58 / 220
12VMAX LXT
Power Tools
makita.ca
56
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Makita offers a wide variety of
ACCESSORIES!
ML105
• Compact aluminum head for
increased durability and versatility
in small areas
• Pivoting head features 12 positive
stops at 110º, 90º, 75º, 60º, 45º, 30º,
15º, 0º, -15º, -30º, -45º, -60º
• High luminance single LED light
• Multi-faceted reflector provides clear
round spot light with uniform brightness
• Removable strap hook for added convenience
• Use with optional Magnetic Adapter
(GM00001714) for hands free attachment to
metal studs, pipe, beams and more!
• BATTERY NOT INCLUDED
LED Flashlight
SPECIFICATIONS
Battery Capacities
12V MAX CXT Li-Ion
Continuous Use
Approx. 14 Hours (with Battery BL1041B)
Overall Dimensions (L x W x H)
10-1/2" x 2-5/8" x 3-5/8" (268 mm x 66 mm x 93 mm)
Net Weight
1.5 lbs (0.7 kg)
GM00001714
Magnetic Adapter for 12V MAX CXT Li-Ion
Flashlights & Worklights
• Attaches quickly and easy to metal pipes, steel studs / beams,
panel boxes, vehicle hoods, fixtures, equipment and more to
enable hands free operation
• For use with ML104 & ML105
12V MAX CXT Li-Ion Worklight
& Flashlight
Magnetic Adapter
ML104
• Operates in 180º or 360º lantern modes or
flashlight mode
• Features 20 x LEDs with up to 710 Lumens
• Built in USB port enables convenient charging
of mobile devices on the jobsite
• eXtreme Protection Technology (XPT) offers
maximum protection against dust, debris
and liquids for optimal performance in
extreme conditions
• Retractable sky hook for added convenience
• Use with optional Magnetic Adapter
(GM00001714) for hands free attachment to
metal studs, pipe, beams and more!
• BATTERY NOT INCLUDED
LED Worklight
SPECIFICATIONS
Battery Capacities
12V MAX CXT Li-Ion
Continuous Use
Approx. 19 Hours (with Battery BL1041B)
Overall Dimensions (L x W x H)
14-1/8" x 2-5/8" x 4" (360 mm x 66 mm x 132 mm)
Net Weight
1.7 lbs (0.78 kg)
710
Lumens
ML106
• 4.9W high-illuminance single white LED
• Multi-faceted
reflector provides
clear round spot
light with uniform
brightness
• Zoom ring function
adjusts the irradiation range
up to 5x larger area
• 12 position pivoting flashlight
head with positive
stops (from 0° to 170°)
• Removable strap hook for added
convenience
• Use with optional Magnetic
Adapter (GM00001714)
• BATTERY NOT INCLUDED
LED Flashlight
SPECIFICATIONS
Battery Capacities
12V MAX CXT Li-Ion
Continuous Use
Approx. 12 Hours (with Battery BL1041B)
Overall Dimensions (L x W x H)
11-3/8" x 2-5/8" x 3-5/8" (290 mm x 66 mm x 93 mm)
Net Weight
0.88 lbs (0.40 kg)
ML103
• Over-discharge protection circuit protects battery against
over-discharge to ensure optimal battery life
• Push button ON / OFF switch
• Soft rubber grip design for comfortable operation
• BATTERY NOT INCLUDED
LED Flashlight
MR052
Compact Design For Maximum Portability
• LCD Digital Display with Backlight
• Rubber FM Antenna
• 5 FM / 5 AM Preset Function
• Push Button AM/FM Digital Tuning Feature
• Digital and Manual Tuning Feature
• Digital Volume Control
• Auxiliary Input & Earphone Jack
• Dual Front Speakers produce clear,
high quality sound
Jobsite Radio
SPECIFICATIONS
Battery Capacities
12V MAX CXT Li-Ion
Continuous Run Time
Approx. 30 Hours (with 4.0 Ah BL1041B)
Overall Dimensions (L x W x H)
6-5/8" x 2-7/8" x 2-15/16" (169 mm x 73 mm x 74 mm)
Net Weight
0.8 lbs (0.35 kg)
SPECIFICATIONS
Battery Capacities
12V MAX CXT Li-Ion
Continuous Use
Approx. 28 Hours (with Battery BL1041B)
Overall Dimensions (L x W x H)
3" x 2-1/8" x 1-1/8" (77 mm x 54 mm x 28 mm)
Net Weight
0.1 lbs (0.06 kg)
100
Lumens
190
Lumens
SK106GDZ
GREEN LASER
STANDARD EQUIPMENT INCLUDES:
SK106GDZ:
Pro L-Adapter (LE00870134),
GreenTarget Plate (LE00823195), Soft Case (LE00864505)
SK106DZ:
Pro L-Adapter (LE00870134),
RedTarget Plate (LE00758831), Soft Case (LE00864505)
IP54 Rated
• Green laser for increased visibility in bright working conditions (SK106GDZ only)
• 2 brightness mode selections: Eco mode, Bright mode
• Powered by 12V MAX CXT batteries with option to use DC jack allowing power
to be supplied from 18V Li-Ion batteries by using
USB adapter ADP05 and power supply cable
• Laser beam selection button allows for:
Horizontal + vertical line + left / right / up / down
4 points, Horizontal line + left / right 2 points, or
Vertical line + up/down 2 points
Cross Line + 4 Points Laser Levels
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Laser:
SK106GDZ
Line Beam Color
Green
SK106DZ
Line Beam Color
Red
Output
1 mW or less
Safety Class
Class 2
SK106GDZ
Wavelength
525 nm
SK106DZ
Wavelength
635 nm
Line Width at 5m
2.0 mm
Vertical Line Indication Range
+/- 4°
Accuracy
+/- 3 mm / 10 m
Overall Dimensions
(L x W x H w/o Protrusions)
5-7/16" x 2-1/2" x 4"
(138 mm x 64 mm x 102 mm)
Net Weight
1.0 lbs (0.46 kg)
SK106DZ
RED LASER
SK106GDZ
SK106DZ
SK105GDZ
GREEN LASER
STANDARD EQUIPMENT INCLUDES:
SK105GDZ:
L-Adapter (LE00870131),
GreenTarget Plate (LE00823195), Soft Case (LE00864505)
SK105DZ:
L-Adapter (LE00870131),
RedTarget Plate (LE00758831), Soft Case (LE00864505)
IP54 Rated
• Green laser for increased visibility in bright working conditions (SK106GDZ only)
• 2 brightness mode selections: Eco mode, Bright mode
• Powered by 12V MAX CXT batteries with option to use DC jack allowing power
to be supplied from 18V Li-Ion batteries by using
USB adapter ADP05 and power supply cable
• Laser beam selection button allows for:
Horizontal + vertical line, Horizontal line only,
or Vertical line only
• Levelling Lock Switch disables self-levelling feature
for sloped line applications, and protects the
self-levelling mechanism during transport
Cross Line Laser Levels
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Laser:
SK105GDZ
Line Beam Color
Green
SK105DZ
Line Beam Color
Red
Output
1 mW or less
Safety Class
Class 2
SK105GDZ
Wavelength
525 nm
SK105DZ
Wavelength
635 nm
Line Width at 5m
2.0 mm
Vertical Line Indication Range
+/- 4°
Accuracy
+/- 3 mm / 10 m
Overall Dimensions
(L x W x H w/o Protrusions)
5-7/16" x 2-1/2" x 4"
(138 mm x 64 mm x 102 mm)
Net Weight
1.0 lbs (0.46 kg)
SK105DZ
RED LASER
SK105GDZ
SK105DZ
