156 / 220
METALWORKING
makita.ca
154
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
GA9060
STANDARD EQUIPMENT INCLUDES:
Wheel Cover (122939-8), Side Handle (143486-6), Inner Flange (224317-9), Lock Nut 5/8"-45 (224486-6), Lock Nut Wrench 28 (782412-6)
Two-Stage Safety Trigger Switch (AC)
• Heavy duty design, including improved armature components and low absorbent motor housing for
maximum jobsite durability
• Newly designed slanted shaft lock enables easier engagement by operator
• Long life carbon brushes and spiral spring brush holders minimize service and maintenance requirements
• Anti-short switch cover, armature components and increased commutator depth ensure optimal
electrical contact and performance
• Transparent cover protects serial number and name plate against wear
• Labyrinth construction features a complex series of channels to prevent penetration of dust and debris
into the field and armature for maximum operational life
• Motor winding protection features increased "Zig-Zag" varnish on the armature and hardened powder on
the field coils to act as an impenetrable barrier to dust and debris
9" Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
9" (230 mm)
Sanding Disc
9" (230 mm)
Wire Cup Brush
4-3/8" (110 mm)
Spindle Thread
5/8" - 11 UNC
No Load Speed
6,600 RPM
AMPS (120V)
15.0 A
Overall Length
17-3/4" (450 mm)
Net Weight
12.1 lbs (5.5 kg)
STANDARD EQUIPMENT INCLUDES:
Side Handle (152492-0)
Trigger Switch with Lock-On Button (AC/DC)
• Heavy duty motor design ideal for continuous operation
• Removable side handle can be mounted on left or right side of tool
• Accepts 7˝ or 9˝ wheels when used with proper guards
9" / 7" Angle Grinder / Sander
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
7" or 9"
(180 mm or 230 mm)
Sanding Disc
7" (180 mm)
Wire Cup Brush
6" (150 mm)
Spindle Thread
5/8"-11 UNC
No Load Speed
7,000 RPM
AMPS (120V)
15.0 A
Overall Length
16-1/4" (412 mm)
Net Weight
12.2 lbs (5.5 kg)
GA7911
• Heavy duty torque limiter prevents damage to internal gearing and prevents operator from
experiencing a surge of torque during wheel lock up
• Labyrinth construction features a complex series of channels to prevent penetration of dust and
debris into the field and armature for maximum operational life
• Includes rear vent ˝Dust Cover Assembly˝ for added protection against dust and debris (GA9031Y Only)
• Motor winding protection features "Zig-Zag" varnish on the armature and hardened powder on the
field coils to act as an impenetrable barrier to dust and debris
• Rear handle swivels 180
°
to adjust to the most comfortable grinding position
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Removable side handle can be mounted on left or right side of tool
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
9" (230 mm)
Sanding Disc
7" (180 mm)
Wire Cup Brush
4-3/8" (110 mm)
Spindle Thread
5/8" - 11 UNC
No Load Speed
6,600 RPM
AMPS (120V)
15.0 A
Overall Length
19-7/8" (504 mm)
Net Weight
14.3 lbs (6.5 kg)
STANDARD EQUIPMENT INCLUDES:
Anti-Vibration Side Handle (194543-3)
Dust CoverAttachment Set (194289-1), Lock Nut Wrench
28 (782412-6),Toolless Wheel Cover (123543-6),
Inner Flange (224317-9), Lock Nut 5/8-45 (224568-4)
GA9031
Trigger Switch with
Lock-On Button
(AC/DC)
GA9031, GA9031Y
9" Angle Grinders
STANDARD EQUIPMENT INCLUDES:
Anti-Vibration Side Handle (194543-3), Dust CoverAttachment Set (194289-1),
Lock Nut Wrench 28 (782412-6),Toolless Wheel Cover (123543-6),
Inner Flange 89 (224317-9), Lock Nut 5/8-45 (224568-4)
GA9031Y
Two Stage Safety
Trigger Switch
(AC/DC)
Makita offers a wide variety of
ACCESSORIES!
GA9040S
STANDARD EQUIPMENT INCLUDES:
Anti-Vibration Side Handle (194543-3), Lock Nut Wrench 28 (782412-6),Toolless Wheel Cover (123543-6),
9˝ Depressed Centre Wheel (D-20812), Inner Flange (224317-9), Lock Nut 5/8"- 45 (224568-4)
Trigger Switch with Lock-On Button (AC)
• Labyrinth construction features a complex series of channels to prevent penetration of dust and debris
into the field and armature for maximum operational life
• Motor winding protection features "Zig-Zag" varnish on the armature and hardened powder on the field
coils to act as an impenetrable barrier to dust and debris
• Soft start feature gradually increases speed to eliminate start up shock
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Rotatable Rear Handle can be adjustable to suit various cutting and grinding operations
• Low vibration rear handle ideal for improved operator comfort during periods of prolonged use
• Removable side handle can be mounted on left, right, or top side of tool
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
9" Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
9" (230 mm)
Sanding Disc
9" (230 mm)
Wire Cup Brush
4-3/8" (110 mm)
Spindle Thread
5/8" - 11 UNC
No Load Speed
6,600 RPM
AMPS (120V)
15.0 A
Overall Length
20-1/8" (511 mm)
Net Weight
14.8 lbs (6.7 kg)
GA9050
STANDARD EQUIPMENT INCLUDES:
Side Handle (152539-0), Lock Nut Wrench 28 (782412-6), Wheel Cover (122939-8), Inner Flange (224317-9), Lock Nut 5/8"-45 (224568-4)
Paddle Switch With Lock-On Button (AC/DC)
• Compact gear housing increases maximum cutting depth by 1/4"
• Lightweight design for optimal maneuverability and control
• Labyrinth construction features a complex series of channels to prevent penetration of dust and debris
into the field and armature for maximum operational life
• Motor winding protection features "Zig-Zag" varnish on the armature and hardened powder on the
field coils to act as an impenetrable barrier to dust and debris
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Removable side handle can be mounted on left or right side of tool
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
9" Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
9" (230 mm)
Sanding Disc
9" (230 mm)
Wire Cup Brush
4-3/8" (110 mm)
Spindle Thread
5/8" - 11 UNC
No Load Speed
6,600 RPM
AMPS (120V)
15.0 A
Overall Length
17" (432 mm)
Net Weight
10.4 lbs (4.7 kg)
