44 / 220
18V LXT
Metalworking Tools
makita.ca
42
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Makita offers a wide variety of
ACCESSORIES!
DJS101Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Hex Wrench 3 (783201-2), Side Blade Set (792536-0), Center Blade (792537-8)
In-Line Design Allows For Better Control And Excellent Maneuverability
• Anti-restart feature prevents accidental start up of tool during battery changing when switch is
locked in the on position
• Battery capacity warning light indicates ideal time to recharge battery
• Electronic current limiter with warning light prevents motor burnout caused by overloading
• Adjustable blade set minimizes burring for various thicknesses of material
• Small circumference, ergonomic soft rubber grip design for vibration absorption and
comfortable operation
• In-line design allows for better control
and excellent maneuverability
20 ga Straight Shear
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Steel
20 gauge (1.0 mm)
Stainless
23 gauge (0.7 mm)
No Load Speed
4,300 SPM
Minimum Cutting Radius 1-3/16" (30 mm)
Overall Length
14-3/8" (364 mm)
Net Weight
3.1 lbs (1.4 kg)
DJS161Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Thickness Gauge (762013-6), Hex Wrench 3 (783201-2), Side Blade Set (792533-6),
Center Blade (792534-4)
In-Line Design Allows For Better Control And Excellent Maneuverability
• Battery capacity warning light indicates ideal time to recharge battery
• Anti-restart feature prevents accidental start up of tool during battery changing when switch is locked
in the on position
• Electronic current limiter with warning light prevents motor burnout caused by overloading
• Adjustable blade set minimizes burring for various thicknesses of material
• Small circumference, ergonomic soft rubber
grip design for vibration absorption and
comfortable operation
16 ga Straight Shear
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Steel
16 gauge (1.6 mm)
Stainless
18 gauge (1.2 mm)
No Load Speed
4,300 SPM
Minimum Cutting Radius 9-7/8" (250 mm)
Overall Length
14-1/4" (362 mm)
Net Weight
3.1 lbs (1.4 kg)
DJN161Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Wrench 32 (781028-4), Hex Wrench 2.5 (783208-8),
Die (A-15051), Punch (A-83951)
Optimal Size And Maneuverability For Cutting Keystone Plate,
Deck Plate, Metal Roofing And Other Corrugated Sheet Materials
• Battery Capacity Warning Light indicates ideal time to recharge battery
• Anti-Restart feature prevents accidental start up of tool during battery changing when switch is
locked in the on position
• Die rotates 360° with positive stops at 0°, 90° Left, 90° Right and 180° for simple and accurate
adjustment on the jobsite
• Built-in thickness gauge for
operator convenience
• Easy punch and die
replacement for less
down time
16 ga Nibblers
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Capacities:
Mild Steel
16 gauge (1.6 mm)
Stainless
18 gauge (1.2 mm)
Aluminum
12 gauge (2.5 mm)
Strokes Per Minute
1,900 SPM
Minimum Cutting Radius:
Outside Edge
2" (50 mm)
Inside Edge
1-3/4" (45 mm)
Overall Length
12-3/8" (313 mm)
Net Weight
4.8 lbs (2.2 kg)
DJS130Z
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.
Hook (281220-7),HexWrench4 (783202-0),ShearHeadAssembly (125849-8)
Shear Head Attachment Rotates 360° For Optimum Maneuverability
• Compact and Lightweight (Overall Length 13-3/4˝)
• Lock-Off Button prevents accidental engagement of trigger
• On Board Hex Wrench Storage
• Belt Clip for operator convenience
• Ergonomic Soft Rubber Grip design for
vibration absorption and
comfortable operation
18 ga Straight Shear
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Steel
18 gauge (1.3 mm)
Stainless
20 gauge (1 mm)
No Load Speed
3,000 SPM
Overall Length
13-3/4" (350 mm)
Net Weight
5.3 lbs (2.4 kg)
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.
5-7/8"C.T.
Blade32T (A-96095),GuideRule (164095-8),HexWrench5
(783203-8),SafetyGoggles (192219-6)
Ultra-Compact & Lightweight With Well Balanced Design
• Features built-in dust box for improved dust/metal chip collection
• Dust box cap can be opened for easy disposal of dust/metal chips
• Designed for cutting channel, corrugated steel, conduit, pipe, sheet metal, square tubing, angle iron and more
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Automatic torque Drive Technology (ADT) feature adjusts the torque and speed according to the load
condition, enabling rapid movement between high speed
and high torque applications
• Brushless DC motor with high power to weight
and size ratio
Electric Brake, LED Light,
Cutting Capacity of 2-1/4" (57.5 mm)
5-7/8" Dust Collecting Metal Cutting Saw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Blade Diameter
5-7/8" (150 mm)
Arbor
5/8" (15.88 mm)
No Load Speed
4,200 RPM
Maximum Cutting Capacity
2-1/4" (57.5 mm)
Overall Length
10-1/2" (267 mm)
Net Weight
5.3 lbs (2.4 kg)
DCS553Z
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.
OuterSleeve20-37 (764361-9), InnerSleeve (764419-4),
OuterSleeve22-39 (153909-6), InnerSleeve (764418-6),
Screwdriver (783001-0),ShoulderBelt (161347-8),
PlasticCarryingCase (821748-9)
Tightens up to 380 M22 torque control bolts per charge
using two 18V (6.0 Ah) Li-Ion Batteries!
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Brushless DC motor with high power to weight and size ratio
• LED battery capacity warning lamp warns operator when the number of bolts that can be tightened is less
than 10 and when the battery is fully drained
• Cast aluminum gear housing to withstand high torque levels of planetary gears (804 Nm)
• Trigger lock-off feature prevents accidental start-up for increased operator safety
• Easy to grip D-handle
Electric
Brake
Shear Wrench
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Capacities: 5/8" (M16), 3/4" (M20), 7/8" (M22)
No Load Speed
14 RPM
Fastening Torque 593 ft. /lbs (804 Nm)
Overall Height
14-7/8" (377 mm)
Overall Length
11-5/8" (296 mm)
Net Weight
12.8 lbs (5.8 kg)
DWT310ZK
