 Nm)

AMPS (120V)

12.0 A

Overall Length

15.0" (382 mm)

Net Weight

19.0 lbs (8.6 kg)

STANDARD EQUIPMENT INCLUDES:

Side Handle (122727-3), Plastic Carrying Case (824737-3)

Reversible

STANDARD EQUIPMENT INCLUDES:

Screwdriver (783001-0), Steel Carrying Case (823276-0), Outer Sleeve 22-39 (153909-6),

Outer Sleeve 20-37 (764361-9), Inner Sleeve (764418-6), Inner Sleeve (764419-4)

Anti-Slipping Mechanism, Tool Starts When

Inner Sleeve Engages With Bolt Tip

• Handy tip lever for ejecting sheared tips

• Rubber bumper for tool body protection

• Cast aluminum gear housing to withstand

high torque levels of planetary gears (804 Nm)

• Easy to grip D-handle

SPECIFICATIONS

Capacities:

7/8" (M22), 3/4" (M20)

No Load Speed

18 RPM

Fastening Torque

593 ft. lbs (804 Nm)

AMPS (120V)

12.0 A

Overall:

Height

9-15/16" (252 mm)

Length

9-13/16" (249 mm)

Power Supply Cord

8.2' (2.4 m)

Net Weight

10.6 lbs (4.8 kg)

6922NB

Shear Wrench

SHEARWRENCHACCESSORIES

Bolt Size Description For Model

Outer Sleeve

Inner Sleeve

M16

Shear

Wrench

Sleeves

DWT310

6922NB

764362-7

764420-9

M20

764361-9

764417-8

M22

153909-6

764418-6

5/8"

764362-7

764420-9

3/4"

764361-9

764419-4

764363-5 (Long)

764353-8 (Long)

Weighs Only

10.6 lbs For Easy

Maneuverability & Less

Operator Fatigue!
