STANDARD EQUIPMENT INCLUDES:
Side Handle (152539-0), Lock Nut Wrench 28 (782412-6), Wheel Cover (122939-8), Inner Flange (224317-9), Lock Nut (224568-4)
Paddle Switch with Lock-On Button (AC/DC)
• Compact gear housing increases maximum cutting depth by 1/4"
• Labyrinth construction features a complex series of channels to prevent penetration of dust and
debris into the field and armature for maximum operational life
• Motor winding protection features "Zig-Zag" varnish on the armature and hardened powder on the
field coils to act as an impenetrable barrier to dust and debris
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Removable side handle can be mounted on left or right side of tool
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
7" Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
7" (180 mm)
Sanding Disc
7" (180 mm)
Wire Cup Brush
4-3/8" (110 mm)
Spindle Thread
5/8" - 11 UNC
No Load Speed
8,500 RPM
AMPS (120V)
15.0 A
Overall Length
17" (432 mm)
Net Weight
9.9 lbs (4.5 kg)
GA7050
STANDARD EQUIPMENT INCLUDES:
7" Depressed Center Wheel (D-20806), Side Handle (152539-0), Inner Flange (224317-9), Lock Nut (224568-4), Lock Nut Wrench 28
(782412-6),Toolless Wheel Cover ( 122772-8)
Paddle Switch with Lock-On Button (AC)
• Electronic current limiter prevents motor burnout due to overloading
• Soft start feature gradually increases speed to eliminate start up shock
• Labyrinth construction features a complex series of channels to prevent penetration of dust and
debris into the field and armature for maximum operational life
• Motor winding protection features varnish on the armature and hardened powder on the
field coils to act as an impenetrable barrier to dust and debris
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Removable side handle can be mounted on left or right side of tool
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
Electronic Current Limiter,
Soft Start
7" Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
7" (180 mm)
Sanding Disc
7" (180 mm)
Wire Cup Brush
4-3/8" (110 mm)
Spindle Thread
5/8" - 11 UNC
No Load Speed
8,400 RPM
AMPS (120V)
15.0 A
Overall Length
17-7/8" (453 mm)
Net Weight
9.5 lbs (4.3 kg)
GA7010C
• Heavy duty torque limiter prevents damage to internal gearing and prevents operator from
experiencing a surge of torque during wheel lock up
• Labyrinth construction features a complex series of channels to prevent penetration of dust and
debris into the field and armature for maximum operational life
• Includes rear vent "Dust Cover Assembly" for added protection against dust and debris (GA7031Y Only)
• Motor winding protection features "Zig-Zag" varnish on the armature and hardened powder on the
field coils to act as an impenetrable barrier to dust and debris
• Rear handle swivels 180
°
to adjust to the most comfortable grinding position
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Removable side handle can be mounted on left or right side of tool
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
7" (180 mm)
Sanding Disc
7" (180 mm)
Wire Cup Brush
4-3/8" (110 mm)
Spindle Thread
5/8" - 11 UNC
No Load Speed
8,500 RPM
AMPS (120V)
15.0 A
Overall Length
19-7/8" (504 mm)
Net Weight
13.9 lbs (6.3 kg)
STANDARD EQUIPMENT INCLUDES:
Anti-Vibration Side Handle (194543-3),
Dust CoverAttachment Set (194289-1),
Lock Nut Wrench 28 (782412-6),
Toolless Wheel Cover (123542-8),
Inner Flange (224317-9),
Lock Nut 5/8-45 (224568-4)
GA7031
Trigger Switch with
Lock-On Button
(AC/DC)
GA7031, GA7031Y
7" Angle Grinders
STANDARD EQUIPMENT INCLUDES:
Anti-Vibration Side Handle (194543-3), Dust CoverAttachment Set (194289-1),
Lock Nut Wrench 28 (782412-6),Toolless Wheel Cover (123542-8),
Inner Flange (224317-9), Lock Nut 5/8-45 (224568-4)
GA7031Y
Two Stage Safety
Trigger Switch
(AC/DC)
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
GA7060
STANDARD EQUIPMENT INCLUDES:
Wheel Cover (122939-8), Side Handle (143486-6), Inner Flange (224317-9), Lock Nut 5/8"-45 (224486-6), Lock Nut Wrench 28 (782412-6)
Two-Stage Safety Trigger Switch (AC)
• Heavy duty design, including improved armature and motor housing for maximum jobsite durability
• Newly designed slanted shaft lock enables easier engagement by operator
• Improved brush holders extends working life of carbon brushes
• Transparent cover protects serial number against wear
• Labyrinth construction features a complex series of channels to prevent penetration of dust and
debris into the field and armature for maximum operational life
• Motor winding protection features "Zig-Zag" varnish on the armature and hardened powder on the field
coils to act as an impenetrable barrier to dust and debris
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Removable 3 position side handle can be mounted on left, right or top side of tool
7" Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
7" (180 mm)
Sanding Disc
7" (180 mm)
Wire Cup Brush
4-3/8" (110 mm)
Spindle Thread
5/8" - 11 UNC
No Load Speed
8,500 RPM
AMPS (120V)
15.0 A
Overall Length
17-3/4" (450 mm)
Net Weight
11.7 lbs (5.3 kg)
STANDARD EQUIPMENT INCLUDES:
Anti-Vibration Side Handle (194543-3), Lock Nut Wrench 28 (782412-6),Toolless Wheel Cover (123542-8),
7˝ Depressed Centre Wheel (D-20806), Inner Flange (224317-9), Lock Nut 5/8"-45 (224568-4)
Trigger Switch with Lock-On Button (AC)
• Labyrinth construction features a complex series of channels to prevent penetration of dust and
debris into the field and armature for maximum operational life
• Motor winding protection features "Zig-Zag" varnish on the armature and hardened powder on the
field coils to act as an impenetrable barrier to dust and debris
• Soft start feature gradually increases speed to eliminate start up shock
• Rotatable gear housing can be positioned at every 90° for optimal positioning
• Rotatable rear handle can be adjustable to suit various cutting and grinding operations
• Low vibration rear handle ideal for improved operator comfort during periods of prolonged use
• Removable side handle can be mounted on left, right, or top side of tool
7" Angle Grinder
SPECIFICATIONS
Maximum Capacities:
Grinding Wheel
7" (180 mm)
Sanding Disc
7" (180 mm)
Wire Cup Brush
4-3/8" (110 mm)
Spindle Thread
5/8" - 11 UNC
No Load Speed
8,500 RPM
AMPS (120V)
15.0 A
Overall Length
20-1/8" (511 mm)
Net Weight
14.2 lbs (6.4 kg)
GA7040S
