STANDARD EQUIPMENT INCLUDES:
5007NB:
7-1/4" Blade 24T (D-51138), Offset Wrench 13 (782016-4)
5007N:
7-1/4" Blade 24T, Hex Wrench (783204-6)
Makita's Best Selling Circular Saw
• Heavy Duty Aluminum Base Plate for jobsite durability
• Well Balanced design for better control from above or behind the saw
•
5007NB
Bevel Capacity of 45°
•
5007N
Bevel Capacity of 56° with Positive Stops at 22.5°, 45°, and 56°
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
AC/DC
7-1/4" Circular Saw
SPECIFICATIONS
Blade Diameter
7-1/4" (185 mm)
Arbor
5/8" (15.9 mm)
Maximum Cutting Capacities:
90°
5007NB
2-3/8˝" (60 mm)
90°
5007N
2-1/2" (63.5 mm)
45°
5007NB / 5007N
1-3/4" (45 mm)
56°
5007N
1-3/8" (35 mm)
No Load Speed
5,800 RPM
AMPS (120V)
15.0 A
5007NB:
Overall Length 11-5/8" (236 mm)
Net Weight
10.9 lbs (4.9 kg)
5007N:
Overall Length 12-1/2" (317 mm)
Net Weight
14.6 lbs (6.6 kg)
5007NB
STANDARD EQUIPMENT INCLUDES:
7-1/4" Blade 24T, Hex Wrench 6 (783204-6)
Hypoid Gear System Provides Increased Power Transmission
• Ideal for Framers, Home Builders, Masons, and Contractors
• High quality, Hardened Steel Hypoid Gears do not wear like bronze-alloy worm drive gears
• Bevel Capacity of 51.5° with Positive Stops at 45° and 51.5° ideal for cutting trusses and rafters
• Ergonomic Soft Rubber Rear Grip design for vibration absorption and comfortable operation
7-1/4" Hypoid Saw
SPECIFICATIONS
Blade Diameter
7-1/4" (185 mm)
Arbor
5/8" (15.9 mm)
Maximum Cutting Capacities:
0°
2-3/8" (60 mm)
45°
1-3/4" (44 mm)
50°
1-9/16" (40 mm)
No Load Speed
4,500 RPM
AMPS (120V)
15.0 A
Overall Length
17-3/8" (442 mm)
Net Weight
14.3 lbs (6.5 kg)
5477NB
STANDARD EQUIPMENT INCLUDES:
7-1/4" C.T. Blade 24CT (1 Ea.A-94530-10), Hex Wrench 6 (783204-6)
Hypoid Gear System Provides Increased Power Transmission
• Ideal for Framers, Home Builders, Masons, and Contractors
• High quality, Hardened Steel Hypoid Gears do not wear like bronze-alloy worm drive gears
• High Performance Magnesium Base Plate, Blade Case and Motor Housing
• Bevel Capacity of 51.5° with Positive Stops at 22.5°, 45° and 51.5° ideal for cutting trusses and rafters
• Rafter Hook enables convenient storage on 2x materials when not in use
Cutting Capacity Of
2-3/8" (60 mm)
7-1/4" Hypoid Saw
SPECIFICATIONS
Blade Diameter
7-1/4" (185 mm)
Arbor
5/8" (15.9 mm)
Maximum Cutting Capacity:
0°
2-3/8" (60 mm)
45°
1-3/4" (44 mm)
50°
1-9/16" (40 mm)
No Load Speed
4,500 RPM
AMPS (120V)
15.0 A
Overall Length
17-3/4" (450 mm)
Net Weight
13.2 lbs (6.0 kg)
5377MG
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Cutting Capacity Of
2-3/8" (60 mm)
High Power To Weight Ratio
• Heavy Duty Aluminum Base Plate for
jobsite durability
• LED Job Light with Independent On / Off Switch
• Flat Motor Housing provides stability during
blade changes
• Bevel Capacity of 45°
Cutting Capacity Of 2-3/8" (60 mm)
AC/DC
7-1/4" Circular Saws
SPECIFICATIONS
Blade Diameter
7-1/4" (185 mm)
Arbor
5/8" (15.9 mm)
Maximum Cutting Capacities:
0°
2-3/8" (60 mm)
45°
1-3/4" (46 mm)
No Load Speed
5,800 RPM
AMPS (120V)
15.0 A
Overall Length
12" (305 mm)
Net Weight
11.1 lbs (5.0 kg)
STANDARD EQUIPMENT INCLUDES:
7-1/4" C.T.Blade24T (1Ea.A-94530-10),
OffsetWrench13 (782016-4),GuideRule (164095-8),
PlasticCarryingCase (824473-1)
5007FK
STANDARD EQUIPMENT
INCLUDES:
7-1/4" Blade 24T,
Offset Wrench 13
(782016-4)
5007F
+
Plastic Carrying Case
HS7600
New And Improved With High Power
To Weight Ratio
• Two-stage safety trigger switch prevents accidental start up
• Aluminum baseplate for added durability
• Flat motor housing provides
stability during blade changes
• Rear dust port
exhausts sawdust away
from operator for clean
and comfortable operation
• Bevel capacity of 45°
7-1/4" Circular Saw
SPECIFICATIONS
Blade Diameter
7-1/4" (185 mm)
Arbor
5/8" (15.88 mm)
Maximum Cutting Capacities:
0°
2-1/2" (64 mm)
45°
1-5/8" (42 mm)
No Load Speed
5,200 RPM
AMPS (120V)
10.5 A
Overall Length
12-1/8" (309 mm)
Net Weight
8.6 lbs (3.9 kg)
STANDARD EQUIPMENT INCLUDES:
1Ea.7-1/4" Blade 16T,HexWrench5 (783217-7)
5057KB
For Cutting Fibre-Cement Materials
• Dust Collection Container captures waste for
clean work environment
• Dust Proof Structure prevents contamination of motor
• Aluminum Baseplate for increased stability
• Guard Lever enables guard to be retracted for easier plunge
cutting applications
7-1/4" Circular Saw
SPECIFICATIONS
Blade Diameter
7-1/4" (185 mm)
Arbor
5/8" (15.9 mm)
Maximum Cutting Capacities:
0°
2-3/8" (60 mm)
45°
1-1/8" (30 mm)
No Load Speed
5,800 RPM
AMPS (120V)
13.0 A
Overall Length
14" (354 mm)
Net Weight
11.9 lbs (5.4 kg)
STANDARD EQUIPMENT INCLUDES:
7-1/4" C.T. Blade 28T (A-90451), Offset Wrench (782016-4), Guide Rule (164095-8)
5005BA
Lightweight Design For Increased
Maneuverability
• Electric Brake for operator safety
• Lock-Off Button prevents accidental start-up for increased
operator safety
• Rugged Steel Base for improved
operational stability
5-1/2" Circular Saw
SPECIFICATIONS
Blade Diameter
5-1/2" (140 mm)
Arbor
5/8" (15.9 mm)
Maximum Cutting Capacities:
0°
1-3/4" (45 mm)
45°
1-3/16" (31 mm)
No Load Speed
8,000 RPM
AMPS (120V)
8.0 A
Overall Length
9-13/16" (249 mm)
Net Weight
6.2 lbs (2.8 kg)
STANDARD EQUIPMENT INCLUDES:
5-1/2" Blade 50T (792334-2), Socket Wrench 9 (782209-3), Guide Rule (164095-8)
Cutting
Capacity
of 2-1/2"
(63.5 mm)
Dust Collector,
Cutting Capacity
of 2-3/8" (60 mm)
Blade Left,
Cutting
Capacity of
1-3/4"
(45 mm)
5007N
