45 / 220
Ideal for
confined spaces!
DPB182Z
makita.ca
43
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
18V LXT
Metalworking Tools
When
QUALITY&SERVICE
Counts – ChooseMakita
STANDARD EQUIPMENT INCLUDES:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830B (194205-3), Rapid Charger (DC18RC), 5-3/8" C.T. Saw Blade 30T (A-95037),
Battery Cover (450128-8), Hex Wrench 5 (783203-8), Safety Goggles (192219-6), Plastic Carrying Case (141485-2)
Compact & Lightweight With Well Balanced Design
• Designed for cutting channel, corrugated steel, conduit, pipe, sheet metal,
square tubing, angle iron and more
• LED Job Light illuminates cutting area
• Large Lock-Off Safety Lever prevents accidental start up
• Stainless Steel Base Plate
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Electric Brake,
Cutting Capacity of 2" (51 mm)
5-3/8" Metal Cutting Saw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Blade Diameter
5-3/8" (136 mm)
Arbor
5/8" (15.9 mm)
No Load Speed
3,600 RPM
Maximum Cutting Capacity
2" (51 mm)
Overall Length
13-3/4" (348 mm)
Net Weight
5.7 lbs (2.6 kg)
DCS550RFE
DPB180RFE
STANDARD EQUIPMENT INCLUDES:
DPB180RFE:
Two 18V (3.0Ah) Li-Ion
Batteries
BL1830B (194205-3),
Rapid Charger (DC18RC), Battery Cover
(450128-8), Bi-Metal Band Saw Blade 18TPI
(792556-A ), D-Style Front Handle (273525-9),
Hex Wrench 4 (783202-0),
Plastic Carrying Case (141496-7)
DPB180Z:
ToolOnly.BatteriesandCharger
SoldSeparately.
Bi-MetalBandSawBlade 18TPI
(792556-A ),D-StyleFrontHandle (273525-9),
HexWrench 4 (783202-0)
Well Balanced And Lightweight
• Ideal center of gravity creates well balanced
design for optimum control
• Variable Speed Dial enables operator to set
constant speed based on materials or application
• Electronic Current Limiter prevents motor
burnout due to overloading
• Warning Light indicates ideal time to
recharge battery
• LED Light with Afterglow feature
• Accepts standard 1/2˝ x 44-7/8˝ blades
Electronic Current Limiter,
LED Light
Band Saw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Cutting Capacities:
Round Material
4-3/4" (120 mm)
Square Material
4-3/4" x 4-3/4"
(120 mm x 120 mm)
Blade Speed
275-530 ft./min.
Overall Length
20-5/8" (523 mm)
Net Weight
13.0 lbs (5.9 kg)
DPB180Z
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.
5-3/8"C.T.SawBlade30T (A-95037),HexWrench5 (783203-8),SafetyGoggles (192219-6)
Compact & Lightweight With Well Balanced Design
• Features built-in dust box for improved dust/metal chip collection
• Dust box cap can be opened for easy disposal of dust/metal chips
• Designed for cutting channel, corrugated steel, conduit, pipe, sheet metal, square tubing,
angle iron and more
• Electric brake stops blade 3-5 seconds after trigger is released for increased operator safety
• LED job light illuminates cutting area
• Large lock-off safety lever prevents accidental startup
• Stainless steel base plate
• Ergonomic soft rubber grip for vibration absorption and comfortable operation
Electric Brake, LED Light,
Cutting Capacity of 2" (51 mm)
5-3/8" Dust Collecting Metal Cutting Saw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Blade Diameter
5-3/8" (136 mm)
Arbor
5/8" (15.88 mm)
No Load Speed
3,600 RPM
Maximum Cutting Capacity 2" (51 mm)
Overall Length
13-3/4" (348 mm)
Net Weight
4.6 lbs (2.0 kg)
DCS552Z
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.
14"AbrasiveWheel (1Ea.B-64705-5),Vise (135708-8)
THE WORLD'S FIRST CORDLESS PORTABLE CUT-OFF SAW!
• Brushless DC motor with high power to weight and size ratio
• Electric brake stops blade 3-5 seconds after trigger is released for
increased operator safety
• Soft start feature gradually increases speed to eliminate start up shock
• LED load status indicator shows the level of load on the motor during operation and alerts the user when
an excessive amount of load is being applied on the tool
• Toolless wheel change feature enables fast and easy blade changes without the need for additional tools
• Quick release vise enables fast clamping of materials
• Pin lock secures saw head in downward position for
safe transportation and storage
• Toolless 3 position guide plate
adjustment for fast and
accurate angle setting
14" Portable Cut-Off Saw
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Blade Diameter
14" (355 mm)
Arbor
1" (25.4 mm)
No Load Speed
3,800 RPM
Cutting Capacity:
45°
5" (127 mm)
90°
5" (127 mm)
Overall Length
21-1/8" (537 mm)
Net Weight
32.9 lbs (14.9 kg)
DLW140Z
Electric Brake, Soft Start,
Mitres 45° Left, 5" (Round)
Cutting Capacity
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold
Separately.
Bi-Metal Band Saw Blade
18TPI (1 Ea. B-40559), Hex Wrench 4
(783202-0), Hook (345736-7)
Compact And Lightweight Design
Ideal For Confined Spaces Or
Small Diameter Material
• Compact and lightweight design ideal for
overhead cutting applications or small diameter
pipes, channel, strut and more!
• Battery protection system provides over-discharge,
temperature and circuit protection for enhanced
performance, battery cycle life and overall
battery life
• Aluminum frame and blade housing for maximum
cutting rigidity and increased durability
• Easy blade tracking adjustment for increased
performance and productivity
• Lock-off button prevents accidental startup
• Ball bearing blade guide provides smooth
blade movement
Band Saw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Capacities:
Round Material
2-1/2" (64 mm)
Square Material
2-1/2" x 2-1/2"
(64 mm x 64 mm)
Blade Speed 630 ft. / min. (3.2 m / sec.)
Overall Length
18-3/4" (477 mm)
Net Weight
7.5 lbs (3.4 kg)
DPB182Z
LED Light
