95 / 220
Electric
Power Tools
makita.ca
93
When
QUALITY&SERVICE
Counts – ChooseMakita
STANDARD EQUIPMENT INCLUDES:
16-5/16" C.T. Blade 32T (A-95093), Hex Wrench 6 (783204-6), Guide Rule (164019-4), Protective Stand Set (194701-1)
Large Capacity For Beam And Timber Cutting
• Powerful Motor delivers 1,800 max. watts out
• Rugged Steel Base for maximum stability
• Electric Brake for increased operator safety
• Blade Stabilizer for stable blade rotation
and superior cutting performance
• Large Depth Control Lever for
convenience and secure adjustments
Electric Brake,
Cutting Capacity of 6-1/4" (158 mm)
16-5/16" Circular Saw
SPECIFICATIONS
Blade Diameter
16-5/16" (415 mm)
Arbor
1" (25 mm)
Maximum Cutting Capacities:
0°
6-1/4" (158 mm)
45°
4-3/16" (106 mm)
No Load Speed
2,300 RPM
AMPS (120V)
15.0 A
Overall Length
24-1/4" (616 mm)
Net Weight
32.2 lbs (14.6 kg)
5402NA
STANDARD EQUIPMENT INCLUDES:
10-1/4" C.TBlade 24T (A-94910), Hex Wrench 6 (783204-6), Guide Rule (164367-1), Wrench Holder 5.6 (410047-0)
Ideal For Single Pass Cutting Of 4X Material
• Lock-off button prevents accidental start-up for operator safety
• Lightweight design with magnesium safety cover and blade case
• Diecast aluminum base for maximum operational stability
• Compact blade case with reduced width for enhanced operational versatility
• Rear angular guide allows easy and precise adjustment of bevel angle
• Adjustment screws enable operator to easily square base plate to blade
• Large top handle for easy carrying
• Flat motor housing for stability during
blade changes
• Bevel capacity of 0° - 50°
10-1/4" Circular Saw
SPECIFICATIONS
Blade Diameter
10-1/4" (260 mm)
Arbor
5/8" (15.88 mm)
Maximum Cutting Capacities:
0°
3-13/16" (97 mm)
45°
2-11/16" (68 mm)
No Load Speed
4,300 RPM
AMPS (120V)
15.0 A
Overall Length
16-1/2" (418 mm)
Net Weight
15.2 lbs (6.9 kg)
HS0600
STANDARD EQUIPMENT INCLUDES:
8-1/4" C.T. Blade 24T (D-21521), Hex Wrench 6 (783204-6), Guide Rule (164095-8)
High Performance Magnesium Blade Case And Base
• Electric Brake for operator safety
• Dual LED Job Lights illuminate cut line
• Blower feature keeps cutting line free of sawdust
• Bevel Capacity of 50° with Positive Stops at 22.5°, 45°, and 50°
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Cutting Depth Capacity Of 3" (75.5 mm)
Electric Brake
8-1/4" Circular Saw
SPECIFICATIONS
Blade Diameter
8-1/4" (210 mm)
Arbor
5/8" (15.9 mm)
Maximum Cutting Capacities:
0°
3" (75.5 mm)
45°
2-1/4" (57 mm)
50°
2" (51.5 mm)
No Load Speed
5,200 RPM
AMPS (120V)
15.0 A
Overall Length
13-1/8" (332 mm)
Net Weight
11.2 lbs (5.1 kg)
5008MGA
STANDARD EQUIPMENT INCLUDES:
5007MG & 5007MGA:
7-1/4" C.T. Blade 24T (1 Ea.A-94530-10), Hex Wrench 6 (783204-6), Guide Rule (164095-8),
Plastic Carrying Case (158279-8)
High Performance Magnesium Blade Case And Base
• Dual LED Job Lights illuminate cut line
• Blower feature keeps cutting line free of sawdust
• Bevel Capacity of 56° with Positive Stops at 22.5°, 45°, and 56°
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Cutting Capacity Of 2-1/2" (63.5 mm)
Electric Brake (5007MGA)
7-1/4" Circular Saw
SPECIFICATIONS
Blade Diameter
7-1/4" (185 mm)
Arbor
5/8" (15.9 mm)
Maximum Cutting Capacities:
0°
2-1/2" (63.5 mm)
45°
1-3/4" (45 mm)
56°
1-3/8" (35 mm)
No Load Speed
5,800 RPM
AMPS (120V)
15.0 A
Overall Length
12-1/2" (317 mm)
Net Weight
10.6 lbs (4.8 kg)
5007MG
5007MGA
High Power To Weight Ratio
• Electric Brake for increased operator safety
• Heavy Duty Aluminum Base Plate for
jobsite durability
• LED Job Light with Independent On / Off Switch
• Flat Motor Housing provides stability during
blade changes
• Bevel Capacity of 45°
Cutting Capacity Of 2-3/8" (60 mm)
Electric Brake
7-1/4" Circular Saws
SPECIFICATIONS
Blade Diameter
7-1/4" (185 mm)
Arbor
5/8" (15.9 mm)
Maximum Cutting Capacities:
0°
2-3/8" (60 mm)
45°
1-3/4" (46 mm)
No Load Speed
5,800 RPM
AMPS (120V)
15.0 A
Overall Length
12" (305 mm)
Net Weight
11.1 lbs (5.0 kg)
STANDARD EQUIPMENT INCLUDES:
7-1/4" C.T. Blade 24T (1 Ea.A-94530-10),
Offset Wrench 13 (782016-4), Guide Rule (164095-8),
Plastic Carrying Case (824473-1)
5007FAK
STANDARD EQUIPMENT
INCLUDES:
7-1/4" C.T. Blade 24T
(1 Ea.A-94530-10),
Offset Wrench 13 (782016-4)
5007FA
+
Plastic Carrying Case
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
10-1/4" C.T. Blade 24T (A-94910), Hex Wrench 6 (783204-6), Guide Rule (165499-7)
"SJS" Technology Prevents Kickback If Blade Jams, Protecting the
Operator And The Tool
• Electric Brake for increased operator safety
• Lock-Off Button prevents accidental start-up for operator safety
• Diecast Aluminum Base for maximum operational stability
• Compact Blade Case and reduced overall tool height for enhanced operational versatility
• Large Top Handle for easy carrying
• Flat Motor Housing for stability during blade changes
"SJS" Technology, Electric Brake,
Cutting Capacity of 3-3/4" (95 mm)
10-1/4" Circular Saw
SPECIFICATIONS
Blade Diameter
10-1/4" (260 mm)
Arbor
5/8" (15.9 mm)
Maximum Cutting Capacities:
0°
3-3/4" (95 mm)
45°
2-3/4" (69 mm)
No Load Speed
3,800 RPM
AMPS (120V)
15.0 A
Overall Length
16" (405 mm)
Net Weight
20.3 lbs (9.2 kg)
5104
Compatible with optional Makita 55" (194368-5)
and 118" (194367-7) Guide Rails using
Guide Rail Adapter (198566-3) for maximum
cutting ease and precision
Cutting
Capacity
Of 3-3/16"
(97 mm)
