METALWORKING
makita.ca
152
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
Socket Wrench 17 (782210-8), Elbow Joint (P-80008)
Used To Cut Steel, Concrete And Masonry Materials
• Guide wheels on the tool guard ensure smooth tool travel over surface material
• Rubber shield protects the operators hand and motor from debris
• Lock-On button for continuous operation
• Ball bearing construction for longer tool life
• SJS technology prevents kickback if blade jams protecting both the operator and tool
• Integrated nozzle can be connected to vacuum system for clean operation
AC/DC, SJS Technology
14" Angle Cutter
SPECIFICATIONS
Blade Diameter
14" (355 mm)
Arbor
1" (25.4 mm)
Maximum Cutting Depth
5" (125 mm)
No Load Speed
3,800 RPM
AMPS (120V)
15.0 A
Overall Length
26-1/2" (673 mm)
Net Weight
22.7 lbs (10.3 kg)
4114
STANDARD EQUIPMENT INCLUDES:
Plastic Carrying Case (824697-9), Socket Wrench 17 (782210-8)
Used To Cut Steel, Concrete And Masonry Materials
• Guide wheels on the tool guard ensure smooth tool travel over surface material
• Rubber shield protects the operators hand and motor from debris
• Lock-On button for continuous operation
• Ball bearing construction for longer tool life
• SJS technology prevents kickback if blade jams protecting both the operator and tool
• Integrated nozzle can be connected to vacuum system for clean operation
AC/DC, SJS Technology
12" Angle Cutter
SPECIFICATIONS
Blade Diameter
12" (305 mm)
Arbor
1" (25.4 mm)
Maximum Cutting Depth 3-15/16" (100 mm)
No Load Speed
5,000 RPM
AMPS (120V)
15.0 A
Overall Length
25-1/2" (648 mm)
Net Weight
25.1 lbs (11.4 kg)
4112H
Designed For Cutting 90° and 135° Grooves in
Aluminum Composite Materials
• Electronic current limiter prevents motor burnout due to
motor overload
• Soft start feature gradually increases speed to eliminate start up shock
• Constant speed control maintains constant speed under heavy load
• Variable speed dial adjusts cutting speed based on materials
or application
• Mechanical brake for increased operator safety
• Easy open blade case enables quick blade changes on the jobsite
• Adapts quickly and easily to Makita 446L and VC4710
Dust Extractors for dust-free operation
• Soft rubber grip design for vibration absorption and
comfortable operation
• Can be used with 55" (194368-5) or 118" (194367-7) Guide Rails
for precision cutting applications
SPECIFICATIONS
Blade Diameter
4-5/8" (118 mm)
Arbor
13/16" (20 mm)
Maximum Cutting Capacities
7/16" (11 mm)
No Load Speed
2,200 - 6,400 RPM
AMPS (120V)
12.0 A
Overall Length
13-5/8" (346 mm)
Net Weight
11.3 lbs (5.1 kg)
CA5000X
4-5/8" Aluminum Groove Cutter
ALUMINUMGROOVE CUTTINGBLADES
Diameter
Arbor
Teeth
Grooving Angle
Kerf
Max. RPM
Material
For Model
Part No.
4-3/8"
20 mm 6 CT
90° (2 mm Width)
0.55"
12,940 RPM Aluminum CA5000X
A-99926
90° (3 mm Width)
A-96132
135°
0.71"
A-96148
STANDARD EQUIPMENT INCLUDES:
Skirt Complete (143293-7), Plate Complete (143396-7), Hex
Wrench 5 (783022-2), 4-5/8˝ Grooving C.T. Blade 6T90° (A-99926)
Variable Speed, Electronic
Current Limiter, Soft Start,
Constant Speed Control,
Mechanical Brake
Find
Aluminum Groove
Cutter Accessories
on page 96
ABRASIVEMETAL CUTTINGWHEELS
Wheel
Diameter Arbor Thickness Grit
Recommended
Use
Max.
RPM
For
Model(s)
5 / Pk
Part No.
25 / Pk
Part No.
16"
1"
1/8"
A36PBF Steel, Ferrous
Metals 3,400 2416S A-90174 A-05050
14"
1"
1/8"
A36P-BF Steel Studs,
Ferrous Metals
3,900
LW1400
LW1401
2414DB
2414NB
4114
DLW140Z
A-90168 A-05044
A30P-BF Long Life
Cutting in
Steel
B-19875-5 B-19875-25
3/32"
A36N-BF
4,400
B-57598-5 B-57598-25
A30Q-BF Fast Cutting
in Steel
3,900
B-23204-5 B-23204-25
A36P-BF Ideal For
Cordless 4,400
B-64705-5 B-64705-25
12"
1"
7/64" A36PBF
Steel,
Ferrous Metals 4,500 2412 A-90152 A-05038
Makita offers a wide variety of
ACCESSORIES!
