CG100DZC
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Safety Goggle (195246-2)
Ideal For Quick and Precise Application of Caulking and Sealants
Accepts Standard 800 ml Cartridges
• Anti-drip function eliminates residual pressure on caulking tube to prevent caulking from escaping
when the trigger is released
• Variable speed dial allows operator to set maximum dispensing speed while the variable speed trigger
enables fine adjustment for maximum control and precision in a wide range of applications
• 360° rotating tube tray allows operator to adjust positioning based on materials or application
• Overload protection feature with warning light prevents motor
burnout caused by overloading
• Battery protection system provides over-discharge,
temperature and circuit protection for
enhanced performance, battery cycle
life and overall battery life
800 ml Caulking Gun
SPECIFICATIONS
Battery Capacities
12V MAX CXT Li-Ion
Max. Pushing Force
1,100 lb (5,000 N)
Compatible Sealant Size:
Cartridge, Sausage Pack
Dimensions (L x W x H)
18-7/8" x 4-1/4" x 11-1/4"
(480 mm x 108 mm x 286 mm)
Net Weight
4.5 lbs (2.5 kg)
Anti-Drip Function,
Variable Speed
CG100DZB
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Three Nozzle (454226-0), Rubber Ring (424547-4),
PistonA (142071-2), Piston C (123221-8), Safety Goggles (195246-2)
Ideal For Quick and Precise Application of Caulking and Sealants
Accepts Standard 600 ml Cartridges, Sausage Packs and Bulk Caulking or Sealants
• Anti-drip function eliminates residual pressure on caulking tube to prevent caulking from escaping
when the trigger is released
• Variable speed dial allows operator to set maximum dispensing speed while the variable speed trigger
enables fine adjustment for maximum control and precision in a wide range of applications
• 360° rotating tube tray allows operator to adjust positioning based on materials or application
• Overload protection feature with warning light prevents motor burnout caused by overloading
• Battery protection system provides over-discharge, temperature and circuit protection
for enhanced performance,
battery cycle life and
overall battery life
600 ml Caulking Gun
SPECIFICATIONS
Battery Capacities
12V MAX CXT Li-Ion
Max. Pushing Force
1,100 lb (5,000 N)
Compatible Sealant Size:
Cartridge, Sausage Pack, Bulk Sealant
Dimensions (L x W x H)
21-1/4" x 4-1/4" x 11"
(538 mm x 108 mm x 278 mm)
Net Weight
4.9 lbs (2.2 kg)
Anti-Drip Function,
Variable Speed
CG100DZA
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Safety Goggle (195246-2)
Ideal For Quick and Precise Application of Caulking and Sealants
Accepts Standard 300 ml Cartridges
• Anti-drip function eliminates residual pressure on caulking tube to prevent caulking from escaping
when the trigger is released
• Variable speed dial allows operator to set maximum dispensing speed while the variable speed trigger
enables fine adjustment for maximum control and precision in a wide range of applications
• 360° rotating tube tray allows operator to adjust positioning based on materials or application
• Overload protection feature with warning light prevents motor burnout caused by overloading
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall
battery life
300 ml Caulking Gun
SPECIFICATIONS
Battery Capacities
12V MAX CXT Li-Ion
Max. Pushing Force
1,100 lb (5,000 N)
Compatible Sealant Size
Cartridge
Dimensions (L x W x H)
15-7/8" x 4-1/4" x 11"
(404 mm x 108 mm x 278 mm)
Net Weight
3.8 lbs (1.7 kg)
Anti-Drip Function,
Variable Speed
PT354DZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Two NoseAdapter (422372-7), Safety Goggles (195246-2),
Hex Wrench 3 (783201-2), Hook (346909-5)
Hose-Free Maneuverability And Control With Low Reaction Force
• Low reaction force mechanism for easy, high-quality nailing of long pins in hard density materials
• Slim contact tip design enables precise fastening in wood trim, crown moulding, baseboard, cabinetry
and other woodworking applications!
• On-board depth control dial for quick and easy adjustment
• Trigger lock-off feature prevents accidental firing for increased operator safety
• Anti-dry fire mechanism prevents added wear on drive pin
23 ga Pin Nailer
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Magazine Capacities
100 nails
Gauge
23 ga
Pin Length 5/8", 11-16", 1", 1-3/16", 1-3/8"
(15 mm, 18 mm, 25 mm, 30 mm, 35 mm)
Overall Length
9-1/8" (231 mm)
Net Weight
3.6 lbs (1.6 kg)
Anti-drip function
eliminates residual
pressure on
caulking tube
CL108FDZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Floor Nozzle (123488-8), Sash Nozzle (451243-1), Pipe (451244-9),
Sash Nozzle Holder (451245-7), High Efficiency Filter (198752-6)
12V MAX CXT Li-Ion Cordless
3-Speed Cleaner
• Stronger suction power for faster cleaning
with more run time
• Built-in LED light illuminates the work area
• Battery capacity warning light indicates
ideal time to recharge battery
• Push button air volume selection
(Turbo / High / Low)
• Floor nozzle swivel joint design
keeps vacuum head close to surface
and enables 360º rotation for
easy high-reach cleaning
600 ml Vacuum Cleaner
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Container Capacity
600 ml (20.2 oz)
Continuous Use with 12V (4.0 Ah) MAX
CXT Battery:
Approx. 20 minutes (Turbo)
Approx. 24 minutes (High)
Approx. 50 minutes (Low)
Maximum Air Flow
42 CFM
Power:
30 W (Turbo) / 20 W (High) / 5 W (Low)
Static Water Lift
17.7" (450 mm)
Overall Length
37-5/8" (956 mm)
Net Weight
1.9 lbs (0.8 kg)
Includes LED Job Light
