41 / 220
18V LXT
Woodworking Tools / Metalworking Tools
makita.ca
39
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
When
QUALITY&SERVICE
Counts – ChooseMakita
DST221Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Safety Goggles (195246-2), Hook (346449-3)
Machined Aluminum Magazine Ensures Smooth Staple Loading And Feeding
• Contact Arm enables bump firing for quick operation
• Depth Control Dial enables precise setting of staple depth
• Belt Clip for operator convenience
• Easy to Repair Construction
• Magazine Window shows quantity of staples remaining
Stapler
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Staple:
Width
3/8˝ (10 mm)
Length 3/8" - 7/8" (10 mm - 22 mm)
Gauge 1/32" x 1/16" (0.6 mm x 1.2 mm)
Magazine Capacity:
Pcs. Per Sheet
84
Maximum
98
Overall Length
9-7/8" (251 mm)
Net Weight
5.3 lbs (2.4 kg)
DCG180RFEC
STANDARD EQUIPMENT INCLUDES:
DCG180RFEC:
Two 18V (3.0Ah)Li-IonBatteries
BL1830B
(194205-3),RapidCharger (DC18RC),BatteryCover (450128-8),
SafetyGoggles (195246-2),ToolBag (821007X)
DCG180ZC:
Tool Only. Batteries and Charger Sold Separately.
Safety Goggle (195246-2)
Ideal For Quick and Precise Application of Caulking and Sealants
Accepts Standard 800 ml Cartridges
• Anti-drip function eliminates residual pressure on caulking tube to prevent caulking from escaping
when the trigger is released
• Variable speed dial allows operator to set maximum dispensing speed while the variable speed trigger
enables fine adjustment for maximum control and precision in a wide range of applications
• 360° rotating tube tray allows
operator to adjust positioning
based on materials or
application
• Overload protection feature
with warning light prevents
motor burnout caused by
overloading
800 ml Caulking Gun
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Max. Pushing Force
1,100 lb (5,000 N)
Compatible Sealant Size:
800 ml Cartridge, Sausage Pack
Dimensions (L x W x H)
18-7/8" x 4-1/4" x 11-1/8"
(480 mm x 108 mm x 281 mm)
Net Weight
4.6 lbs (2.1 kg)
DCG180RFE
DCG180Z
STANDARD EQUIPMENT INCLUDES:
DCG180RFE:
Two 18V (3.0Ah)Li-IonBatteries
BL1830B
(194205-3),RapidCharger (DC18RC),BatteryCover (450128-8),
SafetyGoggle (195246-2),ToolBag (821007X)
DCG180Z:
Tool Only. Batteries and Charger Sold Separately.
Safety Goggle (195246-2)
Ideal For Quick and Precise Application of Caulking and Sealants
Accepts Standard 300 ml Cartridges
• Anti-drip function eliminates residual pressure on caulking tube to prevent caulking from escaping
when the trigger is released
• Variable speed dial allows operator to set maximum dispensing speed while the variable speed trigger
enables fine adjustment for maximum control and precision in a wide range of applications
• 360° rotating tube tray allows
operator to adjust positioning
based on materials or application
• Overload protection feature with
warning light prevents motor
burnout caused by overloading
300 ml Caulking Gun
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Max. Pushing Force
1,100 lb (5,000 N)
Compatible Sealant Size
300 ml Cartridge
Dimensions (L x W x H)
15-7/8" x 4-1/4" x 11-1/8"
(404 mm x 108 mm x 281 mm)
Net Weight
4.8 lbs (2.2 kg)
Anti-Drip Function,
Variable Speed
Anti-Drip Function,
Variable Speed
DCG180ZC
DCG180RFEB
DCG180ZB
STANDARD EQUIPMENT INCLUDES:
DCG180RFEB:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830B (194205-3),
Rapid Charger (DC18RC), Battery Cover (450128-8), Nozzle (454226-0),
Rubber Ring (424547-4), PistonA (142071-2), Piston C (123221-8),
Screw (266827-0), Safety Goggle (195246-2),Tool Bag (821007X)
DCG180ZB:
Tool Only. Batteries and Charger Sold Separately.
Nozzle (454226-0), Rubber Ring (424547-4), PistonA (142071-2), Piston C (123221-8),
Screw (266827-0), Safety Goggle (195246-2)
Ideal For Quick and Precise
Application of Caulking and Sealants
Accepts Standard 600 ml Cartridges, Sausage Packs
and Bulk Caulking or Sealants
• Anti-drip function eliminates residual pressure on
caulking tube to prevent caulking from escaping
when the trigger is released
• Variable speed dial allows operator to set
maximum dispensing speed while the variable
speed trigger enables fine adjustment for maximum
control and precision in a wide range of applications
600 ml Caulking Gun
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Max. Pushing Force
1,100 lb (5,000 N)
Compatible Sealant Size:
600 ml Cartridge
Sausage Pack, Bulk Sealant
Dimensions (L x W x H)
21-1/4" x 4-1/4" x 11-1/8"
(538 mm x 108 mm x 281 mm)
Net Weight
5.9 lbs (2.7 kg)
Anti-Drip Function, Variable Speed
Auto-Start Wireless System (AWS) Technology Features
Wireless Dust Collection Technology!
• AWS (Auto-Start Wireless System) uses Bluetooth
®
technology to communicate between tool and
vacuum and enable wireless control when used with Makita AWS cordless tools
• Automatic torque Drive Technology (ADT) adjusts the torque and speed according to the load condition,
enabling rapid movement between high speed and high torque applications
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids
for optimal performance in extreme conditions
9" Angle Grinder with AWS
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Grinding Wheel
9" (230 mm)
No Load Speed
6,000 RPM
Arbor Size
5/8" - 11 UNC
Overall Length
19-5/8" (499 mm)
Net Weight
9.9 lbs (4.5 kg)
DGA901Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Toolless Wheel Cover (123543-6), Side Handle (143486-6),
Lock Nut Wrench 28 (782412-6), Inner Flange (224500-8), Lock Nut 5/8"-45 (224486-6)
Two-Stage Safety
Paddle Switch,
Electric Brake
Bluetooth
®
is a registered
trademark of Bluetooth
®
SIG
High Performance And Efficiency For Heavy-Duty
Grinding Applications
• Automatic torque Drive Technology (ADT) adjusts the torque and speed according to
the load condition, enabling rapid movement between high speed and high torque applications
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Active Feedback sensing Technology (AFT) automatically shuts down the tool if there is a sudden
drop in rotation speed (e.g. kick-back)
• Brushless DC motor with high power to weight and size ratio
• Anti-restart feature prevents accidental start up
of tool during battery changing when switch
is locked in the on position
• Battery guard protects batteries from shocks,
(e.g. fall damage, bumps, etc.)
9" Angle Grinder
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Grinding Wheel
9" (230 mm)
No Load Speed
6,000 RPM
Arbor Size
5/8" - 11 UNC
Overall Length
19-5/8" (499 mm)
Net Weight
9.9 lbs (4.5 kg)
DGA900Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Toolless Wheel Cover (123543-6), Side Handle (143486-6),
Lock Nut Wrench 28 (782412-6), Inner Flange (224500-8), Lock Nut 5/8"-45 (224486-6)
Two-Stage Safety
Paddle Switch,
Electric Brake
