18V LI-IONFLASHLIGHTS
Description
Features (BATTERIES NOT INCLUDED)
Continuous Run Time
Net Weight (No Battery)
Up To
710
Lumens
LED Worklight
DML807
• Operates in 180°or 360° lantern modes or
flashlight mode
• Features 20 x LEDs with up to 710 Lumens
• Built in USB port enables convenient charging
of mobile devices on the jobsite
11 Hours Full Brightness
(with Battery BL1850B)
0.9 lbs
(0.4 kg)
Up To
620
Lumens
LED Worklight
DML806
• Operates in 180°or 360° lantern modes or
flashlight mode
• Features 20 x LEDs with up to 620 Lumens
• Retractable sky hook for added convenience
11 Hours Full Brightness
(with Battery BL1850B)
0.9 lbs
(0.4 kg)
240
Lumens
LED Flashlight
DML801
• Rotatable (Left or Right) and Foldable Head
Design enables flashlight to be positioned in
numerous configurations for maximum versatility
in a variety of applications
• Foldable Head features 7 Positive Stops at
0°, 30°, 60°, 90°, 120°, 150°, 180°
17 Hours Full Brightness
(with Battery BL1850B)
0.7 lbs
(0.3 kg)
190
Lumens
LED
Flashlight
DML808
• Pivoting Head features 12 Positive Stops at 110°, 90°,
75°, 60°, 45°, 30°, 15°, 0°, -15°, -30°, -45°, -60°
• Zoom ring function adjusts the irradiation range
up to 5x larger area
• High luminance single LED light
Up to 26 Hours
(with Battery BL1850B)
0.9 lbs
(0.4 kg)
180
Lumens
Xenon
Flashlight
DML185
• 4-position pivoting head for greater versatility
• High luminance single xenon bulb
emits 180 lumens
• Includes shoulder strap and replacement bulb
stored in flashlight head for convenience
Up to 7.6 Hours
(with Battery BL1850B)
0.9 lbs
(0.4 kg)
Up To
180
Lumens
LED
Flashlight Radio
DMR050
• Pivoting Head features 6 Positive Stops at
90°, 60°, 30°, 0°, -30°, -60°
• Features 3 LED Lights for high illumination
• LED charge level indicator displays approximate
remaining battery power
Radio Only Approx. 38 Hours
(with Battery BL1850B)
Light Only Approx. 14.5 Hours
(with Battery BL1850B)
Radio and Light Approx. 10 Hours
(with Battery BL1850B)
1.3 lbs
(0.6 kg)
30
Lumens
LED Flashlight
DML186
• Wide and Bright Illumination on the Jobsite
• 6 LED Lights provide maximum illumination
• Convenient Hook & Loop Carrying Strap
Approx. 30 Hours Full Brightness
(with Battery BL1830B)
0.4 lbs
(0.2 kg)
DML807, DML806, DML801, DML808 and DMR050 are compatible with 14.4V Li-Ion Batteries
FLASHLIGHTS &BULBSQUICKREFERENCE CHART
Flashlight
LED Circuit Board
Fluorescent Tube
Incandescent Bulb
Model No.
Battery Type
Voltage
Part No.
Part No.
Part No.
BML360
Li-Ion Slide
36V
-
A-95015
-
DML185 / BML185
18V
-
-
A-90261
DML801 / LXLM03
18V
GM00001284
-
-
DML186 / LXLM01
18V
GM00001187
-
-
DMR050 / LXRM01
18V
SE00000109
-
-
DML807
14.4V / 18V
GM00001465
-
-
DML802 / LXLM04
14.4V / 18V
GM00001213
-
-
DML184 / BML184
14.4V / 18V
-
SM00000050
A-94502
BML145
14.4V
-
-
A-90233
ML103
12V
GM00001493
-
-
ML102
Li-Ion Pod
12V
TE00000122
-
-
LM02
12V
GM00001243
-
-
BML240
Ni-MH Slide
24V
-
-
A-90984
ML902
Ni-Cad or Ni-MH Stick
9.6V
-
-
192545-3
ML702
7.2V
-
-
192242-1
ML183
Ni-Cad or Ni-MH Pod
18V
-
A-90978
-
ML180
18V
-
-
A-90261
ML143
14.4V
-
A-90978
-
ML140
14.4V
-
-
A-90233
ML123
12V
-
A-90978
-
ML120
12V
-
-
A-90233
ML903
9.6V
-
-
192545-3
ML901
9.6V
-
-
192545-3
