60 / 220
10.8V LXT / 7.2V LXT / 3.6V LXT
Power Tools
makita.ca
58
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
DF001DW
STANDARD EQUIPMENT INCLUDES:
Plastic Carrying Case, USB Cable (661753-2),
ACAdapterADP07 (198372-6), 81 Pc Bit Case Set
Features Built-In 3.6V (1.5 Ah)
Li-Ion Battery
Includes 81 Piece Accessory Set
• Adjustable hinged handle enables easy straight
or pistol style operation
• LED job light with Independent On / Off Switch
illuminates work area
• Built-in battery eliminates need to transport
and store additional batteries
• Includes AC charging adapter with
micro-USB connector
• Accessory set includes: magnetic bit holder,
nutsetters 3/16", 1/4", 9/32", 5/16", 11/32", 3/8"
2" driver bits PH1, PH2, PH3, T20, T25, T30
1" insert bits: SQ0 (3), SQ1 (3), SQ2 (3), SQ3 (3)
PH0 (3), PH1 (3), PH2 (3), PH3 (3), T10 (2),
T15 (2) T20 (3), T25 (3), T27 (2), T30 (3),
T40 (2) PZ0 (1), PZ1 (2), PZ2 (2), PZ3 (1),
Hex 3/32" (2) 1/8" (2), 5/32" (2), 3/16" (2),
1/4" (2), 5/64" (2) SL4-5 (3), SL6-8 (3),
SL10-12 (3)
1/4" Screwdriver
SPECIFICATIONS
Battery
3.6V (1.5 Ah) Li-Ion
Hex Shank
1/4"
No Load Speed
220 RPM
Maximum Torque
53 in. lbs (6.0 Nm)
Overall Length
11-1/4" (287 mm)
Net Weight
0.8 lbs (0.36 kg)
Reversible
DF012DSE
STANDARD EQUIPMENT INCLUDES:
Two 7.2V (1.5Ah) Li-Ion Batteries
BL0715 (198001-1), Charger (DC10WB), Phillips Bit 1-50 (784245-5), Phillips Bit 2-50 (784244-7),
Battery Plastic Case (824781-0), Plastic Carrying Case (158775-6)
Compact And Lightweight Design With Precision Control
• Auto stop system indicates battery power reduction and stops operation when battery reaches minimal
capacity in order to prevent incomplete fastening
• Auto stop clutch stops motor automatically when clutch is disengaged
• Adjustable handle with enhanced hinge mechanism for operational versatility
• Locking feature prevents accidental start up and enables use as a hand-held screwdriver
• LED job light illuminates work area and features independent on/off switch
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
1/4" Driver / Drill
SPECIFICATIONS
Battery Capacities
7.2V Li-Ion
Hex Shank
1/4"
Capacities:
Steel
3/16" (5 mm)
Wood
1/4" (6 mm)
No Load Speed:
Low
0 - 200 RPM
High
0 - 650 RPM
Maximum Torque
71 in. lbs (8.0 Nm)
Overall Length
8-5/8" (218 mm)
Net Weight
1.2 lbs (0.53 kg)
Variable 2-Speed,
Reversible
STANDARD EQUIPMENT INCLUDES:
7.2V (1.5Ah) Li-Ion Battery
BL0715 (198001-1), Pod / Stick Charger (DC10WB), Holster (168435-2),
Phillips Bit 2-50 (784244-7),Tool Bag (831277-4)
1/4" Cordless Impact Driver
SPECIFICATIONS
Battery Capacities
7.2V Li-Ion
Hex Shank
1/4"
Impacts Per Minute
0 - 3,000 IPM
No Load Speed
0 - 2,450 RPM
Maximum Fastening Torque
220 in. lbs (25 Nm)
Capacities:
Machine Screw 1/8" - 5/16" (M3 - M8)
Standard Bolt
1/8" - 5/16" (M3 - M8)
High Tensile Bolt 1/8" - 1/4" (M3 - M6)
Overall Length
11-1/8" (282 mm)
Net Weight
1.2 lbs (0.56 kg)
TD022DS
Variable Speed, Reversible,
Electric Brake
Compact And Lightweight Design With Precision Control
And High Fastening Torque
• Multi-function variable speed rotary switch allows operators to adjust driving speed and direction
simultaneously for precise fastening applications
• Switch position enables easy access for left or right handed users
• Lock-off button prevents accidental startup
• Adjustable handle with enhanced hinge mechanism for operational versatility
