57 / 220
12VMAXCXT
Power Tools
makita.ca
55
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
When
QUALITY&SERVICE
Counts – ChooseMakita
SK209GDZ
GREEN LASER
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Laser Viewing Glass (TK02100200), Shoulder Harness (TK00SB0001),
Storage Case (TKAK400MUN)
2 Vertical Lines & 1 Horizontal Line / IP54 Rated
• Green laser ideal for increased visibility in bright working conditions
• 3 brightness mode selections: eco, normal, bright
• Powered by 12V MAX CXT Li-Ion batteries with option to use DC adapter allowing
power to be supplied from 18V Li-Ion batteries by
using USB Adapter ADP05 and power supply cable
Laser Level (2V/1H)
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Laser:
Line Beam Color
Green
Output
1 mW or less
Safety Class
Class 2
Wavelength
510 - 530 nm
Line Width at 10m
2.5 mm
Vertical Line Indication Range
+/- 2°
Accuracy:
2-Vertical Line
90° +/- 0.01°
Emitted Laser
+/- 1 mm / 10 m
Overall Dimensions
(L x W x H w/o Protrusions)
4-3/4" x 5-1/8" x 9"
(122 mm x 130 mm x 230 mm)
Net Weight
2.7 lbs (1.2 kg)
SK312GDZ
GREEN LASER
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Laser Viewing Glass (TK02100200), Shoulder Harness (TK00SB0001),
Storage Case (TKAK400MUN)
3 Vertical Lines & 1 Horizontal Line / IP54 Rated
• Green laser ideal for increased visibility in bright working conditions
• 3 brightness mode selections: eco, normal, bright
• Powered by 12V MAX CXT Li-Ion batteries with option to use DC adapter allowing
power to be supplied from 18V Li-Ion batteries by
using USB Adapter ADP05 and power supply cable
Laser Level (3V/1H)
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Laser:
Line Beam Color
Green
Output
1 mW or less
Safety Class
Class 2
Wavelength
510 - 530 nm
Line Width at 10m
2.5 mm
Vertical Line Indication Range
+/- 2°
Accuracy:
2-Vertical Line
90° +/- 0.01°
Emitted Laser
+/- 1 mm / 10 m
Overall Dimensions
(L x W x H w/o Protrusions)
4-3/4" x 5-1/8" x 9"
(122 mm x 130 mm x 230 mm)
Net Weight
2.7 lbs (1.2 kg)
CF100DZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
ACAdapter (TE00000213)
Compact And Lightweight 7-1/8" Diameter Fan Ideal For
Use In A Wide Variety Of Areas
• Integrated keyhole mounting slots allow fan to be installed directly on walls, stud frames, shops,
facilities, vehicles, temporary shelters and more!
• Adjustable hook / handle enables easy carrying and attachment to a variety of objects, including pipes,
scaffolding and more!
• Adjustable fan head for accurate and effective positioning
• Push button control - ON / OFF & HIGH / MEDIUM / LOW
• Operates on AC or DC power sources for
maximum productivity
• Use with Makita Tripod GM00001381
Cordless or Electric Jobsite Fan
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Continuous Run Time:
High up to 275 mins (with Battery BL1041B)
Medium up to 380 mins (with Battery BL1041B)
Low up to 630 mins (with Battery BL1041B)
Overall Length
5-7/8" (158 mm)
Net Weight
2.3 lbs (1.0 kg)
3-Speed
CF101DZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Compact And Lightweight 7-1/8" Diameter Fan Ideal For
Use In A Wide Variety Of Areas
• Off-timer switch enables automatic shutoff after 1, 2 or 4 hours of runtime
• Automatic oscillation switch swings fan in a 45° left/right range for maximum air distribution
• Adjustable hook / handle enables easy carrying and attachment to a variety of objects, including pipes,
scaffolding and more!
• Adjustable fan head (90º upwards, 45º downwards, 90º left or right)
for accurate and effective positioning
• Push button control - ON / OFF & HIGH / MEDIUM / LOW
• Operates on AC or DC power sources for maximum
productivity
• Use with Makita
Tripod GM00001381
Cordless or Electric Jobsite Swing Fan
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Continuous Run Time:
High up to 275 mins (with Battery BL1041B)
Medium up to 380 mins (with Battery BL1041B)
Low up to 630 mins (with Battery BL1041B)
Overall Length
7-1/4" (185 mm)
Net Weight
2.8 lbs (1.3 kg)
3-Speed
UH201DZ
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.
ShearBladeAssemblySet (198409-9),BladeCover (195274-7),
ChipReceiverSet (198402-3)
Compact Design For Added Versatility
• Dual Blade action cuts quickly with shearing effect
• Chip Receiver prevents material from falling onto blade
• Non-Electrolyzed Nickel Plated Blades reduce staining and rusting
• Tool-less Blade Changing System enables simple and easy blade changes
7-7/8" Hedge Trimmer
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
No Load Speed
2,500 SPM
Cutting Length
7-7/8" (200 mm)
Maximum Cutting Thickness 5/16" (8 mm)
Overall Length
19-7/8" (504 mm)
Net Weight
2.5 lbs (1.1 kg)
Optional Grass
Shear Attachment
for UH201DZ
Shear BladeAssembly
195176-7
Blade Cover
452055-5
Grass Catcher
457426-1
Chip Receiver Set
(Standard Equipment)
(Part No. 198402-3)
UM600DZ
12V MAX CXT Slide
STANDARD EQUIPMENT INCLUDES:
UM600DZ:
ToolOnly.BatteriesandChargerSoldSeparately.
ShearBladeAssembly (195176-7),BladeCover (452055-5),GrassCatcher (457426-1)
MU01Z:
Tool Only. Batteries and Charger Sold Separately.
Shear BladeAssembly (195176-7), Base Frame (325896-1),
Change Lever (451813-6), Blade Cover (452055-5)
Compact Design For Added Versatility
• Dual Blade action cuts quickly with shearing effect
• Non-Electrolyzed Nickel Plated Blades reduce staining and rusting
• Grass Catcher enables quick and easy depth adjustment
• Tool-less Blade Changing System enables simple and easy blade changes
6-5/16" Grass Shears
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
No Load Speed
2,500 SPM
Cutting Width
6-5/16" (160 mm)
Depth Adjustment
5/8" / 13/16" / 1"
(15 mm / 20 mm / 25 mm)
Overall Length
13-5/8" (347 mm)
Net Weight
2.5 lbs (1.1 kg)
Optional Hedge
Trimmer Attachment
for UM600DZ or MU01Z
Shear BladeAssembly
198409-9
Chip Receiver Set
198402-3
Blade Cover
195274-7
MU01Z
12V MAX (1.3 Ah) Pod
UM600DZ
UM600DZ:
12V MAX CXT Slide
MU01Z:
12V MAX (1.3 Ah) Pod
MU01Z