• LED job light with pre-glow feature
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Floor Nozzle (123485-4), Pipe (451424-7), Sash Nozzle (416041-0),
Sash Nozzle Holder (416043-6), Paper Filter (5 / Pk) (194566-1)
330 ml Vacuum Cleaner
CL072DZ
Lightweight And Portable Vacuum Cleaner
For Shop, Office Or Home Use
• Hinged front cover opens with push button for quick
and easy access to dust bag
• 2-Speed power button with lock-on feature allows
for continuous use without having to keep
button depressed
• Battery capacity warning light indicates ideal
time to recharge battery
• On board sash nozzle storage
• Angled suction port enables
easy floor cleaning without
floor nozzle and prevents
extension pipes from
wobbling during
operation
2-Speed
SPECIFICATIONS
Battery Capacities
7.2V Li-Ion
Container Capacity:
500 ml (Dust Bag)
330 ml (Paper Bag)
Continuous Use with 7.2V (1.5 Ah) Battery:
Approx. 12 minutes (High)
Approx. 24 minutes (Low)
Maximum Air Flow
32 CFM
Power:
14 W (High) / 6 W (Low)
Static Water Lift
9.2" (230 mm)
Overall Length
38-3/4" (984 mm)
Net Weight
2.0 lbs (0.9 kg)
STANDARD EQUIPMENT INCLUDES:
Floor Nozzle (198150-4), Pipe (451424-7), Sash Nozzle (416041-0), Sash Nozzle Holder (416043-6), Reusable Nylon Pre-Filter (451208-3),
Reusable Cloth Filter (443060-3), Charger (DC1001)
560 ml Vacuum Cleaner
SPECIFICATIONS
Battery
10.8V Li-Ion
Container Capacity
560 ml
Charging Time with DC1001 Charger
Approx. 180 minutes
Continuous Use
Approx. 12 minutes
Maximum Air Flow
49.4 CFM
Power
21 W
Static Water Lift
14" (350 mm)
Overall Length
35-3/4" (900 mm)
Net Weight
2.1 lbs (0.94 kg)
CL111DWI
Lightweight & Portable Vacuum Cleaner for Shop, Office
or Home Use / Features Built-In 10.8V Li-Ion Battery
• Easy to empty dust canister minimizes downtime and
maximizes vacuuming efficiency
• 2-stage nylon and cloth filter
• Battery Capacity Warning Light indicates ideal time to
recharge battery and completion of charging cycle
• Built-in Battery eliminates need to transport and store
additional batteries
• On board Sash Nozzle Storage
• Angled suction port enables easy
cleaning without floor nozzle and
prevents extension pipes from
Increased Air Flow and
Sealed Suction for Maximum
Performance
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Floor Nozzle (123485-4), Pipe (451424-7), Sash Nozzle (416041-0),
Sash Nozzle Holder (416043-6), Reusable Nylon Pre-Filter (451208-3), Reusable Cloth Filter (443060-3)
600 ml Vacuum Cleaner
SPECIFICATIONS
Battery Capacities
7.2V Li-Ion
Container Capacity
600 ml
Continuous Use with 7.2V (1.5 Ah) Battery
Approx. 12 minutes
Maximum Air Flow
42 CFM
Power
14 W
Static Water Lift
7.2" (180 mm)
Overall Length
38-1/32" (966 mm)
Net Weight
1.6 lbs (0.7 kg)
CL070DZ
Lightweight & Portable Vacuum Cleaner For Shop,
Office Or Home Use
• Cloth filtration system enables easy disposal of dust,
eliminating the need for disposable paper bags
• Angled suction port enables easy floor cleaning without
floor nozzle and prevents extension pipes from
wobbling during operation
• Floor nozzle swivel joint keeps vacuum head close
to surface when cleaning in tight spaces,
such as beneath sofas, providing
maximum performance
• On board sash nozzle storage
• Low noise level at just 70 dB ideal
for quiet cleaning operation in
noise sensitive environments
Makita offers a wide variety of
ACCESSORIES!
